Optical transmitter OT301
Optical receivers OR301, OR301M
Product description
The optical transmitters series OT and the optical receivers series OR are intended to distribute SAT IF and DTT (Digital
terrestrial TV) signals through a fibre optic.
The transmitter OT301 converts 2 SAT IF sub-bands and DTT band into an optical signals.
AGC (automatic gain control) provides for automatically controlled constant RF level to the laser.
The receivers OR301, OR301M convert optical signals into 2 SAT IF sub-bands and DTT band.
OLC (optical level control) provides for fixed RF output level at different level of optical input.
Receiver with letter M (OR301M) have built-in multiswitch (quad outputs).
The product is intended for indoor usage only.
Coding explanation of receiver
OR
3
01
M
3 - 3 cable system 2 SAT IF signals and DTT signals.
OT - optical transmitter
OR - optical receiver
M (only for receivers) - Multiswitch type output (quad).
01 – series
Advertisement
Table of Contents
Related Manuals for Terra OT301
Summary of Contents for Terra OT301
- Page 1 The optical transmitters series OT and the optical receivers series OR are intended to distribute SAT IF and DTT (Digital terrestrial TV) signals through a fibre optic. The transmitter OT301 converts 2 SAT IF sub-bands and DTT band into an optical signals. AGC (automatic gain control) provides for automatically controlled constant RF level to the laser.
- Page 2 INSTALLATION Requirements for external power supply unit (PSU) Transmitter Receiver Output voltage range +12 V min ...+20 V max +12 V ± 1 V Output current > 1.25 A > 0.5 A Output connector pin (range 0.5...0.75 mm type 3.5/1.35 EP (+) plug •...
- Page 3 Transmitters must be fixed with 3 steel screws, receivers – with 2 steel screws Ø 4-4.5 mm. The screws are not included in a package. OR301M Optical splitter to the network OT301 - optical transmitter at440 - UHF TV channel amplifier OR301M - optical receiver with 2x4 multiswitch...
- Page 4 TERRA confirms, that this product is in accordance with Custom Union Technical Regulations: “Electromagnetic compatibility of technical equipment“ CU TR 020/2011, “On safety of low-voltage equipment“ CU TR 004/2011. TERRA confirms, that this product is in accordance with safety standard AS/NZS 60065: 2012 and EMC standards of Australia.
- Page 5 – short circuit occurred or overload on LNB or terrestrial preamplifier above). green – works correctly Technical specifications - LED indicator of laser status. Type OT301 red - laser is damaged green - works correctly Satellite inputs yellow - laser ageing Number of inputs - RF input of DTT signal, DC output for preamplifier +12 V switchable.
- Page 6 OPERATING AND SETTINGS External view of the receiver General notes Read the safety instruction first. All unused optical connectors must be covered with a clean protective caps. All unused F type connectors must be terminated with 75 Ω loads. SAT IF and DTT inputs on transmitter due to DC voltage must be terminated with 75 Ω...
