  • Page 1 MJ BARINA SPARK MJ Barina Spark Owner’s Handbook...
  • Page 2 Change of name, address or ownership In the event of a Safety Recall, or for various reasons, Holden may need to contact you as the owner of this vehicle. If you have recently changed your address, or name, or purchased this vehicle second-hand, please help us to help you by taking a few minutes to fill in and mail the forms at the beginning of the Service/warranty booklet.
  • Page 3: Table Of Contents

    Contents Introduction ........2 In brief ..........4 Keys, doors, and windows ... 14 Seats, restraints ......24 Storage ........40 Instruments and controls ..... 44 Lighting ........57 Infotainment system ..... 61 Climate control ......71 Driving and operating ....76 Vehicle care .........
  • Page 4: Introduction

    Please note that all information, illustrations and specifications in this Handbook are based on the latest production information available at the time of printing. Holden reserves the right to make changes at any time without notice and without incurring any obligation.
  • Page 5 Introduction • Directional data, e.g. left or right, Introduction Danger, warnings or front or back, always relate to Your vehicle is a designed and cautions the direction of travel. combination of advanced technology, • Depending on the model variant, safety, environmental friendliness and Danger integrated special equipment economy.
  • Page 6: In Brief

    In brief In brief Locking/unlocking the Seat adjustment vehicle Seat positioning Remote keyless entry Initial drive information 1. Move the seat forwards or backwards by lifting the bar at The key operates all locks and the the front and sliding the seat. ignition.
  • Page 7 In brief Seat backrests Seat height Head restraint adjustment 1. Recline the seatback by pulling • Rotate the hand wheel to adjust • Lift the head restraint up to raise. the lever. the height of the seat. • Push the locking button and push Seats, restraints, see page 24.
  • Page 8 In brief Seat belts Mirror adjustment Exterior mirrors Interior mirrors 1. Withdraw the belt from the reel. To adjust the external rear view mirrors: 2. Pull the metal tongue across To reduce headlamp glare from your body into the buckle, until it •...
  • Page 9 In brief Steering wheel adjustment 1. To unlock, move the lever down. 2. Adjust the steering wheel. 3. To lock, move the lever up. Ensure the steering wheel is locked in position before driving. Steering wheel adjustment, see page 44.
  • Page 10 In brief 1. Bonnet release lever Instrument panel overview 2. Side air vents 3. Wiper and washer lever 4. Horn and driver’s airbag 5. Instrument panel 6. Lamp control 7. Centre air vents 8. Infotainment system 9. Centre display 10. Hazard warning flasher 11.
  • Page 11 In brief Hazard warning flashers Exterior lighting High/low beam OFF: Turns all lamps and lights off. To activate high beam: Press ¨ to turn the hazard warning flasher on or off, when the ignition is 8 (Park lamps): Turns on the park 1.
  • Page 12 In brief Turn and lane change Horn Windscreen wiper/washer signals Windscreen wiper Press j. • Push the lever in the direction the steering wheel is turned. Intermittent wipe • A green arrow on the instrument Continuous slow speed panel flashes when the lamps Continuous fast speed are in operation.
  • Page 13 In brief Windscreen washer Air conditioning system Transmission Manual transmission The air conditioning panel is located Pull to wash the windscreen. in the centre of the dashboard. Washer fluid is sprayed and the • When shifting from one gear to wipers cycle for a short time.
  • Page 14 In brief LOCK: The key can only be inserted Getting started Starting the engine and removed from this position. 1. Check that windows, mirrors and ACC: When the key is in this lamps are clean. position, the audio system operates. 2.
  • Page 15 In brief Parking 1. Apply the park brake. 2. If facing uphill or on flat ground, select 1st gear. If facing downhill, select reverse gear. 3. Shut all windows. 4. Turn the ignition off and remove the key. 5. Press e on the key to lock all doors.
  • Page 16: Keys, Doors, And Windows

    Keys, doors and windows Keys, doors and Keys and locks About the keys • The remote control has a range windows of approximately 20 metres. Keys • The range depends on the charge of the key battery, Keys and locks ......14 on ambient conditions, the key’s Doors ..........17 location and the area between...
  • Page 17 9. Replace the back cover. Replacement keys 10. Check key operation. If a key is lost, a replacement can be ordered through any Holden Caution Dealer by quoting the key code number. The number is printed on a Avoid touching the flat surfaces detachable tag supplied with the key.
  • Page 18 Keys, doors and windows • Keep the transmitter away from Central locking system Locking water and direct sunlight. Doors may be locked and unlocked If the transmitter gets wet, wipe it by pushing buttons on: with a soft cloth. • The driver’s door •...
  • Page 19: Doors

