Electric Heater Kit
MODELS:
FLEXX24HP240V1AH
FLEXX36HP240V1AH
FLEXX48HP240V1AH
FLEXX60HP240V1AH
INSTALLATION
MANUAL
Thank you for choosing our product.
Please read this Installation & Owner's Manual carefully before
operation and retain it for future reference.
If you lose this Manual, please contact your local distributor
visit www.greecomcomfort.com/resources now to download an
file the electronic version.
CAT NO : GREE_FLEXX_ELECTRIC_HEATER_KIT_INSTALLATION_MANUAL_092721
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Gree FLEXX24HP240V1AH
Summary of Contents for Gree FLEXX24HP240V1AH
- Page 1 MODELS: Thank you for choosing our product. Please read this Installation & Owner’s Manual carefully before operation and retain it for future reference. FLEXX24HP240V1AH FLEXX36HP240V1AH If you lose this Manual, please contact your local distributor FLEXX48HP240V1AH visit www.greecomcomfort.com/resources now to download an FLEXX60HP240V1AH file the electronic version.
-
Page 2: Attention Installing Personnel
ATTENTION INSTALLING PERSONNEL Prior to installation, thoroughly familiarize yourself with this Installation Manual. Observe all safety warnings. During installation or repair, caution is to be observed It is your responsibility to install the product safely and to educate the customer on its safe use... - Page 3 CAUTIONS ENSURE THAT ALL POWER IS DISCONNECTED PRIOR TO ATTEMPTING INSTALLATION OF THIS HEATER KIT. THERE MAY BE MORE THAN ONE DISCONNECT SERVICING THE UNIT. A MEANS OF STRAIN RELIEF AND CONDUCTOR PROTECTION MUST BE PROVIDED AT THE SUPPLY WIRE ENTRANCE INTO CABINET.
- Page 4 1. Remove the front panel and upper access panel from the air handler. 2. Disassemble the electrical box...
- Page 5 3. Remove the electrical box 4. Disassemble the metal plate at the mounting hole of the electric heater...
- Page 6 5. Install the electric heater to the metal plate position which disassembles in step 4. (Notes: There are two holes circled below which are used to fasten the electric heater bracket during installation)
- Page 7 6. Install breaker (Notes: When installation, you need to lift up the buckle first, hold the breaker bracket and then put down the buckle to fix the breaker) 7. Connect the electric heater terminal...
- Page 8 8. After installation, the schematic diagram is as follows: 9. Install the electrical box back to the original position 10. Install the front panel and upper panel back to the air handler. Electric heater installation is completed.
- Page 9 Electric Heater Kits Model Cooling capacity(ton) Optional electric heater Optional electri 2.0 / 3.0 FLEXXHTR5KW FLEXX24,36HP230V1AH 2.0 / 3.0 FLEXXHTR8KW FLEXX24,36HP230V1AH 3.0 / 4.0 / 5.0 FLEXX36,48,60HP230V1AH FLEXXHTR10KW 4.0 / 5.0 FLEXXHTR15KW FLEXX48,60HP230V1AH 4.0 / 5.0 FLEXXHTR20KW FLEXX48,60HP230V1AH...
- Page 10 U.S. CONTACT INFORMATION TRADEWINDS, LLC E-mail: info@twclimate.com Contractor Support: 888-850-7928 | Mon-Fri 8 AM - 5 PM EDT G R E E C O M F O R T . C O M CAT NO: GREE_FLEXX_ELECTRIC_HEATER_KIT_INSTALLATION_MANUAL_092721...
