Vaporesso GTX ONE - Vape Kit Manual

Please read this instruction carefully before use to ensure a perfect experience.
If there is any additional requirement about this product, please consult the local agent or contact us through our website: www.vaporesso.com

EXPLODED VIEW

EXPLODED VIEW

SPECIFICATION

GTX ONE MOD
Dimensions 83.6 x 29.3 x 22.7mm
Resistance Range 0.15-5Ω
Output Power 5-40W
Output Voltage 0-4V
Charging Current DC 5V/2A, Type-C
Display 0.69" OLED Screen
Battery Capacity Built-in 2000mAh
Tank Connection 510 Thread
GTX TANK 18
Dimensions Φ18 x 48.6mm
Capacity 3ml / 2ml
Coils GTX 0.8Ω MESH Coil (12-20W)
GTX 1.2Ω MESH Coil (7-11W)

PACKING LIST

Regular Version:

1 x GTX ONE MOD
1 x GTX TANK 18 (3ml)
1 x GTX 0.8Ω MESH Coil (Pre-installed)
1 x GTX 1.2Ω MESH Coil (In Box)
4 x O-ring
1 x Glass Tube (2ml)
1 x Type-C USB Cable
1 x User Manual
1 x Warranty Card

TPD Version:

1 x GTX ONE MOD
1 x GTX TANK 18 (2ml)
1 x GTX 0.8Ω MESH Coil (Pre-installed)
1 x GTX 1.2Ω MESH Coil (In Box)
4 x O-ring
1 x Glass Tube (2ml)
1 x Type-C USB Cable
1 x User Manual
1 x Warranty Card

USE INSTRUCTIONS

Install the Tank

Install the tank to the battery by screwing the 510 thread. Make sure they are firmly connected.

Replace the Coil

Replace the Coil

  • Unscrew the thread base from the tank;
  • Pull out the used coil in the tank;
  • Install a new coil to the tank;
  • Reattach the thread base into place.

Fill the E-liquid

Fill the E-liquid

  • Unscrew the top cap from the tank;
  • Fill the e-liquid along the glass tube;
  • Reattach the top cap back into place;
  • Please wait 5 minutes for the e-liquid to soak into the coil completely.

Adjust the Airflow

To adjust the airflow volume, please rotate the air-inlet ring on the bottom of the tank.

System Operating

  1. Power on/off: press the power button 5 times in 2s.
    System Operating - Step 1
  2. Lock/unlock the Buttons: press the power button 3 times continuously to lock or unlock the "+" button and "-" button.
    System Operating - Step 2
  3. Start Vaping: press and hold the power button to start vaping. For your safety, please do not vape for more than 10 seconds at a time.
  4. Adjust the Power: press the "+" button or "-" button to adjust the power.
  5. Flip the Screen: press the power button and "+" button simultaneously to flip the screen 180°.
  6. System Setting: press the "+" button and "-" button simultaneously to enter the system setting interface, which includes VV, VW, SMART VW, and DEFAULT.
    VV: select "VV"and press the power button to enter VV mode.

    VW: select "VW" and press the power button to enter VW mode.

    SMART VW: select "SMART VW" and press the power button to enter ON/OFF setting.

    DEFAULT: select "DEFAULT", "YES" and press the power button to restore the factory setting.

PROTECTIONS

  1. Overtime Protection: the device will stop working if you vape for more than 10 seconds at a time, and "OVER TIME" will show on the screen.
  2. Low Resistance Protection: when an extremely low resistance is detected, the device will stop working and show "LOW ATOMIZER" on the screen.
  3. High Resistance Protection: when a high resistance is detected, the device will stop working and show "HIGH ATOMIZER" on the screen.
  4. No-load Protection: when there is no tank detected, the device will stop working and "CHECK ATOMIZER" will show on the screen.
  5. Short-circuit Protection: when a short-circuit is detected, the device will stop working and "SHORT ATOMIZER" will show on the screen.
  6. Low Voltage Protection: when the battery voltage is too low to start vaping, the device can not be operated and "LOW BATTERY" will show on the screen.
  7. Over Discharge Protection: when the battery voltage is extremely low during vaping, the device will stop working and "LOW POWER" will show on the screen.
  8. Over Charge Protection: the device will stop charging when it is fully charged.
  9. USB Input Protection: when the USB detects an input voltage exceeding the rated voltage, the device will stop charging.

  1. Please turn off the device when it is not in use.
  2. Do not leave the charging device unattended.
  3. Do not drop, throw or abuse your device, which may cause damage.
  4. Please use a standard USB output charger with proper charging current and voltage range.
  5. Keep away from the water or any flammable gas, liquid.
  6. Do not expose the device to direct sunlight, dust, moisture or mechanical shock.
  7. Do not expose the device to extreme temperature. (Recommended temperature range: -10~60℃ /14~140 ℉ while using and -10~45℃ /14~113 ℉ while storing).
  8. EEE Recycling: the product should not be treated as household waste, instead, it should be handed over to the applicable collection point for the recycling of electrical and electronic equipment.
  9. Battery Recycling: the product battery should not be treated as household waste, instead, it should be handed over to the applicable used battery collection point for recycling.
  10. Only have your device repaired by Vaporesso. Do not attempt to repair it by yourself as damage or personal injury may occur.


This refillable electronic cigarette is intended for use with compatible e-liquid, which may contain nicotine. Nicotine is an addictive substance and it is not suitable or recommended to use in following cases:

  1. This device is not suitable for:
    • Persons under the legal smoking age.
    • Persons experiencing heart disease, stomach or duodenal ulcers, liver or kidney problems, long-term throat disease or difficult breathing due to bronchitis, emphysema or asthma.
    • Persons with an overactive thyroid gland or experiencing phaeochromocytoma (a tumour of the adrenal gland that can affect blood pressure).
    • Persons taking certain medications like Theophylline, Ropinirole or Clozapine and etc..
  2. This device is not recommended for:
    • Non-smokers
    • Pregnant or breastfeeding women
