Airwell AW-HDL012-N91 Service Manual

Hdl high wall

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Service Manual

HDL High Wall

AW-HDL012-N91/AW-YHDL012-H91

7SP023101/7SP02961

R32

English Manual

IMPORTANT NOTE:

Read this manual carefully before installing or operating your new air conditioning unit. Make sure to

save this manual for future reference.

20.AW.HDL.12.R32.SM.EN.06.03

Table of Contents

Need help?

Do you have a question about the AW-HDL012-N91 and is the answer not in the manual?

Questions and answers

Summary of Contents for Airwell AW-HDL012-N91

Page 1 Service Manual HDL High Wall AW-HDL012-N91/AW-YHDL012-H91 7SP023101/7SP02961 English Manual IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference. 20.AW.HDL.12.R32.SM.EN.06.03...
Page 2: Table Of Contents
Service Manual Table of Contents Part Ⅰ : Technical Information ...............1 1. Summary ........................1 2. Specifications ......................2 2.1 Specification Sheet......................2 2.2 Operation Characteristic Curve ..................4 2.3 Capacity Variation Ratio According to Temperature ............4 2.4 Cooling and Heating Data Sheet in Rated Frequency .............5 2.5 Noise Curve........................5 3.
Page 3 Service Manual 9. Maintenance ......................37 9.1 Malfunction Analysis.......................37 9.2 Flashing LED of Indoor Unit/Outdoor and Primary Judgement ........41 9.3 How to Check Simply the Main Part................49 10. Exploded View and Parts List .............63 10.1 Indoor Unit........................63 10.2 Outdoor Unit .........................65 11.
Page 4: Part Ⅰ : Technical Information
Service Manual Part Ⅰ : Technical Information 1. Summary Indoor Unit: Outdoor Unit Remote controller RC08A Caution: Risk of fire/flammable material Technical Information...
Page 5: Specifications
Service Manual 2. Specifications 2.1 Specification Sheet Model AW-HDL012-N91 7SP023101 Product Code Rated Voltage 220-240 Power Rated Frequency Supply Phases Power Supply Mode Outdoor Cooling Capacity 3200 Heating Capacity 3500 Cooling Power Input Heating Power Input Cooling Current Input 4.42 Heating Current Input 4.30...
Page 6 Service Manual Model of Outdoor Unit AW-YHDL012-H91 Product Code of Outdoor Unit 7SP062961 Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR CO., LTD Compressor Model QXF-B096zE190A Compressor Oil FW68DA Compressor Type Rotary L.R.A. 20.0 Compressor RLA 4.21 Compressor Power Input Overload Protector 1NT11L-6233 Throttling Method Capillary Operation temp...
Page 7: Operation Characteristic Curve
Service Manual 2.2 Operation Characteristic Curve Cooling Heating 220V Conditions 220V Indoor:DB27°C/WB19°C Outdoor:DB35°C/WB24°C Indoor air flow:Super High 230V Pipe length:5m 230V 240V Conditions Indoor:DB20°C/WB15°C 240V Outdoor:DB7°C/WB6°C Indoor air flow:Super High Pipe length:5m 10 20 30 40 50 60 70 80 90 100 Compressor speed (rps) Compressor speed (rps) 2.3 Capacity Variation Ratio According to Temperature...
Page 8: Cooling And Heating Data Sheet In Rated Frequency
Service Manual 2.4 Cooling and Heating Data Sheet in Rated Frequency Cooling: Pressure of gas pipe Inlet and outlet pipe Rated cooling Fan speed Fan speed Compressor connecting indoor temperature of heat condition( C) (DB/WB) Model of indoor of outdoor frequency and outdoor unit exchanger...
Page 9: Outline Dimension Diagram
Service Manual 3. Outline Dimension Diagram 3.1 Indoor Unit 168.5 159.5 Φ55 Φ55 Unit:mm Unit:mm Models Φ55 Φ55 Technical Information...
Page 10: Outdoor Unit
Service Manual 3.2 Outdoor Unit Unit:mm Technical Information...
Page 11: Refrigerant System Diagram
Service Manual 4. Refrigerant System Diagram Cooling and heating model Outdoor unit Indoor unit Gas pipe side Valve 4-Way valve Di s charge Heat Accumlator Suction exchanger Compressor (evaporator) Heat exchanger Liquid pipe (condenser) side Valve Strainer Capillary Strainer COOLING HEATING ��...
Page 12: Electrical Part
Jumper cap Yellow Brown COMP Compressor Blue Grounding wire YEGN Yellow/Green Black Violet Orange Note: Jumper cap is used to determine fan speed and the swing angle of horizontal lover for this model. ● Indoor Unit AW-HDL012-N91 6363222005 Technical Information...
Page 13 ● Outdoor Unit 60000700076302 These wiring diagrams are subject to change without notice; please refer to the one supplied with the unit.
