TRENDnet TE100-SK3plus Specifications

TE100-SK3plus
5-Port 10/100Mbps Switched Fast Ethernet Network Kit
TRENDnet's TE100-SK3plus, a 10/100Mbps Fast Ethernet
Switched Network Kit, is a complete solution for connecting
two personal computers to share files, printers, and hard
drives. The kit comes with two 32-bit PCI Bus 10/100Mbps
NWay Fast Ethernet PCI cards (TE100-PCIWN), one 5-port
10/100Mbps Ethernet Mini Switch (TE100-S55Eplus), two 15
feet CAT5 cables, and an easy-to-use installation guide. As
your network grows, you can uplink switches or network hubs
to the 5-port mini switch to gain more ports. Designed
especially for home and small office use, this reliable network
kit lets you cruise in 200Mbps (full-duplex) and expand your
network in the future.
FEATURES
10/100Mbps 32-Bit N-way Fast Ethernet PCI Card (TE100-PCIWN)
Complies with IEEE 802.3 and IEEE 802.3u standards
Single RJ-45 connector (CAT 3, 4, 5 UTP/STP cables for
10Mbps operation and CAT 5 UTP/STP cable for 100Mbps
operation)
32-bit PCI Bus master mode
Plug and Play (PnP) for auto-configuration
Supports half- and full-duplex operation
Built-in FIFO buffers reduces overhead of memory transfers
Compatible with all popular operating systems
5 Year Warranty
5-Port 10/100Mbps Ethernet Mini Switch (TE100-S55Eplus)
Complies with IEEE 802.3 and IEEE 802.3u standards
Five 10/100Mbps NWay auto-negotiation UTP/STP RJ-45 ports
Operates at maximum packet filtering and forwarding rate
MDI-II uplink port (shared) for easy expansion
128Kb buffer memory
Half- or full-duplex mode
Filtering Address Table up to 1K MAC entries (per device)
Compact design with external power adapter
5 Year Warranty
TRENDnet
TRENDware, USA
What's Next in Networking
BENEFITS
Upgrabable:
Add workstations as needed.
Expandable:
Add a server, Internet station, network
printer, or network hub without
changing the switch.
Flexible:
Switch is small enough to be put
anywhere it is needed.
Cost Effective:
With lifetime warranty, purchase only
the parts you need.
TE100-SK3plus (11-17-2002)
