Summary of Contents for TRENDnet TEG-S224

  • Page 1 Quick Installation Guide TEG-S224...
  • Page 2: Table Of Contents

    Table of Contents Table of Contents English ... 1. Before You Start 2. Hardware Installation ... Technical Specifications ... Troubleshooting ... Version 09.27.2007...
  • Page 3: Minimum Requirements

    26-Port 10/100/1000Mbps Copper Gigabit Switch Internet Cable/DSL Workstations with 10/100Mbps Ethernet Card Modem Router 1000Mbps 10/100Mbps Package Content TEG-S224 Quick Installation Guide 2 mounting brackets and screws 4 Rubber Feet Power Cord (TEG-S224) Workstation with Copper Gigabit PCI Adapter (TE100-PCIWN)
  • Page 4: Hardware Installation

    2. Hardware Installation 1. Connect the Power Cord to the TEG-S224 and then to a power outlet. 2. Connect a CAT-5e or CAT-6 RJ-45 network cable from the computer to an available Ethernet port on the TEG-S224. English...
  • Page 5 To ensure the highest level of customer service and support, please take a moment to register your product Online at: Register Your Product www.trendnet.com/register Thank you for choosing TRENDnet English...
  • Page 6: Technical Specifications

    Technical Specifications Standards Protocol Data Transfer Rates Topology Network Cables Number of Ports Transmission Method Packet Filtering/ Forwarding Rate MAC Address Learning RAM Buffer Filtering Address Table General IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000BASE-T IEEE 802.3x Full-Duplex Flow Control CSMA/CD Ethernet:...
  • Page 7 Physical and Environmental AC inputs Power Consumption Temperature Humidity Dimensions (L x W x H) Weight Certification 100-240V AC Universal, 50/60 Hz 11.75 Watts Operating: 0 ~ 40 C, Storage: -10 ~ 70 C ° ° Operating: 10% ~ 90% (non-condescending) 440 x 140 x 44 mm 4.7lbs FCC Class A, CE Mark Class A, VCCI Class A...
  • Page 8: Troubleshooting

    Troubleshooting After connecting the Switch to a power outlet, the LEDs do not turn on. Check the connection of the power adapter to the TEG-S224 and the power outlet. Also check that the power outlet is receiving power. When I connect a computer to the Switch port, the LINK/ACT LED turns on, but the 1000Mbps LED remains off.
  • Page 9 Return Material Authorization (RMA) number, accompanied by a copy of the dated proof of the purchase. Products returned to TRENDnet must be pre- authorized by TRENDnet with RMA number marked on the outside of the package, and...
  • Page 10 ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE OR USE OF TRENDNET’S PRODUCTS. TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S...
  • Page 11 Certifications This equipment has been tested and found to comply with FCC and CE Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received. Including interference that may cause undesired operation.
  • Page 12: Product Warranty Registration

    English/Espanol - 24/7 Francais/Deutsch - 11am-8pm, Monday - Friday MET Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com/register 20675 Manhattan Place Torrance, CA 90501 Copyright ©2007. All Rights Reserved. TRENDnet.