Page 14: Pcb Printed Diagram
5.2 PCB Printed Diagram AW-HDL012-N91 Indoor Unit Top view Name Communication wire Live wire Fuse Neutral wire PG fan interface Auto button up&down swing interface Interface of PG feedback Needle stand for WiFi Interface of temperature sensor Interface of display board...
Page 15 Outdoor Unit ● Top view Name Interface of compressor wire Interface of reactor Fan terminal Interface of 4-way valve Terminal of electronic expansion valve Grounding wire Live wire Neutral wire Communication wire 10 Overload interface of compressor 11 Interface of temperature sensor ●...
Page 16: Function And Control
6. Function and Control 6.1 Remote Controller Introduction of RC08A...
Page 17 PRECAUTIONS TEMPERATURE SETTING BUTTONS DISPLAY TRANSMITTER SENSOR - (cooler) Press this button to decrease the Information are displayed when the remote control unit is powered up. Air temperature sensor When you press the set temperature. Operation Mode inside the remote buttons of the remote + (warmer) Press this button to increase the Automatic...
Page 18 USING THE REMOTE CONTROL UNIT OPERATION HOW TO INSTALL BATTERIES TEMPERATURE SENSOR SELECTOR Remove the lid in the rear part of the remote control unit. Under normal conditions the room temperature is detected and checked by the Insert two AAA alkaline batteries of 1,5 V-DC.Make sure to insert the batteries temperature sensor placed in the air conditioner.
Page 19 OPERATION OPERATION COOLING NOTE For several minutes after the start of heating operation, the indoor fan will not run until Verify that the unit is connected to the main the indoor heat exchanger coil has warmed up sufficiently. This is because the COLD power and the STANDBY lamp is lighted up.
Page 20 OPERATION OPERATION DEHUMIDIFYING (DRY) MANUAL If you want to manually adjust speed just set the FAN SPEED selector as desired. Each time the button is pressed, the fan speed is changed in sequence: 1. Set the MODE selector switch to “DRY” 2.
Page 21 OPERATION OPERATION SETTING THE TIMER In cooling mode or dehumidifying mode, 1 hour after the sleep curve is set, the setting temperature will rise by 1 degree C , 2 hours later, the setting temperature will rise by 2 degree C. After 3 hours, the setting temperature will not change any more. The timer can be selected by pressing TIMER ON button.
Page 22 OPERATION OPERATION C) HOW TO SET A PROGRAM FOR DAILY ON/OFF OPERATION Set vertical vanes to the front position during COOLING/DRY operation if humidity is high. 1. Press the TIMER OFF button to select the desired timer. If the vertical vanes are set to the left-most or right-most position, condensation may 2.
Page 23: Part Ⅱ : Installation And Maintenance
Service Manual Part Ⅱ : Installation and Maintenance 7. Notes for Installation and Maintenance Safety Precautions: 10. If the power cord or connection wire is not long enough, please get the specialized power cord or connection wire Important! from the manufacture or distributor. Prohibit prolong the wire by yourself.
Page 24 Service Manual Safety Precautions for Installing and Relocating the Unit: To ensure safety, please be mindful of the following precautions. Warnings 1. When installing or relocating the unit, be sure to keep the refrigerant circuit free from air or substances other than the specified refrigerant.
Page 25 Safety Operation of Flammable Refrigerant Qualification requirement for installation and maintenance man ●All the work men who are engaging in the refrigeration system should bear the valid certification awarded by the authoritative organization and the qualification for dealing with the refrigeration system recognized by this industry. If it needs other technician to maintain and repair the appliance, they should be supervised by the person who bears the qualification for using the flammable refrigerant.
Page 26 Main Tools for Installation and Maintenance 1. Level meter, measuring tape 2. Screw driver 3. Impact drill, drill head, electric drill 4. Electroprobe 5. Universal meter 6. Torque wrench, open-end wrench, inner hexagon spanner 7. Electronic leakage detector 8. Vacuum pump 9.
Page 27: Installation
8. Installation 8.1 Installation Dimension Diagram Space to the wall At least 15cm At least 15cm Space to the wall Drainage pipe...
