HARDWARE IDENTIFICATION CHART
This chart is provided to help identify the hardware used in the assembly process. Place the washers or
the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to
check the length of the bolts and screws.
3/16"
1/4"
0
1/2
1
0
10
20
6
NOTICE: The length of all bolts and screws, except those with flat
heads, is measured from below the head to the end of the bolt
or screw. Flat head bolts and screws are measured from the
top of the head to the end of the bolt or screw.
After unpacking the unit, open the hardware bag and make sure that you have all the following items.
Some hardware may be already attached to the part.
5/16"
3/8"
1/2
2
1/2
30
40
50
60
8
10
Part Number and Description
33
54
10
14
32
38
80
81
11
1/2"
3
1/2
4
70
80
90
100 110 120 130 140 150
MILLIMETERS
12
Bolt, Button Head (M10 x 1.5 x 43mm)
Bolt, Button Head (M8 x 1.25 x 20mm)
Bolt, Button Head (M8 x 1.25 x 16mm)
Nylock Nut (M6 x 1)
Nylock Nut (M10 x 1.5)
Flange Bolt (M8 x 1.25 x 15mm)
Bolt, Hex Head (M6 x 1 x 33mm)
Arc Washer (M6)
Arc Washer (M8)
6
INCHES
1/2
5
1/2
length
length
6
in.
mm.
Qty
2
4
6
2
2
2
2
2
4