    Keys, doors and windows Locking: Doors Child safety 1. Push the locking knob on the rear door locks inside of all doors, except the Manual door locks driver’s door. 2. Close the driver’s door and lock from the outside with the key. Insert the key and turn towards the rear of the vehicle.
  • Page 20 Keys, doors and windows Tailgate Remote unlocking/locking Caution Warning Do not pull the inside door handle while the child security door is Do not drive with the tailgate locked. Damage may occur. open or ajar, e.g. when transporting bulky objects. To open a rear door when the child Dangerous exhaust fumes may security door lock is activated, open...
  • Page 21: Vehicle Security

    Keys, doors and windows • The engine is automatically Manual unlocking/locking Vehicle security immobilised when the key is turned to the LOCK position Immobiliser and is removed from the ignition The immobiliser prevents switch/lock. unauthorised engine starting. • Only valid ignition keys can be used to start the engine.
  • Page 22: Exterior Mirrors

    Keys, doors and windows Exterior mirrors Power mirrors Folding mirrors Convex mirror The convex exterior mirrors provide a wider view of the road and traffic. Note Objects appear smaller than their actual size. When the vehicle is parked, the To adjust the external rear view mirrors may be folded flat against mirrors: the side of the vehicle.
  • Page 23: Interior Mirrors

    Keys, doors and windows Heated mirrors Interior mirrors Windows The vehicle has heated rear view mirrors. Rear view mirror Manual windows The heating is switched on automatically when the rear window demister is switched on. The vehicle may have manual rear To reduce headlamp glare from following vehicles, pull the lever door windows.
  • Page 24 Keys, doors and windows Push and hold or pull and hold the Power windows Child safety switch required button, to raise or lower a window. Warning The window stops moving up as Before operating the power soon as the button is released. windows, check they are free of obstructions and that passengers Danger...
  • Page 25 Keys, doors and windows Sun visors The sun visors may be folded down or folded outwards over the side window, to prevent glare. • The sun visors may have mirrors. • Close the mirror cover when driving. Warning Do not place the sun visor in such a position that reduces visibility of the roadway, traffic or other objects.
  • Page 26: Seats, Restraints

    Seats, restraints Seats, restraints Head restraints Height adjustment Front head restraints Warning Head restraints ......24 This safety feature is not Front seats........25 intended as a headrest. It Rear seats ........27 is solely for the reduction of Seat belts........29 whiplash neck movement in an accident involving your vehicle.
  • Page 27: Front Seats

    Seats, restraints • Adjust the seat so that your legs Rear head restraints Front seats are slightly angled when against the pedals. Seat position • Adjust the backrest angle to easily reach the steering wheel Warning with arms slightly bent. See To avoid reducing the Steering wheel adjustment on effectiveness of seat belts,...
  • Page 28 Seats, restraints Seat adjustment Danger Do not sit nearer than 25 cm from the steering wheel, to allow safe airbag deployment. Warning Do not adjust the driver’s seat when the vehicle is moving as 1. Move the seat forwards or 1.
  • Page 29: Rear Seats

    Seats, restraints Heated front seats Rear seats Folding down rear seatbacks Danger Ensure the rear seatbacks are securely in place. Do not press the release button on the top of the seatback while the vehicle is moving. This could cause damage or injuries to the •...
  • Page 30 Seats, restraints To fold the rear seatbacks down To return the seatback to the upright separately: position: 1. Lift the seatback upwards and 1. Slide the front seat forwards. push firmly back into place. 2. Adjust the front seatback to an Make sure the seat belts are upright position.
  • Page 31: Seat Belts

    Seats, restraints for which they have been Seat belts Belt force limiters designed. A slack belt will greatly In the front seats, stress on the body reduce the protection afforded to is reduced by the gradual release of the wearer. the belt during a collision.
  • Page 32 Seats, restraints Three point belt Warning Fitting Incorrect handling (e.g. removal or fitting of belts or belt buckles) can trigger the belt tensioners causing a risk of injury. When the belt tensioners have been deployed, v illuminates on the instrument panel. See Seat belt reminder on page 51.
  • Page 33 Seats, restraints Removing Seat belt use during Seat belt care pregnancy Warning Warning Care should be taken to avoid contamination of the webbing The lap belt must be positioned with polishes, oils and chemicals, as low as possible across the and particularly battery acid.
  • Page 34: Airbag System

