Motion Concepts MaTRx Headrests Installation Manual

MaTRx Headrests with Standard Mounting Hardware

TOOLS REQUIRED:

Phillips Screwdriver
Wrenches: 7/16"
Tape Measure/Ruler
Allen Key: 5/32", 1/8"

INSTALLATION INSTRUCTIONS:

The headrest clamp is secured to the wheelchair back using the hardware provided.
Whenever possible, the clamp should be installed into existing mounting holes in the
backpan. If no holes are provided, holes may be drilled in the desired location using
the mounting plate as a template 1 .
The overall height of the headrest pad/ mounting post can be adjusted via the
main headrest clamp assembly. The depth of the headrest is adjusted along the
horizontal headrest rod and secured in position by the upper clamp assembly.
The headrest pad is secured to the mounting post via the corresponding mounting
ring and headrest hardware provided. (note: prior to tightening the mounting
hardware, the headrest pad can also be adjusted to the desired position/angle
around the pivot ball at the end of the headrest rod).
1 Important! - before drilling/modifying any backpan, be certain to contact
the back manufacturer to ensure the back is recommended to support a
headrest application.
w w w w w w . . m m o o t t i i o o n n c c o o n n c c e e p p t t s s . . c c o o m m
i i n n f f o o @ @ m m o o t t i i o o n n c c o o n n c c e e p p t t s s . . c c o o m m
- 3 -
Power Drill
1/4" Drill Bit
