Motion Concepts Matrx FLIPP LOXX Installation And Setup page 4

2.1 M
FLIPP LOXX
(Refer to images provided in Section 2.2: ADJUSTMENT OVERVIEW (p. 5-6))
OPTIONAL LOCKING SCREW
30 locking screw (A2) provided. Remove/unscrew the lever from the upper clamp housing and
mm
retain the original washer (a). Being careful to keep the clamping block (b) in position inside the upper
pivot, use the 5
mm
MOUNTING CLAMP INSTALLATION: (see Fig 2):
Secure the mounting clamp assembly (E) onto back shell* using hardware provided. If additional
clearance is required, install the spacer plate and long screws (c) provided. (*note: the mounting clamp
hardware is installed from the inside of the back shell)
HARDWARE INSTALLATION: (see Fig 3):
FLIPP LOXX
™
•
Loosen set-screw (d) and remove the lower D-Ring (D2) from the headrest post (1).
•
Install the headrest post (F) into the mounting clamp assembly (E), and adjust the headrest post
to the desired height/position (2). (note: loosen upper D-Ring if necessary)
•
Tighten the mounting clamp (E) to secure the headrest post in position (3).
•
Adjust the upper D-Ring (D1) so that it rests flush with the top of the mounting clamp (4), then secure
the D-Ring into place via the set-screw (d).
•
Reinstall and secure the Lower D-Ring (D2) onto the headrest post (5) so that it rests flush with the
bottom of the mounting clamp assembly.
HEADREST POST MODIFICATIONS:
If necessary, the headrest post (F) can be cut (shortened) to prevent any collision interference along
the back of the wheelchair/seating system. (Note: After cutting the post, the plastic end cap (G) can
be removed and re-installed into the newly cut post).
HEADREST PAD ADJUSTMENT: (see Fig 4):
Loosen the locking lever (A1) or locking screw (A2) on the upper pivot assembly (B). Slide the
horizontal bar (C) to the desired depth inside the upper pivot (1), and adjust the headrest angle by
pivoting/rotating the upper pivot to achieve the desired headrest position (2). Re-tigthen the locking
lever/locking screw (B) to secure the headrest into position.
FLIP-BACK LATCH MECHANISM: (see Fig 5):
To 'flip-back' the headrest, depress the release button (H) on the latch mechanism (1). To return the
headrest to its original position, simply lift upward on the headrest until the latch mechanism is
re-engaged (2). (The latch will lock in place automatically)
ELAN HEADREST PAD* INSTALLATION: (see Fig 6):
Position the headrest mounting collar over the pivot ball on the horizontal bar (1); then align and
secure the mounting collar to the headrest pad (2).
(*NOTE: Headrest sold separately).
I
™
(see Fig 1): The locking lever (A1) may be replaced with the optional
hex key (provided) to install the replacement locking screw (with washer)
/S -
- 4 -
I :
