E2S D1xB2X05 Instruction Manual page 2

2.2 Surge Current Ratings for use in Fire Alarm
Systems
Model Nominal Voltage
D1XB2 Voltage Range
X05DC024 24Vdc 20-28Vdc
X10DC024 24Vdc 20-28Vdc
X15DC024 24Vdc 20-28Vdc
X21DC024 24Vdc 20-28Vdc
2.3 NEC & CEC Class / Division Ratings for US /
Canada
The D1xB2X Xenon beacons comply with the following
standards:
UL 1203 (Ed. 5) 2018
UL1638A (Ed. 1) 2016
UL1638 (Ed. 5) 2017
CSA C22.2 No. 30-M1986 (Ed. 3) 2016
CSA C22.2 No. 25 (Ed. 4) 2017
CSA C22.2 No. 205 (Ed. 3) 2017
The D1xB2X05DC012, D1xB2X05DC024 &
D1xB2X05DC048 Xenon Beacons are rated as follows:
Class I Div 1 Group ABCD T5 Ta -55°C to +80°C
Class I Div 1 Group ABCD T6 Ta -55°C to +65°C
Class II Div 1 Group EFG T5 Ta -55°C to +80°C
Class III Div 1 Ta -55°C to +80°C
The D1xB2X05AC115 & D1xB2X05AC230 Xenon Beacons
are rated as follows:
Class I Div 1 Group ABCD T4A Ta -55°C to +70°C
Class I Div 1 Group ABCD T5 Ta -55°C to +55°C
Class I Div 1 Group ABCD T6 Ta -55°C to +40°C
Class II Div 1 Group EFG T4 Ta -55°C to +40°C
Class III Div 1 Ta -55°C to +40°C
The D1xB2X10DC024 & D1xB2X10DC048 Xenon Beacons
are rated as follows:
Class I Div 1 Group ABCD T4 Ta -55°C to +80°C
Class I Div 1 Group ABCD T4A Ta -55°C to +70°C
Class I Div 1 Group ABCD T5 Ta -55°C to +50°C
Class II Div 1 Group EFG T4 Ta -55°C to +80°C
Class III Div 1 Ta -55°C to +80°C
E2S Warning Signals Impress House, Mansell Road, Acton, London W3 7QH
Document No. D191-00-201-IS
Peak RMS
Flash Surge surge
Rate current current
1Hz 955mA 370mA
1.33Hz 960mA 370mA
1.5Hz 955mA 365mA
Double 960mA 355mA
1Hz 970mA 700mA
1.33Hz 970mA 700mA
1.5Hz 990mA 700mA
Double 990mA 695mA
1Hz 990mA 925mA
1.33Hz 990mA 930mA
1.5Hz 990mA 925mA
Double 990mA 905mA
1Hz 1590mA 1220mA
1.33Hz 1710mA 1240mA
1.5Hz 1590mA 1240mA
Double 1650mA 1200mA
Issue 3 28-11-22
The D1xB2X10AC115 & D1xB2X10AC230 Xenon Beacons
are rated as follows:
Class I Div 1 Group ABCD T4 Ta -55°C to +70°C
Class I Div 1 Group ABCD T4A Ta -55°C to +55°C
Class II Div 1 Group EFG T4 Ta -55°C to +40°C
Class III Div 1 Ta -55°C to +40°C
The D1xB2X15DC024 & D1xB2X15DC048 Xenon Beacons
are rated as follows:
Class I Div 1 Group ABCD T3C Ta -55°C to +80°C
Class I Div 1 Group ABCD T4 Ta -55°C to +55°C
Class II Div 1 Group EFG T4 Ta -55°C to +80°C
Class III Div 1 Ta -55°C to +80°C
The D1xB2X15AC115 & D1xB2X15AC230 Xenon Beacons
are rated as follows:
Class I Div 1 Group ABCD T4 Ta -55°C to +70°C
Class I Div 1 Group ABCD T4A Ta -55°C to +55°C
Class II Div 1 Group EFG T4 Ta -55°C to +40°C
Class III Div 1 Ta -55°C to +40°C
The D1xB2X21DC024 & D1xB2X21DC048 Xenon Beacons
are rated as follows:
Class I Div 1 Group ABCD T3B Ta -55°C to +80°C
Class I Div 1 Group ABCD T3C Ta -55°C to +75°C
Class I Div 1 Group ABCD T4 Ta -55°C to +50°C
Class II Div 1 Group EFG T3C Ta -55°C to +40°C
Class III Div 1 Ta -55°C to +40°C
The D1xB2X21AC115 & D1xB2X21AC230 Xenon Beacons
are rated as follows:
Class I Div 1 Group ABCD T3C Ta -55°C to +60°C
Class I Div 1 Group ABCD T4 Ta -55°C to +55°C
Class I Div 1 Group ABCD T4A Ta -55°C to +40°C
Class II Div 1 Group EFG T4 Ta -55°C to +40°C
Class III Div 1 Ta -55°C to +40°C
Installation must be carried out in compliance with the
National Electric Code / Canadian Electric Code
2.4 NEC Class / Zone ratings US
The D1xB2X Xenon beacons comply with the following
standards:
UL 60079-0 (Ed. 6) 2017
UL 60079-1 (Ed. 7) 2015
UL 60079-31 (Ed. 2) 2015
The D1xB2X05DC012, D1xB2X05DC024 &
D1xB2X05DC048 Xenon Beacons are rated as follows:
Class I Zone 1 AEx db IIC T4 Ta -55°C to +80°C
Class I Zone 1 AEx db IIC T5 Ta -55°C to +75°C
Class I Zone 1 AEx db IIC T6 Ta -55°C to +60°C
Zone 21 AEx tb IIIC T99°C Ta -55°C to +80°C
The D1xB2X05AC115 & D1xB2X05AC230 Xenon Beacons
are rated as follows:
Class I Zone 1 AEx db IIC T4 Ta -55°C to +70°C
Class I Zone 1 AEx db IIC T5 Ta -55°C to +50°C
Zone 21 AEx tb IIIC T153°C Ta -55°C to +70°C
www.e2s.com Tel: +44 (0)208 743 8880
Sheet 2 of 9
