- Page 1 Installation and maintenance manual Manuel d’installation et de maintenance Aqu@Fan II 10 ÷ 90 English Français Fan coil units Ventilo-convecteurs IOM AQF-N.4GBF Date : July / Juillet 2007 Supersedes / Annule et remplace : IOM AQF-N.3GBF/06.07...
- Page 3 INSTALLATION INSTRUCTION NOTICE D’INSTALLATION INSTALLATIONSHANDBUCH ISTRUZIONI INSTALLAZIONE INSTRUCCIONES DE INSTALACIÓN...
-
Page 4: Table Of Contents
CONTENTS GENERAL RECOMMENDATIONS .......................3 SAFETY DIRECTIONS ................................3 WARNING ....................................3 INSPECTION AND STORAGE ........................4 WARRANTY ...............................4 MODEL NOMENCLATURE ..........................4 TECHNICAL SPECIFICATIONS ........................5 DIMENSIONS ..................................5 NET WEIGHT ................................... 5 INSTALLATION ............................6 CLEARANCE .................................... 6 UNIT LOCATION ..................................6 UNIT INSTALLATION ................................. 7 AWN / AWC CONSOLE UNIT .................................. -
Page 5: General Recommendations
POWER SUPPLY MUST BE SWITCHED OFF BEFORE STARTING WORK IN THE ELECTRIC CONTROL BOX GENERAL RECOMMENDATIONS Please read the following safety precautions very carefully before installing the unit. SAFETY DIRECTIONS Follow the safety rules in forces when you are working on your appliance. The installation, commissioning and maintenance of these units should be performed by qualified personnel having a good knowledge of standards and local regulations, as well as experience of this type of equipment. -
Page 6: Inspection And Storage
INSPECTION AND STORAGE At the time of receiving the equipment carefully cross check all the elements against the shipping documents in order to ensure that all the crates and boxes have been received. Inspect all the units for any visible or hidden damage. -
Page 7: Technical Specifications
TECHNICAL SPECIFICATIONS without Electric heating Size Power supply 230V-50Hz ALTERNATIF Fan motor power Fuse rating Am Fuse rating ASE / VDE Cable section mini mm² 3G1.5 with Electric heating Size Power supply 230V-50Hz ALTERNATIF Electric heating capacity BE1 1000 Fuse rating Gg Fuse rating ASE / VDE Cable section mini mm²... -
Page 8: Installation
INSTALLATION The unit is not designed to withstand weights or stresses from adjacent equipment, pipe work or constructions. Any foreign weight or stress on the unit structure could lead to a malfunction or a collapse with dangerous consequences for personnel and property. In such an event, the warranty shall be null and void. -
Page 9: Unit Installation
UNIT INSTALLATION AWN / AWC CONSOLE UNIT All units are to be installed against a wall as a floor console with support feet, or wall mounting as per dimensional data. On the fan coil units equipped with support feet, we recommend you to fix the unit to the wall through the both oblong holes located on the upper part of the unit chassis. -
Page 10: Cabinet Removal
CABINET REMOVAL When removing cabinet do not pull or lift it up by the discharge grilles, to avoid any damages on articulated fasteners of the access doors. On the AWC and AHC models, to hang the unit to the wall, it is necessary to remove the cabinet. To achieve this: ... -
Page 11: Water Connections
WATER CONNECTIONS OPERATING FACE The operating face of Left/Right versions is defined in relation to the position of the hydraulic connections when the unit is viewed facing the operator. Note: In the example below, the operating face is on the left. OPERATING FACE CHILLED WATER COIL - HOT WATER COIL... -
Page 12: Water Coil Headers
Crimp the 6.35 F fast-on clips with their insulator bushes (supplied) on the wires of this thermostat. OPERATING TEMPERATURE RANGE AQU@FAN II Opening 30 ± 4° C Closing 15 ± 4° C TAE20 AND AQUANET The sensor (change over) supplied is to be fitted to the water inlet tube. -
Page 13: Electrical Connections
ELECTRICAL CONNECTIONS WARNING Before carrying out any work on the equipment, make sure that the electrical power supply is disconnected and that there is no possibility of the unit being started inadvertently. Non-compliance with the above instructions can lead to injury or death by electrocution. WIRING DIAGRAM AND LEGEND SEE APPENDIX SE3530... -
Page 14: Optional Electric Heater
OPTIONAL ELECTRIC HEATER On request, all fan coil units can be factory mounted with an electric heater. The heating rod type electric heating is inserted directly into a finned exchanger. The latter may be a single block unit for sizes 10. 80. 90 or with an additional block for sizes 20 to 70. Do not install the electric heater on existing unit without using the supply air grilles resistant to high temperature. -
Page 15: Unit Initial Start-Up
UNIT INITIAL START-UP After installing the fan coil unit, water and electrical connections being made, it is imperative to re-install the cabinet on the AWC and AHC fan coil unit. The cabinet will be fixed by the both screws, mentioned on section "Unit installation/Cabinet removal". Before initial start up, be sure that the fan wheel is rotating free on it shaft. -
Page 16: Air Filter
AIR FILTER Changing the filter is a maintenance operation that should only be performed by qualified personnel. To avoid clogging of air filter, it is recommended to clean it regularly. Filter changes are required at the regular intervals. The time period between changes will depend upon the specific operating conditions. -
Page 17: Condensate Drain Pan
CONDENSATE DRAIN PAN The condensate drain pan should be checked periodically and cleaned and rinsed if required. MODELS 20 TO 70: You can gain direct access to the condensates tray on non-encased units and after removal of the casing on encased units (See instructions in the chapter «Unit Installation / Casing removal) for encased units. -
Page 18: In Case Of Warranty - Material Return Procedure
Take care It is not the manufacturer's policy to make recommendations in terms of water treatment (please contact a specialised water treatment company). However, given the critical nature of this subject, particular care should be taken to ensure that, if treatment is required, it works effectively. - Page 19 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO APPENDIX ANNEXE ANLAGE ALLEGATO ANEXO...