Page 28 Installation procedures Start installation Preparation before installation Read the requirements select installation Prepare tools for electric connection location Select indoor unit Select outdoor unit installation location installation location Install the support of outdoor unit Install wall-mounting (select it according to the actual situation) frame, drill wall holes Connect pipes of indoor Fix outdoor unit...
Page 29: Installation Parts-Checking
8.2 Installation Parts-checking 8.4 Requirements for electric connection 1. Safety Precaution Name Name (1) Must follow the electric safety regulations when installing Indoor unit Sealing gum the unit. Outdoor unit Wrapping tape (2) According to the local safety regulations, use qualified power supply circuit and air switch.
Page 30 (3) Fix the wall-mounting frame on the wall with tapping screws 5. Connect the Pipe of Indoor Unit (ST4.2X25TA) and then check if the frame is firmly installed by (1) Aim the pipe joint at the corresponding bellmouth.(As show pulling the frame. If the plastic expansion particle is loose, in Fig.5) please drill another fixing hole nearby.
Page 31 7. Connect Wire of Indoor Unit 8. Bind up Pipe (1) Open the panel, remove the screw on the wiring cover and (1) Bind up the connection pipe, power cord and drain hose then take down the cover.(As show in Fig.11) with the band.(As show in Fig.14) (2) Reserve a certain length of drain hose and power cord Panel...
Page 32: Installation Of Outdoor Unit
8.6 Installation of Outdoor Unit Refer to the following table for wrench moment of force: Tightening torque(N . m) Hex nut diameter(mm) 1. Fix the Support of Outdoor Unit(Select it According to Φ6 15~20 the Actual Installation Situation) Φ9.52 30~40 (1) Select installation location according to the house structure.
Page 33: Vacuum Pumping And Leak Detection
(3) The water outlet can't be placed in water in order to drain 8.8 Check after Installation and Test smoothly.(As show in Fig.27) Operation 1. Check after Installation Check according to the following requirement after finishing installation. The drain hose can't be fluctuant Items to be checked Possible malfunction Has the unit been...
Page 34: Maintenance
9. Maintenance 9.1 Malfunction Analysis Note: When replacing the controller, be sure to insert the wire jumper into the new controller, otherwise the unit will display C5 Measure insulation resistance The breaker trips at once when it to ground to see if there is any is set to “ON”.
Page 35 Improper set of temperature Adjust set temperature If cooling (heating) load is Check the forecasted load of cooling (heating) proper Check and fill the leakage, then The refrigerant has leakage or is vacuumize it and supplement the re- insufficient frigerant as required Leakage between the high pres- Replace the compressor sure and the low pressure in-...
Page 36 Improper set of temperature Adjust set temperature If cooling (heating) load is Check the forecasted load of cooling (heating) proper Check and fill the leakage, then The refrigerant has leakage or is vacuumize it and supplement the re- insufficient frigerant as required Leakage between the high pres- Replace the compressor sure and the low pressure in-...
Page 37 The torque of the swing motor is not enough First, check whether the connection is Wrong connection The swing fan wrong. If no, replace the parts does not run. The controller is damaged(IC2003 is damaged, the swing relay can not close, etc) C o n t r o l l e r m a l f u n c t i o n ( I C 2 0 0 3 Change controller...
Page 38: Flashing Led Of Indoor Unit/Outdoor And Primary Judgement
9.2 Flashing LED of Indoor Unit/Outdoor and Primary Judgement Display Method of Indoor Unit Indicator Display (during Malfunction blinking, ON 0.5s and OFF Dual-8 A/C status Possible Causes Name 0.5s) Code Display Operation Cool Heating Indicator Indicator Indicator During cooling and drying Possible reasons: High operation, except indoor...
Page 39 Display Method of Indoor Unit Indicator Display (during Malfunction blinking, ON 0.5s and OFF Dual-8 A/C status Possible Causes Name 0.5s) Code Display Operation Cool Heating Indicator Indicator Indicator When the outdoor unit receive OFF 3S OFF 3S signal of Gathering refrigerant Gathering and blink and blink...
