- Page 1 INSTALLATION MANUAL Elavo™ White Ceramic Undermount Bathroom Sinks w/ Overflow KCU-231 / KCU-241 / KCU-251 www.kraususa.com Toll Free: 1.800.775.0703 © 2021 Kraus USA Plumbing LLC REV. September 17, 2021...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: STOP DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
-
Page 3: Prior To Installation
Toll-Free: 800-775-0703 or customerservice@kraususa.com The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus Sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to install all Kraus products by hiring a licensed professional. - Page 4 Jig Saw Scissors Phillips Screwdriver Tape Measure Pencil Screwdriver Putty Knife NOTE: Specialized tools may be necessary to install Kraus Ceramic Undermount sinks with countertop materials other than wood, marble, or granite Parts List (included) · Cut-Out Template · Mounting Hardware...
- Page 5 Dimensions 17" (432mm) 20 5/8" (525mm) R1 1/8" R1 1/8" (30mm) (30mm) 18 1/2" (470mm) 14 1/2" (368mm) Ø 2 3/4" Ø 2 5/8" (70mm) (68mm) KCU-231 KCU-241 17" x 17" x 7 1/2"* 20 5/8" x 14 3/8" x 8 1/8"* 23 1/4"...
- Page 6 1. Cut paper template · Use scissors to cut along the inside line of the paper template. Clip Location Rim of Lavatory Cut Along This Line 14.25” (362mm) 2. Trace template · Compare cut template with sink to ensure proper size. ·...
- Page 7 3. Cut countertop · Cut the countertop opening by carefully following the pencil line traced from the template. NOTE: Please use the appropriate saw that best fits your countertop material.
- Page 8 4. Install anchors · Flip countertop over and place on a foam pad for protection. Use cutout template to mark the anchor placement on the countertop. Drill 5/16” diameter x 3/8” deep hole in countertop. · Place epoxy in the drilled hole. Insert brass nut anchors into the drilled hole and wait until the epoxy cures.
- Page 9 5. Install sink · Use a bead of clear silicone (or preferred adhesive) around the rim of the sink. Check the alignment of the sink to the opening in the countertop. Place sink over cutout hole and press firmly. Attach mounting hardware to secure bowl. Remove excess sealant from inside lip. ·...
- Page 10 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 11 Commercial Warranty Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied are given, including but not limited to, any implied warranty of merchantability or fitness for a particular purpose.
- Page 12 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