- Page 20 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO APPENDIX DIMENSIONS ..............III WIRING DIAGRAM ............VI AWC/AHC ................III SE3530 10 - 90 CMV ............VII AWN .................. IV SE3531 10 - 90 CMV/TBV ..........VIII AHN ................... IV SE3532 10 - 90 CMV/TBV1 ..........IX VIEW OF MAIN COMPONENTS - AWC FAN COIL UNIT ..V SE3533 10 - 90 CMV/TBMV1 ..........
- Page 21 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO DIMENSIONS DIMENSIONS ABMESSUNGEN DIMENSIONI DIMENSIONES AWC/AHC Auxiliary condensate drain pan and support feet supplied as optional. Bac auxiliaire et pieds en option A : auxiliary coil water inlet B : auxiliary coil water outlet C : main coil water inlet D : main coil water outlet A : entrée eau batterie auxiliaire...
- Page 22 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO A : auxiliary coil water inlet B : auxiliary coil water outlet C : main coil water inlet D : main coil water outlet A : entrée eau batterie auxiliaire B : sortie eau batterie auxiliaire C : entrée eau batterie principale D : sortie eau batterie principale 1065 430...
- Page 23 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO VIEW OF MAIN COMPONENTS - AWC FAN COIL UNIT VUE DES PRINCIPAUX COMPOSANTS - MODÈLE AWC UBERSICHT - AWC-MODELL COMPONENTI PRINCIPALE – UNITÀ VERTICALI MODELLO AWC VISTA DE LOS COMPONENTES PRINCIPALES - UNIDAD FAN COIL AWC Coil Batterie Register...
- Page 24 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO WIRING DIAGRAM SCHEMAS ELECTRIQUES STROMLAUFPLANS SCHEMA ELETRICO ESQUEMA ELECTRICO TAKE CARE! These wiring diagrams are correct at the time of publication. Manufacturing changes can lead to modifications. Always refer to the diagram supplied with the product. ATTENTION Ces schémas sont corrects au moment de la publication.
- Page 25 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO SE3530 10 - 90 CMV...
- Page 26 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO SE3531 10 - 90 CMV/TBV VIII...
- Page 27 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO SE3532 10 - 90 CMV/TBV1...
- Page 28 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO SE3533 10 - 90 CMV/TBMV1...
- Page 29 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO SE3534 10 - 90 CMV/TBV...
- Page 30 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO SE3535 10 - 90 AQUANET...
- Page 31 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO SE3585 70 - 90 AQUANET + ELECTRIC HEATING XIII...
- Page 32 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO SE3537 10 - 90...
- Page 33 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO 2-PIPE 4-PIPE COOLING HEATING LOW SPEED MEDIUM SPEED HIGH SPEED COILS COILS BATTERIES BATTERIES FROID CHAUD PETITE VITESSE VITESSE MOYENNE GRANDE VITESSE 2 TUBES 4 TUBES BATTERIEN BATTERIEN KÜHLUNG HEIZUNG KLEINE MITTLERE HOHE 2 ROHREN...
- Page 34 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO Q1 Q2 Q3 Q1 Q2 Q3 TAE20 TAE20 + SW TRM-VP TRM-VP TRM-VP TRM-VP TRM-VP TRM-VP...
- Page 35 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO + SW TRM-FA TRM-FA TRM-FA TRM-FA TRM-FA TRM-FA TRM-FA XVII...
- Page 36 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO MODEL NOMENCLATURE NOMENCLATURE DES APPAREILS BEZEICHNUNG DER GERÄTE NOMENCLATURA – DESCRIZIONE DEGLI APPARECCHI NOMENCLATURA XVIII...
- Page 37 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO...
- Page 38 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO...
- Page 39 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO...
- Page 40 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO XXII...
- Page 41 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO EXAMPLE EXEMPLE BEISPIEL ESEMPIO EJEMPLO A40.W.C.$.30.1000W.V1.V2.V4.G.G1.B.4V/TOR/2T.MPG.+ALV A40: MODEL 40 A40: MODELE 40 CONSOLE MOUNTING MONTAGE ALLEGE MURAL MODEL WITH CASING MODELE CARROSSE NO BRAND SANS MARQUE 2P/3R COIL BATTERIE 2T/3R 1000W: HEATING CAPACITY IN W 1000W: PUISSANCE CANNE CHAUFFANTE EN W...
- Page 42 APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO XXIV...
- Page 43 Declaramos, bajo nuestra responsabilidad, que los productos designados en este manual son conformes a las disposiciones de las directivas CEE enu- nuciadas a continuacion, asi como a las legislaciones nacionales que las contemplan. AQU@FAN II - Type AWC / AHC / AWN / AHN Mod: 10-20-30-40-50-60-70-80-90...
- Page 44 As part of our ongoing product improvement programme, our products are subject to change without prior notice. Non contractual photos. Dans un souci d’amélioration constante, nos produits peuvent être modifiés sans préavis. Photos non contractuelles. ACE Industrie Route de Verneuil 27570 Tillières-sur-Avre France : +33 (0)2 32 60 61 00...
