C.5 Di gital I/O Sample Program

************************************************************************************

// SuperIO relative definition (Please reference to Table 1)

#d efine byte SIOIndex //This parameter is represented from N o te1

#d efine byte SIOData //This parameter is represented from N o te2

#d efine vo id IOWriteByte(b yte IOPort, b yte Value);

#d efine b yte IOReadByte(b yte IOPort);

// Digital Input Status relative definition (Please reference to Table 2)

#d efine byte DInput1LDN // This parameter is represented from N ote3

#d efine byte DInput1Reg // This parameter is represented from N o te4

#d efine byte DInput1Bit // This parameter is represented from N o te5

#d efine byte DInput2LDN // This parameter is represented from N ote6

#d efine byte DInput2Reg // This parameter is represented from N o te7

#d efine byte DInput2Bit // This parameter is represented from N o te8

#d efine byte DInput3LDN // This parameter is represented from N ote9

#d efine byte DInput3Reg // This parameter is represented from N o te10

#d efine byte DInput3Bit // This parameter is represented from N o te11

#d efine byte DInput4LDN // This parameter is represented from N o te12

#d efine byte DInput4Reg // This parameter is represented from N o te13

#d efine byte DInput4Bit // This parameter is represented from N o te14

#d efine byte DInput5LDN // This parameter is represented from N ote15

#d efine byte DInput5Reg // This parameter is represented from N o te16

#d efine byte DInput5Bit // This parameter is represented from N o te17

#d efine byte DInput6LDN // This parameter is represented from N ote18

#d efine byte DInput6Reg // This parameter is represented from N o te19

#d efine byte DInput6Bit // This parameter is represented from N o te20

#d efine byte DInput7LDN // This parameter is represented from N o te21

#d efine byte DInput7Reg // This parameter is represented from N o te22

#d efine byte DInput7Bit // This parameter is represented from N o te23

#d efine byte DInput8LDN // This parameter is represented from N ote24

#d efine byte DInput8Reg // This parameter is represented from N o te25

#d efine byte DInput8Bit // This parameter is represented from N o te26

************************************************************************************

Appendix C – Digital I/O Information

122
