Preface
This manual describes how to install and use the Fiber Ethernet
Adapter. This Fiber Adapter allows options of different fiber
connections, such as connector types and segment distance.
To get the most out of this manual, you should have an
understanding of Ethernet networking concepts.
In this manual, you will find:
• Introduction on Fiber Adapter
• Product features
• LEDs functions
• Hardware installation
• Software installation
• Specifications
User's Guide
檔名: pcifxp.doc
原作者: Carrie Chen
列印時間: 1/31/2003 3:06 PM
Fiber Ethernet Adapter
1
Advertisement
Table of Contents
Related Manuals for TRENDnet TE100-PCI
Summary of Contents for TRENDnet TE100-PCI
-
Page 1: Preface
Preface This manual describes how to install and use the Fiber Ethernet Adapter. This Fiber Adapter allows options of different fiber connections, such as connector types and segment distance. To get the most out of this manual, you should have an understanding of Ethernet networking concepts. -
Page 2: Table Of Contents
Fiber Ethernet Adapter Table of Contents ...1 REFACE ...2 ABLE OF ONTENTS ...3 RODUCT VERVIEW ...3 IBER THERNET DAPTER ...3 ACKAGE ONTENTS ...4 RODUCT EATURES Driver Support...5 5Software Support ...5 LEDs ...6 ARDWARE NSTALLATION NSTALLING IBER DAPTER INTO ONNECTING EMOTE ONNECTING TO ETWORK Cabling Requirements ...11... -
Page 3: Product Overview
Product Overview Fiber Ethernet Adapter Figure 1: Adapters with SC (left) and ST (right) connectors, featuring two LEDs Package Contents When you unpack the product package, you shall find the items listed below. Please inspect the contents, and report any apparent damage or missing items immediately to our authorized reseller. -
Page 4: Product Features
Fiber Ethernet Adapter Product Features • Provide a variety of fiber connections: SC, ST, MT-RJ or VF-45 connectors for multi-mode, and SC connector for single-mode • Support 32-bit Bus Master operation • PCI bus clock speed range from 16.75 to 40 MHz •... -
Page 5: Driver Support
Driver Support The Fiber Adapter supports a wide range of drivers for commonly used network operating systems: • NDIS2 (DOS, OS/2, LANtastic, WFW3.1…) • NDIS for Win95, 98, NT 3.51, 4.0, 5.0 WFW3.11 • NetWare ODI driver for DOS, OS/2, and NetWare 3.x, 4.x, 5.0 Server •... -
Page 6: Leds
Fiber Ethernet Adapter LEDs LNK Link This LED comes on when a network connection is established successfully. ACT Activity This LED flashes when the port is transmitting or receiving data. LEDs Status Indication A valid network connection established. Steady LNK stands for LINK. Disconnection. -
Page 7: Hardware Installation
Hardware Installation Installing Fiber Adapter into PCI slot Step 1: Turn off the power to the PC. Step 2: Remove any metal decorations from your hands and wrists. Step 3: Remove the cover from your PC. Step 4: Locate an empty, non-shared bus mastering 32-bit PCI slot and remove the corresponding backplate. - Page 8 Fiber Ethernet Adapter Install the Fiber Ad ap ter into the PCI slot a nd sc rew it onto the b ac kp la te Figure 2: Installing Fiber Adapter into 32-bit PCI slot <Note> Always ensure the power is cut off before any installation to avoid electric shock and possible damage to the equipments.
-
Page 9: Connecting Remote Wake-Up Cable
Connecting Remote Wake-Up Cable This is an optional function. Proceed with the installation only when your PC supports this Remote Wake-Up and you wish to make use of this function. Please check your Motherboard User’s Guide for more information. Step 1: Make sure the power to the PC is off. -
Page 10: Connecting To Your Network
Fiber Ethernet Adapter Connecting to Your Network This section describes how to connect the Fiber Adapter to a 100 Mbps fiber-based Ethernet network, which contributes to its optimal performance. <Note> You must connect the Fiber Adapter to the network before installing the network driver. -
Page 11: Cabling Requirements
Cabling Requirements For cabling requirements and maximum segment distance when connecting the Fiber Adapter to your network, please refer to the Ordering Information on page 18. T X c onnec tor Insert the othe r end of c a b le into the 'rec eive' (RX) c onnec tor on network hub or switc h Insert the othe r end of c a b le... -
Page 12: Software Installation
Fiber Ethernet Adapter Software Installation Diagnostic Software The program (RSET8139.exe) provided in the software diskette is 1) to set up the Fiber Adapter’s hardware configuration, and 2) for diagnostic purpose. Step 1: Execute the program. This program MUST be run under pure DOS. Press <SPACE>... -
Page 13: About Hardware's Configuration
About Hardware’s Configuration Step 1: Choose “View Current Configuration” from the Main Menu and press <ENTER> to view the adapter’s current configuration. Step 2: If you want to change the current configuration, choose “Set Up New Configuration” from the Main Menu and press <ENTER> to proceed. Step 3: Choose “Media Type”... -
Page 14: Run Diagnostics
Fiber Ethernet Adapter Run Diagnostics Step 1: Choose “Run Diagnostics” from the Main Menu. Press <ENTER>. Step 2: Select a test or diagnostics, and press <ENTER> to run: --> Run EEPROM Test --> Run Diagnostics On Board --> Run Diagnostics On Network (requires twoTE100PCIFXplus on the same network. -
Page 15: Loading Network Drivers
Loading Network Drivers The Fiber Adapter is shipped with one software diskette enclosed. The following drivers are provided in the diskette: • NDIS2 (DOS, OS/2, LANtastic, WFW3.11…) • NDIS for Win95, 98, NT 3.51, 4.0, 5.0, WFW3.11 • NetWare ODI driver for DOS, OS/2, and NetWare 3.x, 4.x, 5.0 Server •... -
Page 16: Quick List For Supported Network Drivers
Fiber Ethernet Adapter Quick List for Supported Network Drivers Network OS Text File Path Windows NT 3.51 \Winnt\Msnt.txt Windows NT 4.0 \Winnt\Msnt.txt Windows 95 NDIS3 OSR2 \W95osr2\Netrts.inf Windows 98 NDIS5 \Win98\Win98.txt Windows for Workgroups 3.1 NDIS2 \Ndis2\Ndis.txt \Ndis2\Wfw.txt Microsoft Network Client 3.0 \Ndis2\Ndis.txt \Ndis2\Msclient.txt LAN Manager 2.0... -
Page 17: Specifications
Specifications Applicable Standards Speed 100BASE-FX: Performance Fiber Cable Wavelength LED Indicators Dimensions Net Weight Power Consumption Operating Temperature Storage Temperature Humidity Emissions User’s Guide 檔名: pcifxp.doc 原作者: Carrie Chen 列印時間: 1/31/2003 3:06 PM Fiber Ethernet Adapter IEEE 802.3u 100BASE-FX PCI Specifications Revision 2.1 200Mbps full-duplex 100Mbps half-duplex 148,800pps for 100Mbps... -
Page 18: Ordering Information
Fiber Ethernet Adapter Ordering Information Please indicate the desired connector type and connection distance when ordering. Connector Wavelength of 1300nm Fiber Optic required Type on Fiber Adapter Multi-mode, 62/125 µm Multi-mode, 62/125 µm VF-45 Multi-mode, 62/125 µm MT-RJ Multi-mode, 62/125 µm Single-mode, 10/125 µm Single-mode, 10/125 µm Single-mode, 10/125 µm...
