- Page 1 Instruction Manual REFRIGERATOR Model:ES 7295 NF ES 7295 IN NF ES 7490 IN NF ES 7500 IN NF...
-
Page 2: Table Of Contents
Contents SAFETY WARNINGS ......................1 INSTALLATION ........................2 Location ........................2 Door Handle Install Illumination(optional) ..............2 Reversing the Door Swing ..................4 Door Space Requirements ..................6 Levelling the Unit ....................... 6 Cleaning Before Use ....................6 Before Using Your Unit ....................6 Interior Accessories .................... -
Page 3: Safety Warnings
1. SAFETY WARNINGS WARNING―Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING―Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. WARNING―Do not damage the refrigerant circuit. WARNING―Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer. -
Page 4: Installation
2. INSTALLATION 2.1 Location When selecting a position for your unit you should make sure the floor is flat and firm, and the room is well ventilated. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the electrical consumption. - Page 5 3) Cap the screw caps on the handle screws. 5) Remove the screws and take the handles down. 4) Take out the screw caps from the handle screw holes. 6) Cap the screw caps on the door handle holes again.
-
Page 6: Reversing The Door Swing
7) Install the handles into the door handle holes of the other side in accordance with the handle installation instructions. 2.3 Reversing the Door Swing 1) Take off knuckle guard. 2) Take off top hinge. - Page 7 3) Take off the door of refrigerating 7) Assemble the door of freezer chamber on chamber. the lower hinge. 4) Take off middle hinge with a screw driver. 8) Assemble middle hinge assembly to left side of the cabinet . 5) Take off the door of freezing chamber.
-
Page 8: Door Space Requirements
Door Space Requirements The unit's door must be able to open fully as shown. W×D≥990×1025mm Levelling the Unit To do this adjust the two levelling feet at the front of the unit. If the unit is not level, the door and magnetic seal alignments will not be covered properly. -
Page 9: Interior Accessories
beverages in the freezer to prevent bursts and other losses. Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is working properly and to allow it time to fall to the correct temperature. Your unit should not be overfilled. Do not damage the power cord under any condition so as to ensure safety use, do not use when the power cord is damaged or the plug is worn. -
Page 10: Product Overview
3. PRODUCT OVERVIEW *Dotted line represents the position of air outlet and return air inlet. *All images in this instruction manual are for indication only; please refer to your individual unit for details. 4. OPERATION 4.1 Operation Instructions Temperature control ... - Page 11 ⑤ ④ ③ ② ① fast cool (External display) A.SET: gear setting key. Display screen Gear 1 Gear 2 Gear 3 Gear 4 Gear 5 Display For the first power-on, the display screen (including the key light) will be displayed in full for 3s, and then the gear in the middle displays the state of running.
-
Page 12: Noise Inside The Unit
Fast cool function Enter: Circulating modulation rapid cooling mode. Operate: Indicator of rapid cooling lights up, and the refrigerator operates at 2℃. Exit: 1. Operate 150min under the rapid cooling mode. 2. Temperature adjustment can exit from the rapid cooling mode. ... -
Page 13: Change The Light Bulb
◆ To prevent cold air escaping from the unit, try to limit the number of times you open the door. We recommend that you only open the door when you need to put food in or take food out. Change the Light Bulb Lamp replacement by professionals 5. -
Page 14: Do Not Shield Positions Of Air Outlet And Return Air Inlet Of The Refrigerator
6.5 Do not shield positions of air outlet and return air inlet of the refrigerator 6.6 Do not keep foods of higher temperature close to temperature sensor 6.7Take out drawer of freezing chamber of refrigerator and put foods directly on the glass partition 7. -
Page 15: Disposal
Every now and then check if the appliance is sufficiently ventilated (adequate air circulation behind the appliance). In normal temperature conditions, please arrange the thermostat at the middle setting. Before loading the appliance with packages of fresh food, make sure they are cooled to ambient temperature.
