FEATURES
• Compliant with ITU-T G.992.1 (G.dmt), G.992.2 (G.lite) and ANSI T1.413 Issue 2
• TDM-C400 is additionally compliant with ITU-T G.992.3 (G.dmt.bis / ADSL2), G.992.5 (ADSL2+) and provides up to 24 Mbps
downstream rate
• Compatible and interoperable with major Central Office side ADSL DSLAM or Multi-service Access System
• One 10/100 Base-TX Ethernet port and one USB 1.1 device port for PC / LAN connection
• RFC2684 / 1483 to bridge or route traffic over ATM over ADSL
• Support Networking protocols such as PPP, IP routing, NAPT, relay / client
• Support local and remote configuration and management through Web, Telnet or SNMP
• Simple firmware upgrade via TFTP, FTP or HTTP
• 5-Year Warranty
ADSL/ADSL2+ Ethernet / USB Combo
Modem Router
TDM-C400
The TDM-C400 is ADSL/ADSL2+ customer premise equipment that
provides high-speed asymmetrical data transmission on a single
twisted copper pair. The DSL line interface supports various ADSL
standards, up to ADSL2+. At the DTE side these CPEs provide, dual
interfaces, a 10/100 Ethernet interface and one USB port for easy
connection to user's PC or LAN environment. TDM-C400 delivers
broadband access for enterprises, telecommuters, home, and
remote office workers with high-speed data transfer requirements.
TDM-C400
rev:12.07.2006