Page 40 Display Method of Indoor Unit Indicator Display (during Malfunction blinking, ON 0.5s and OFF Dual-8 A/C status Possible Causes Name 0.5s) Code Display Operation Cool Heating Indicator Indicator Indicator Decrease Overload or temperature is too All loads operate normally, frequency high;...
Page 41 Display Method of Indoor Unit Indicator Display (during Malfunction blinking, ON 0.5s and OFF Dual-8 A/C status Possible Causes Name 0.5s) Code Display Operation Cool Heating Indicator Indicator Indicator (during (during Compressor blinking, blinking, intermediate Showing during middle cooling or 0.25s 0.25s frequence in...
Page 42 Display Method of Indoor Unit Indicator Display (during Malfunction blinking, ON 0.5s and OFF Dual-8 A/C status Possible Causes Name 0.5s) Code Display Operation Cool Heating Indicator Indicator Indicator During cooling and drying operation, compressor will stop OFF 3S Refer to the malfunction analysis System is while indoor fan will operate;...
Page 43 Display Method of Indoor Unit Indicator Display (during Malfunction blinking, ON 0.5s and OFF Dual-8 A/C status Possible Causes Name 0.5s) Code Display Operation Cool Heating Indicator Indicator Indicator Malfunction of During cooling and drying phase current OFF 3S operation, compressor will stop detection and blink while indoor fan will operate;...
Page 44 Display Method of Indoor Unit Indicator Display (during blinking, ON 0.5s and OFF Dual-8 Malfunction A/C status Possible Causes 0.5s) Code Name Operation Cool Heating Display Indicator Indicator Indicator 1. Outdoor ambient temperature exceeds the operation range of unit (eg: less than-20oC or more Cool: compressor and Undefined than 60oC for cooling;...
Page 45 Analysis or processing of some of the malfunction display: 1. Compressor discharge protection Possible causes: shortage of refrigerant; blockage of air filter; poor ventilation or air flow short pass for condenser; the system has noncondensing gas (such as air, water etc.); blockage of capillary assy (including filter); leakage inside four-way valve causes incorrect operation;...
Page 46: How To Check Simply The Main Part
9.3 How to Check Simply the Main Part Indoor Unit (1) Malfunction of Temperature Sensor F1, F2 Main detection points: ● Is the wiring terminal between the temperature sensor and the controller loosened or poorly contacted? ● Is there short circuit due to trip-over of the parts? ●...
Page 47 2. Malfunction of Blocked Protection of IDU Fan Motor H6 (2) Malfunction of Blocked Protection of IDU Fan Motor H6 Main.detection.points: Main detection points: SmoothlyIs.the.control.terminal.of.PG.motor.connected.tightly? ● Is the control terminal of PG motor connected tightly? SmoothlyIs.the.feedback.interface.of.PG.motor.connected.tightly? ● Is the feedback interface of PG motor connected tightly? The.fan.motor.can't.operate.
Page 48 (3) Malfunction of Protection of Jumper Cap C5 Main detection points: ● Is there jumper cap on the mainboard? ● Is the jumper cap inserted correctly and tightly? ● The jumper is broken? ● Detectioncircuit of the mainboard isdefined abnormal? Malfunction diagnosis process: Troubleshooting for C5 malfunction...
Page 49 (4) Malfunction of Zero-crossing Inspection Circuit Malfunction of the IDU Fan Motor U8 Main detection points: Instant energization afte de-energization while the capacitordischarges slowly? Malfunction diagnosis process: Troubleshooting for U8 malfunction Turn power off for 1minute,the turn back on The unit returns to normal. U8 is still Conclusion:U8 is displayed due displayed...
Page 50 Service Manual 5. Malfunction of detecting plate(WIFI ) JF Start check if the connection wire are correctly connected detecting Replace the plate with the same model Is malfunction eliminated Replace the mainboard with the same model The end Installation and Maintenance...
Page 51 Service Manual Outdoor Unit (1) Capacitor charge fault (Fault with outdoor unit) (AP1 below refers to the outdoor control panel) Main Check Points: ●Use AC voltmeter to check if the voltage between terminal L and N on the wiring board is within 210VAC~240VAC. ●Is the reactor (L) correctly connected? Is the connection loose or fallen? Is the reactor (L) damaged? Fault diagnosis process: Troubleshooting for...
