3 - Installation and User Guidance

3 Installation and User Guidance
3.1

Initial Inspection

After receiving the device, the customer should visually inspect the product as follows:
1) Inspect the label found on the bottom of the device (see section 2.3.1 Hardware Identification) and
make sure the label is not missing, obscured, or modified.
2) Check the PCI Hardware Identifier on the device label and make sure it matches the
listed for the device on the PCI web site for Approved Devices. Go to the PCI compliance web page
and search for MagTek, and find the product name, DynaFlex II Go. Compare the Hardware ID and
Firmware ID: https://www.pcisecuritystandards.org/assessors_and_solutions/pin_transaction_devices
Note: Firmware ID is accessible by connecting DynaFlex II Go to a host device via USB or Bluetooth
LE, using the latest software provided by MagTek (see section 2.3.2 Firmware Identification).
3) Check the Device serial number (SN) and make sure it matches with labels on shipping materials and
documentation.
4) Visually inspect the device, per D998200593 DynaFlex II Go, Device Inspection Document,
which is included in the package with each device. See section 4.1 Periodic Inspection for more
information regarding visual inspection of the device.
5) Follow the steps in section 2.3.2 to view the PCI firmware versions installed on the device. Make
sure this matches one of the
that in PCI listings, lowercase "x" is a wildcard meaning 'any single character.'
3.2

Installation

Connect the device to a USB host for control and power (if battery power is not sufficient). DynaFlex II
Go products are designed to provide flexible mounting options such as:
•
External clip
•
Embedded lanyard
3.3

Environmental Conditions

The specified environmental conditions to operate and store the device are:
•
Operating temperature range: 0°C to 35°C / 5% to 90% RH
•
Storage temperature range: -20°C to 45°C / 5% to 90% RH
For safety, battery charging is disabled when the device is connected outside the recommended operating
temperature range.
The security of the reader is not compromised by altering the environmental conditions outside the stated
operating ranges above. Any temperature or operating voltage outside the values in the table below will
trigger environmental security protections, resulting in a tamper condition. The device will need to be
returned to the factory for inspection before this condition can be cleared.
Sensor
Internal Voltage
Temperature
DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Firmware # values listed on the PCI web site for DynaFlex II Go. Note
Low Threshold Value
1.60V ± 0.055V
-45°C ± 15°C
Page 11 of 18 (D998200596-100)
Hardware #
High Threshold Value
3.775V ± 0.1V
120°C ± 10°C
