Page 1: Table Of Contents
Split system air conditioners INSTALLATION MANUAL Contents Safety Precautions Read Before Installation Name of Parts AW-YSDM048-H11 Installation Procedure Troubleshootingve and Move and scrap the air conditioningcrap the air conditioning 0150530176 A Please read this manual carefully before installation. Keep this operation manual for future reference. - Page 2 EUROPEAN REGULATIONS IMPORTANT INFORMATION REGA- CONFORMITY FOR THE MODELS RDING THE REFRIGERANT USED Contains fluorinated greenhouse gases covered by the Kyoto Protocol All the products are in conformity with the following R410A European provision: -Low voltage Directive -Electomagnetic CompatibilitY ROHS The products are fulfilled with the requirements in the directive 2011/65/EU of the European parliament and of council on the Restriction of the use of Certain Hazardous...
-
Page 3: Safety Precautions
WARNING f the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. his appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 4 Safety Precautions WARNING No goods or nobody is permitted to Air-conditioner can't be installed in the environment with placed on or stand on outdoor unit.The inflammable gases because the inflammable gases near falling of goods and people may cause air-conditioner may cause fire hazard. accidents.
- Page 5 Safety Precautions WARNING Do not touch the fins on the heat exchanger with bare hands, When installing the unit in a small room, safeguard against for they are sharp and dangerous. hypoxia that results from leaked refrigerant reaching the threshold level. In the event of a refrigerant gas leak, provide adequate Consult the dealer for necessary measures to take.
- Page 6 Safety Precautions Before Installing the Unit Caution Do not install the unit in a place where there is a possibility When installing the unit in a hospital, take necessary measures of flammable gas leak. against noise. Leaked gas accumulated around the unit may start a fire. High-frequency medical equipment may interfere with the normal operation of the air conditioning unit or the air Do not use the unit to preserve food, animals, plants, artifacts,...
-
Page 7: Read Before Installation
Read Before Installation Items to Be Checked (1). Verify the type of refrigerant used by the unit to be serviced. Refrigerant Type: R410A (2). Check the symptom exhibited by the unit to be serviced. Look in this service handbook for symptoms relating to the refrigerant cycle. - Page 8 Read Before Installation Piping Materials Types of Copper Pipes (Reference) Maximum Operation Pressure Applicable Refrigerants 3.4MPa R22, R407C 4.15MPa R410A Use pipes that meet the local standards. Piping Materials/Radial Thickness Use pipes made of phosphorus deoxidized copper. Since the operation pressure of the units that use R410A is higher than that of the units for use with R22, use pipes with at least the radial thickness specified in the chart below.
- Page 9 Read Before Installation Air Tightness Test No changes from the conventional method. Note that a refrigerant leakage detector for R22 or R407C cannot detect R410A leakage. Halide torch R22 or R407C leakage detector Items to be strictly observed : Pressurize the equipment with nitrogen up to the design pressure and then judge the equipment's air tightness, taking temperature variations into account.
-
Page 10: Name Of Parts
Name of Parts AW-YSDM048-H11 Installation Procedure Installation of Outdoor Unit 1. Selection of the place of installation Select the place of installation satisfying the following conditions and, at the same time, obtain a consent from the client or user. Place where air circulates. - Page 11 Installation Procedure Installation of Outdoor Unit Procedure for Selecting the Location 1) Choose a place solid enough to bear the weight and vibration of the unit, where the operation noise will not be amplified. 2) Choose a location where the hot air discharged from the unit or the operation noise, will not cause a nuisance to the neighbors of the user.
- Page 12 Place the concrete foundation deep enough. Install the unit so that the angle of inclination must be less than 3 degrees. (a) Concrete foundation (b) Foundation anchor Unit Unit Anchor bolt Concrete foundation Concrete foundation To fix by bolts Anchor bolt Installation dimension (Unit:mm) AW-YSDM048-H11...
- Page 13 Installation Procedure Piping Connection 1. Piping diagram for single split AW-YSDM048-H11 Flare connection 3-way stop valve Gas pipe Indoor Outdoor unit unit Liquid pipe 3-way stop valve 2. Piping size for single split 9.52x0.8mm Liquid pipe 90+0.5 AW-YSDM048-H11 19.05x1.0mm Gas pipe Install the removed flare nuts to the pipes to be connected, then flare the pipes.
- Page 14 Installation Procedure Air Tightness Test After finishing connection of refrigerant pipe, it shall perform air tightness test. The air tightness test adopts nitrogen tank to give pressure according to the pipe connection mode as the following figure shown. The gas and liquid valve are all in close state. In order to prevent the nitrogen entering the circulation system of outdoor unit, tighten the valve rod before giving pressure (both gas and liquid valve rods).
- Page 15 Installation Procedure Vacuuming Piping vavuum method: to use vacuum pump Liquid stop valve Gas stop valve Detach the service port's cap of gas stop valve, the valve rod's cap for liquid stop valve and gas stop valve, and connect the service port into the projection Gauge manifold(R410A) of charge hose (low) for gaugemanifold.
- Page 16 If the fuse of control box is broken, please change it with the type of T25A/450VAC; If the fuse of control PC board is broken, please change it with the type of T3.15A/250VAC. But for AW-YSDM048-H11, the type is T6.3A/250VAC.
- Page 17 Installation Procedure Electrical Wiring WARNING: INTERCONNECTING WIRES MUST BE WIRED ACCORDING TO FIGURE BELOW. INCORRECT WIRING MAY CAUSE EQUIPMENT DAMAGE. SINGLE SPLIT SYSTEM UNITS WIRING DIGRAM AW-YSDM048-H11 Indoor unit terminal block Outdoor unit terminal block Power supply:1PH,220-230V~, 50Hz Installation Procedure...
-
Page 18: Troubleshootingve And
Troubleshooting... -
Page 19: Move And Scrap The Air
Move and scrap the air conditioning When moving, to disassemble and re-install the air conditioning, please contact your dealer for technical support. In the composition material of air conditioning, the content of lead, mercury, hexavalent chromium, polybrominated biphenyls and polybrominated diphenyl ethers are not more than 0.1% (mass fraction) and cadmium is not more than 0.01% (mass fraction).