Page 52 Service Manual (2) IPM protection, phase current overcurrent (the control board as below indicates the control board 2. IPM protection, phase current overcurrent (the control board as below indicates the control board of outdoor unit) H5/P5 of outdoor unit) H5/P5 Mainly detect: (1) Compressor COMP terminal (2) voltage of power supply (3) compressor (4) Refrigerant-charging volume (5) air outlet and air inlet of outdoor/indoor unit...
Page 53 Service Manual (3)High temperature and overload protection diagnosis (AP1 hereinafter refers to the control board of the outdoor unit) Mainly detect: ●Is outdoor ambient temperature in normal range? ●Are the outdoor and indoor fans operating normally? ●Is the heat dissipation environment inside and outside the unit good? Fault diagnosis process: Overheat and high temperature protection...
Page 54 Service Manual (4) Start-up failure (following AP1 for outdoor unit control board) Mainly detect: ●Whether the compressor wiring is connected correct? ●Is compressor broken? ●Is time for compressor stopping enough? Fault diagnosis process: Power on the unit Restart it up after Is stop time of the compressor 3 minutes longer than 3 minutes?
Page 55 Service Manual (5) Out of step diagnosis for the compressor (AP1 hereinafter refers to the control board of the outdoor unit) Mainly detect: ●Is the system pressure too high? ●Is the input voltage too low? Fault diagnosis process: Out of step occurs in Out of step occurs once the operation unit is powered on.
Page 56 Service Manual (6) Overload and air exhaust malfunction diagnosis (following AP1 for outdoor unit control board) Mainly detect: ●Is the PMV connected well or not? Is PMV damaged? ●Is refrigerant leaked? Fault diagnosis process: 20 minutes after the complete unit is powered off Is the terminal FA for the Connect the...
Page 57 Service Manual (7) Power factor correct or (PFC) fault (a fault of outdoor unit) (AP1 hereinafter refers to the control board of the outdoor unit) Mainly detect: ●Check if the reactor (L) of the outdoor unit and the PFC capacitor are broken Fault diagnosis process: Start Check wiring of the...
Page 58 Service Manual (8) Communication malfunction: (following AP1 for outdoor unit control board) Mainly detect: ●Is there any damage for the indoor unit mainboard communication circuit? Is communication circuit damaged? ●Detect the indoor and outdoor units connection wire and indoor and outdoor units inside wiring is connect well or not, if is there any damage? Fault diagnosis process: Start...
Page 59 Service Manual (9) Malfunction of Overcurrent Protection E5 5. Malfunction of Overcurrent Protection Main detection points: Main detection points: ● Is the supply voltage unstable with big fluctuation? Is the supply voltage too low with overload? ● Is the supply voltage too low with overload? Hardware trouble? ●...
Page 60: Exploded View And Parts List
Service Manual 10. Exploded View and Parts List 10.1 Indoor Unit WiFi The component picture is only for reference; please refer to the actual product. Installation and Maintenance...
Page 61 Service Manual Part Code Description GWH12QB-K6DNA1I/I Product Code CB419N15000 Front Panel 20022479S Filter Sub-Assy 11122219 Display Board 30565263 Front Case Assy 00000200128 Guide Louver 10512722 Helicoid Tongue 26112508 Left Axile Bush 10512037 Rear Case assy 20162010 Drainage Hose 0523001408 Ring of Bearing 26152022 O-Gasket sub-assy of Bearing 7651205102...
Page 62: Outdoor Unit
Service Manual 10.2 Outdoor Unit The component picture is only for reference; please refer to the actual product. Installation and Maintenance...
Page 63 Service Manual Part Code Description AW-YHDL012-H91 Product Code 7SP062961 Left Side Plate 01303200P Fan Motor 1501308507 Motor Support 01703136 Condenser Assy 011002000588 Top Cover Sub-Assy 01253081 Rear Grill 01475014 Clapboard Sub-Assy 01233180 Compressor and Fittings 00103925G Compressor Gasket 76710287 4-Way Valve Assy 030152000016 Big Handle 2623343106...
Page 64: Removal Procedure
Service Manual 11. Removal Procedure Caution: discharge the refrigerant 11.1 Removal Procedure of Indoor Unit completely before removal. Step Procedure 1. Remove ﬁ lter assembly Front panel Open the front panel. Push the left ﬁ lter and right ﬁ lter until they are separate from the groove on the front panel.
Page 65 Step Procedure 4. Remove detecting plate(wifi) and electric box cover2 Remove the screws fixing detecting plate and remove detecting plate(wifi). Detecting plate(WIFI) Remove the screws fixing electric box cober2 and remove electric box2. 5. Remove front case sub-assy Screws Remove the screws fixing front case. Note: 1.Open the screw caps before removing the screws around the air outlet.