    Seats, restraints Airbag system Warning Warning When triggered, airbags inflate WARNING – EXTREME HAZARD Airbags are part of the within milliseconds. They also supplemental restraint system deflate so quickly that it is often Do not use a rearward facing (SRS) as they assist, but do not unnoticeable during the collision.
  • Page 35 Seats, restraints Front airbag system Warning The horn pad must not be covered with adhesive or any other material. The driver should adjust the seat as far rearward as possible while still maintaining control of the vehicle. Front airbags will inflate in certain Warning severe frontal or near frontal Do not place any objects on or...
  • Page 36 Seats, restraints The side airbags deploy in most, but Side airbag system not all severe side impacts. Warning Do not fit unauthorised seat covers as they may impair the deployment of the side airbags. Do not position your body or any object (including pillows) between front seats and doors.
  • Page 37 Seats, restraints Curtain airbag system Warning Do not position your body or any object (including pillows) in the area in which the airbag inflates. There must be no objects in the area in which the airbag inflates. Refer to the illustration. Use the hooks above the doors only to hang up light articles of clothing.
  • Page 38: Child Restraints

    • The front seats and upholstery suitable for your child. are damaged. • The headliner or trim panels are damaged. It is recommended that this work be carried out by a Holden Dealer or approved repairer.
  • Page 39 Seats, restraints Selecting the right Older children Warning A child should use a normal three system point seat belt only when: Always ensure that the seat Infants belt fits firmly around the child • They can sit against the back of Rearward facing infant capsules restraint.
  • Page 40 Earlier types of child restraints compartment in line with the three restraint, contact an approved may not attach securely to this rear seating positions. restraint fitting station or a Holden type of anchor. Dealer. Note Use only Standards Australia Use the child restraint anchors for and New Zealand approved child their designed purpose only.
  • Page 41 Secure the child in the restraint in accordance with the manufacturer’s instructions. If unsure about installing a child restraint anchor fitting, contact an approved restraint fitting station or a Holden Dealer.
  • Page 42: Storage

    Storage Storage Storage Coin storage compartments Storage compartments ....40 Instrument panel storage Loading information ...... 43 The coin storage compartment is located on the driver side of the dashboard. The instrument panel storage compartment is located in front of the shift lever.
  • Page 43 Storage Glove box storage Cup holders Warning To avoid scalding, never place hot drinks in the cup holders. Do not place uncovered containers of liquid in the cup holder while the vehicle is in motion. The glove box is located in the dashboard, in front of the passenger’s seat.
  • Page 44 Storage Sunglasses storage Under seat storage Load compartment Danger Do not stack objects higher than the front seats. Do not allow passengers to sit on the folded seatbacks while the vehicle is in motion. Serious injuries or death can result. For folding down rear seatbacks, see Rear seats on page 27.
  • Page 45 Storage Loading information • Place all heavy objects in the load compartment as far forward as possible. • Secure objects to prevent from sliding. Movement of heavy objects in the load compartment may change the handling of the vehicle. • Ensure the backrests are securely engaged.
  • Page 46: Instruments And Controls

