Terra OD012 Instructions

Product description

Optical receivers (in text - receivers) are converting optical signals into electrical signals and amplify for further distribution
TV signals in cable TV networks.
Receivers are powered from the mains 230 V~.
The receivers are intended for indoor use only.

Safety instructions

Installation of the receiver must be done according IEC60728-11 and national safety standards.
The receiver is powered from mains 230 V~. This voltage is dangerous to life.
Any repairs must be done by a skilled personnel.
Receiver is double isolated from the mains 230 V~.
To ensure safe operation of the receiver follow these instructions:
Do not remove the cover of the power supply section, without disconnecting the unit from the mains supply.
Do not plug the receiver into the mains supply if the power cord or plug is damaged.
Do not plug the receiver into the mains supply until all cables have been connected correctly.
The mains socket must be easily accessible.
Receiver shall not be exposed to dripping or splashing water.
Avoid placing receiver next to central heating components and in areas of high humidity.
If the receiver has been kept in cold conditions for a long time, keep it in a warm room no less than 2 hours before plugging
into the mains.
Do not insert any objects into ventilation openings.
The ventilation should not be impeded by covering the ventilation openings with items, such as newspapers, table-cloths,
curtains.
Mount in locations where children not likely to be present. Shields of cables must be connected to main potential equalization
bus.
From top, front and bottom of installed receiver must be at least 10 cm free space.
An connector of optical cable after disconnection emits optical radiation.
Avoid looking directly into beam, laser light can cause eye injuries and result in permanent loss of vision.

External view

mounting supports
LED display
Optical input
Vers. 1.03
Optical receivers OD012, OD102
Output test point
-20 dB
Adjustment buttons
RF OUT
Functional
grounding clamp
1
DC voltage indicator
mounting supports
Mains connection
User Manual
EN