Page 66 Step Procedure 7. Remove electric box assy Screw Loosen the connection clasps between shield cover of electric box sub-assy and Clasps electric box, and then remove the shield cover of electric box sub-assy. Remove the screw ﬁ xing electric box assy . Electric box Shield cover of electric box sub-assy...
Page 67 Step Procedure Instruction: Some wiring terminal of this product is with lock catch and other devices. circlip The pulling method is as below: holder 1.Remove the soft sheath for some terminals at ﬁ rst, hold the circlip and then pull out the terminals.
Page 68 Step Procedure 9. Remove motor and cross ﬂ ow blade Remove the screws fixing motor clamp Screws and then remove the motor clamp. Motor clamp Cross ﬂ ow Remove the screws at the connection Screw Motor place of cross flow blade and motor; lift Holder the motor and cross flow blade upwards sub-assy...
Page 69: Removal Procedure Of Outdoor Unit
11.2 Removal Procedure of Outdoor Unit Warning: Be sure to wait for a minimum of 20 minutes after turning off all power supplies and discharge the refrigerant completely before removal. Step Procedure 1.Remove big handle Before disassamble. Remove the screws fixing handle、valve big handle cover and then remove them.
Page 70 Step Procedure 3.Remove grille 、protective grille and front panel Remove connection screws between the front grille and the front panel. Then remove the front grille. Remove connection screws connecting the front protective panel with the chassis and the motor support, and grille then remove the front panel.
Page 71 Step Procedure 6.Remove motor and motor support Remove the screws fixing motor and then remove the motor. Remove the screws fixing motor support and then remove the motor support. motor support motor 7.Remove electric box assy Remove the screws fixing electric box assy; cut off electric box assy the tieline;...
Page 72 Step Procedure 9.Remove 4-way valve assy 4-way valve assy Unsolder the welding joints connecting the 4-way valve assy with capillary sub-assy, compressor and condenser; remove the 4-way valve. Note: capillary Before unsoldering the welding joint, wrap the 4-way valve with a wet cloth completely to avoid damage to the valve caused by high temperature.
Page 73: Appendix
Appendix: Appendix 1: Reference Sheet of Celsius and Fahrenheit Conversion formula for Fahrenheit degree and Celsius degree: Tf=Tcx1.8+32 Set temperature Fahrenheit Fahrenheit Fahrenheit display Fahrenheit display Fahrenheit display Fahrenheit Celsius （℃） Celsius （℃） Celsius （℃） temperature temperature temperature （℉）（℉）（℉）...
Page 74: Appendix 3: Pipe Expanding Method
Appendix 3: Pipe Expanding Method Pipe Note: Pipe cutter Improper pipe expanding is the main cause of refrigerant leakage.Please expand the pipe according to the following steps: Leaning Uneven Burr A:Cut the pip ● Confirm the pipe length according to the distance of indoor unit and outdoor unit. ●...
Page 75: Appendix 4: List Of Resistance For Temperature Sensor
Appendix 4: List of Resistance for Temperature Sensor Resistance Table of Ambient Temperature Sensor for Indoor and Outdoor Units (15K) Temp( C) Resistance(kΩ) Temp( C) Resistance(kΩ) Temp( Resistance(kΩ) Temp( Resistance(kΩ) 138.1 18.75 3.848 1.071 128.6 17.93 3.711 1.039 121.6 17.14 3.579 1.009 16.39...
Page 76 Service Manual Resistance Table of Tube Temperature Sensors for Outdoor and Indoor (20K) Temp( C) Resistance(kΩ) Temp( C) Resistance(kΩ) Temp( Resistance(kΩ) Temp( Resistance(kΩ) 181.4 25.01 5.13 1.427 171.4 23.9 4.948 1.386 162.1 22.85 4.773 1.346 153.3 21.85 4.605 1.307 20.9 4.443 1.269 137.2...
Page 77 Service Manual Resistance Table of Discharge Temperature Sensor for Outdoor (50K) Temp( C) Resistance(kΩ) Temp( Resistance(kΩ) Temp( C) Resistance(kΩ) Temp( Resistance(kΩ) 853.5 18.34 4.75 799.8 93.42 17.65 4.61 89.07 16.99 4.47 703.8 84.95 16.36 4.33 660.8 81.05 15.75 4.20 620.8 77.35 15.17 4.08...
Page 78 Consult with the sales agency or manufacturer for details. ATTENTION : Le design et les données techniques sont donnés à titre indicatif et peuvent être modifiés sans préavis. AIRWELL RESIDENTIAL SAS 10,Rue du Fort de Saint Cyr, 78180 Montigny le Bretonneux- France www.airwell.com...