    Instruments and controls Instruments and Controls Steering wheel controls controls Steering wheel adjustment Warning Controls ........44 Do not attempt to adjust the Setting the clock ......47 steering wheel while driving. Warning lights, gauges and indicators ....... 48 Trip computer ....... 55 The infotainment system can be operated using the controls on the steering wheel.
  • Page 47 Instruments and controls Horn Windscreen wiper/washer Intermittent wipe Windscreen wiper Continuous slow speed Continuous fast speed Note Wipers cycle once while the lever is pushed down slightly and released. Press j. The wipers/washers operate with the ignition in the ON position. Caution Do not operate the wipers on dry glass or when covered with snow...
  • Page 48 Instruments and controls Windscreen washer Rear window Warning wiper/washer Do not spray washer fluid on the windscreen in freezing weather. Pull to wash the windscreen. Washer fluid is sprayed and the • Push to the first stop for the wipers cycle for a short time. rear window wiper.
  • Page 49 Instruments and controls Clock Power outlet Caution Do not operate the wipers on dry glass or when covered with snow or ice, as this will damage the rubber and scratch the glass. Do not operate the windscreen washer for more than a few seconds, or when the washer fluid reservoir is empty.
  • Page 50 Instruments and controls Warning lights, Odometer Tachometer gauges and indicators Speedometer Shows distance travelled in Shows engine speed in thousands of kilometres. revolutions per minute (RPM). Trip odometers A and B measure distances travelled since the trip Shows vehicle speed in kilometres odometer was reset: per hour (km/h).
  • Page 51 Instruments and controls Fuel gauge Service display Control indicators The vehicle may have the following indicators. Indicators illuminate for a short time when the ignition is turned on to show that the light is working. Red: danger, important reminder Yellow: warning, information, fault Green: confirmation of activation Blue: confirmation of activation Shows the level of fuel in the fuel...
  • Page 52 Instruments and controls Information displays Centre display Graphic Information Display (GID) Instrument panel...
  • Page 53 If the vehicle reaches a specific signals on page 58. belt tensioner system repaired distance or speed and the seat immediately by a Holden Dealer. belt is unfastened, X or will flash and the chime will sound for 100 See Airbag system on page 32.
  • Page 54 1. Stop and switch off the engine. extinguish or illuminate while driving Note 2. Contact a Holden Dealer. and the park brake is released, there The vehicle’s brake system remains is a problem with the brakes:...
  • Page 55 Engine oil on page 93. • If the W warning light does not • If necessary, contact a Holden extinguish, switch the engine off Dealer. and contact a Holden Dealer. Caution Engine damage may result if you keep driving.
  • Page 56 • There is a problem with the ESC. See Catalytic converter on page 79. • The ESC is no longer operating. • Contact a Holden Dealer. See Electronic Stability Control (ESC) on page 82. If the flashes: • The ESC is helping the vehicle with road grip and stability.
  • Page 57 Instruments and controls Trip computer Driving distance Average speed for remaining fuel • Shows the average speed of the vehicle. Each time MODE is pressed, the trip • Estimates driving distance to an computer displays changes in the • To reset the average speed to empty fuel tank from the current following sequence: zero, press MODE for more than...
  • Page 58 Instruments and controls Driving time Ambient temperature • Shows the total drive time. • Shows the outside temperature. • To reset the driving time to zero, • A temperature range between press MODE for more than –30 and 70°C is displayed. 1 second.
  • Page 59: Lighting

    Lighting Lighting Exterior lighting High/low beam Lamp control Exterior lighting ......57 Interior lighting ......59 Lighting features ......60 To activate high beam: 1. Turn the headlamps on. OFF: Turns all lamps and lights off. 2. Push the lever forwards. 8 (Park lamps): Turns on the park The high beam indicator lamp lamps, number plate lamps and...
  • Page 60 Lighting Hazard warning flashers Turn and lane Warning change signals Always switch the headlamps to low beam when vehicles are approaching or when following another vehicle. To flash the high beam lamps: Press ¨ to turn the hazard warning flasher on or off, when the ignition is 1.
  • Page 61 Lighting Front fog lamps Reversing lamps Interior lighting The reversing lamps illuminate when the ignition is on and reverse gear is Instrument panel engaged. illumination 1. Turn the headlamps/ parklamps on. 2. Rotate the switch towards the front of the vehicle to the ON 1.
  • Page 62 Lighting Courtesy lamp Lighting features Warning Do not leave the courtesy lamp Battery saver on while driving in the dark. To prevent the battery from discharging, lamps are switched off automatically after the key is turned to the LOCK or ACC positions and the driver’s door is opened.
  • Page 63: Infotainment System

