TRENDnet TE100-SK3 Features

TE100-SK3
5-Port 10/100Mbps Switch Fast Ethernet Network Kit
TRENDnet's TE100-SK3, a 10/100Mbps Fast Ethernet
Switch Network Kit, is a complete solution for connecting two
personal computers to share files, printers, and hard drives.
The kit comes with two 32-bit 10/100Mbps N-way Fast
Ethernet PCI cards (TE100-PCIWN), one 5-port 10/100Mbps
Ethernet Mini Switch (TE100-S55E), two 20 feet cables, and
an easy-to-use installation guide. As your network grows, you
can uplink switches or network hubs to the 5-port mini switch
to gain more ports. Designed especially for home and small
office use, this reliable network kit lets you cruise in 200Mbps
(full-duplex) and expand your network in the future.
FEATURES
10/100Mbps 32-Bit N-way Fast Ethernet PCI Card (TE100-PCIWN)
Complies with IEEE 802.3 and IEEE 802.3u standards
10/100Mbps auto-sensing
Single RJ-45 connector (CAT 3, 4, 5 UTP cables for 10Mbps
operation and CAT 5 UTP cable for 100Mbps operation)
32-bit PCI Bus master mode
Plug and Play (PnP) for auto-configuration
Supports half- and full-duplex operation
Built-in FIFO buffers reduces overhead of memory transfers
Compatible with all popular operating systems
5 Year Warranty
5-Port 10/100Mbps Ethernet Mini Switch (TE100-S55E)
Complies with IEEE 802.3 and IEEE 802.3u standards
5-port N-way 10/100Mbps auto-detection
Operates at maximum packet filtering and forwarding rate
Supports an extra MDI-II connector for easy expansion
1 Megabyte buffer memory
Half- or full-duplex mode
Filtering Address Table up to 1K MAC entries (per device)
Compact design for external power adapter
5 Year Warranty
TRENDnet
TRENDware, USA

BENEFITS

Upgrabable:
Add workstations as needed.
Expandable:
Add a server, Internet station, network
printer, or network hub without
changing the switch.
Flexible:
Switch is small enough to be put
anywhere it is needed.
Cost Effective:
With a 5 year warranty, purchase only
the parts you need.
R
TE100-SK3 (11-17-2002)