    Infotainment system Infotainment Introduction Caution system General information Do not place beverages close to the audio system. Do the following before driving: Do not strike or allow anything to • Read the infotainment system Introduction ........61 impact the audio system. section to become familiar with Radio ..........65 the functions.
  • Page 64 Infotainment system Unlock the audio system with the Overview security code before use. If CODE flashes on the screen: 1. Turn the ignition key to the ON or ACC positions. 2. Press (L) to turn the audio system on. CODE flashes. 3.
  • Page 65 Infotainment system A. CD select and pause button Next track: Steering wheel B. Preset buttons 1 to 6 • Press SEEK to go to the remote controls (radio, CD, USB, iPod ® next track. Power: C. CD slot • Press SEEK for more than •...
  • Page 66 Infotainment system Operation Audio adjustment Preset EQ selection 1. Press SOUND (F) repeatedly Bass/tone Power on/off until the current equaliser setting 1. Press SOUND (F) repeatedly • Press (L) to turn the audio is displayed. until BAS is displayed. system on. 2.
  • Page 67: Radio

    Infotainment system Radio Favourite memory preset Delete autostore page Store up to six favourite pages and 1. Press FAV/INFO (R) until a beep up to 48, AM or FM stations: is heard. AM-FM radio 1. Select a station. 2. Press FAV/INFO (R) until Radio mode selection AST.Page is displayed.
  • Page 68: Cd Player

    Infotainment system Radio reception Fixed mast antenna CD player Frequency interference, static, noise, distortion or loss of reception can General information occur during normal radio reception due to: Caution • Distance from the transmitter If a label is added to a CD, or •...
  • Page 69 Infotainment system Handling CDs Playing a CD Caution • Avoid leaving fingerprints on the When a CD is in the player, it will: CD when removing it. Avoid inserting any foreign • Remain in the player when the objects into the slot of the player. •...
  • Page 70 Infotainment system CD mode selection Next/previous folder All/directory mode (MP3/WMA) (MP3/WMA) To select CD mode, do one of the Repeat, intro-scan and random following: functions operate in the current 1. Press (N) or (M). folder when DIR is displayed: • Insert a CD into the CD slot (C).
  • Page 71: Auxiliary Devices

    Infotainment system Auxiliary devices USB/iPod ® port Selecting the USB/iPod ® as source General information General information 1. Connect a USB stick or iPod ® the USB/iPod port (P). • Devices such as USB sticks A USB stick or iPod can be ®...
  • Page 72: The Audio System

    Infotainment system iPod ® navigation Next/previous folder All/directory mode (MP3/WMA) 1. Connect an iPod to the USB/ 1. Press (N) or (M). Repeat, intro-scan and random ® iPod port (P). functions operate in the current Repeat folder when DIR is displayed: 2.
  • Page 73: Climate Control

    Climate control Climate control Air conditioning Controls system Air conditioning system....71 Danger Air vents........74 Maintenance ......... 75 Do not sleep with the air conditioning or heating system on. Serious harm or death may occur due to a drop in oxygen level and/or body temperature.
  • Page 74 • Have any faults repaired by a • V: To the windscreen and side so is not recommended for long Holden Dealer. window demist vents, with a periods of time. small amount of the air to the • Do not use recirculation if outer dashboard vents.
  • Page 75 Climate control 5. Rotate the mode switch to Maximum cooling Windscreen demister 6. Adjust the angle of the air vents. 7. Rotate the fan speed switch x to 4. 1. Slide the recirculation switch Use maximum cooling for to 5. quick cooling of the passenger compartment.
  • Page 76 Climate control Rear window demister Air vents Caution Do not use sharp objects or Adjustable air vents abrasive window cleaners on the rear window. Do not scratch or damage the wires when cleaning. 1. Turn the ignition key to the ON position.
  • Page 77 Climate control Pollen/dust filter Maintenance The passenger compartment air filter filters contaminants such as pollen Air intake and dust from entering the vehicle. Caution Have the passenger compartment air filter replaced if driving frequently on dusty and unpaved roads or polluted areas. 1.
  • Page 78: Driving And Operating

    Driving and operating Driving and Driving information Starting and operating operating Before entering the vehicle New vehicle running-in Check that windows, mirrors and Driving information......76 Use the following precautions to lamps are clean. improve performance: Starting and operating ....76 Visually check tyre inflation.
  • Page 79 Driving and operating LOCK: When the key is in this Brakes Ignition positions position, some electrical accessories • Do not let the vehicle run down and the engine are off. hills, or coast with the engine off, The key can only be inserted and as the power assistance does removed from this position.
  • Page 80 Driving and operating ON: When the key is in this position, Starting the engine Parking the engine is ready to start and all 1. Apply the park brake firmly. 1. Apply the park brake. electrical systems are active. 2. Push the clutch pedal to the floor. 2.
  • Page 81 Warning other problems occur, contact a Be careful where you park or Catalytic converter Holden Dealer as soon as possible. drive. As with any vehicle, do The catalytic converter reduces the In an emergency, drive for a short not park or operate the vehicle...
  • Page 82 Considerably more force is needed • Do not over rev the engine when for this. The braking distance is shifting to a lower gear. extended. Contact a Holden Dealer. Warning • When shifting from one gear to another, push the clutch pedal to After driving through deep water, the floor.
  • Page 83 If there is a malfunction with the retained, even in the event of ABS, the vehicle’s brake system panic braking. remains operational, but without ABS assistance. Have a Holden Warning Dealer check the system as soon Do not let this special safety as possible.
  • Page 84 Driving and operating Park brake Ride control systems Warning Electronic Stability Do not let this special safety feature tempt you into taking Control (ESC) risks when driving. Traffic safety The ESC: can only be achieved by adopting • Improves driving stability in any a responsible driving style.
  • Page 85 Driving and operating Deactivation Object detection Warning systems The driver is always responsible for taking care and attention while Park Assist (PA) manoeuvring the vehicle. The PA is only an aid and is neither The vehicle may have Park intended to, nor able to take over Assist (PA).
  • Page 86 • A warning tone sounds. damaged. obstacles near the rear bumper, • As the distance decreases, contact a Holden Dealer. • The PA may not operate correctly the repetition rate of the tone when the vehicle is driven over •...
  • Page 87 Driving and operating Fuel Take the vehicle to a Holden Warning Dealer if you think the vehicle Danger needs inspecting for any of the FUEL above reasons. Fuel is extremely flammable and EXHAUST WARNING – Do not sit (or leave children or highly explosive.
  • Page 88 Driving and operating Warranty to the extent that Caution Caution Holden considers that the fuel affects the specifications and FUEL ADDITIVES USE OF FUEL quality of your vehicle. CONTAINING ETHANOL Various additives are used in the The use of any fuel, other than...
  • Page 89 Driving and operating 1. Stop the engine. Refuelling Always fill the fuel tank at the intermediate or fast fill rate. Do not add any more fuel after the fuel filler first clicks off or fuel blows back. This allows room for the fuel to expand inside the tank.
  • Page 90: Vehicle Care

    Vehicle care recycle the vapours through the Vehicle care General information normal combustion process. Where specified, use only Holden 2. Crankcase emission control genuine parts and accessories. system. This system is designed General information ...... 88 to prevent blow-by gases from Vehicle checks ......
  • Page 91 Do not apply the park brake. schedule, in the Service/Warranty • Check the coolant level. Booklet. It is recommended that servicing be carried out by an authorised Holden Dealer who will maintain the vehicle’s emission control system as per the Service/Warranty Booklet.
  • Page 92: Vehicle Checks

    Vehicle care Vehicle checks Bonnet Opening Doing your own service work Warning Do not touch engine compartment components when the ignition is on due to extremely high voltages. 2. Push up on the safety catch. Note The cooling fan may still operate when the ignition is off.
  • Page 93 Vehicle care Closing Warning To avoid injury and/or damage to the vehicle, check each time, before the bonnet is closed, that the contact area is unobstructed. 1. Place the support rod into the bonnet holder. 2. Lower the bonnet and allow it to drop into the catch.
  • Page 94 Vehicle care 1. Engine coolant reservoir, Engine compartment overview see page 95 2. Brake fluid reservoir, see page 97 3. Engine oil reservoir, see page 93 4. Battery, see page 98 5. Fuse box, see page 107 6. Engine air filter, see page 94 7.
  • Page 95 Vehicle care Engine oil Adding engine oil See Capacities on page 135. Checking oil level • Check the engine oil level before a long journey. • The engine must be at operating temperature and the ignition turned off for at least 5 minutes. 1.
  • Page 96 New and water or hand cleaner. Vehicle Voluntary Warranty, to the Be careful when draining the extent that Holden considers the engine oil as it may be hot. non-recommended fluid to have Filter cover removal affected the specifications or quality 1.
  • Page 97 4. Replace the cap securely. Do not remove the radiator cap If the coolant requires regular if the engine and radiator are still topping up, contact a Holden hot. Scalding fluid and steam If the cooling system is cold, the Dealer.
  • Page 98 MIN and MAX 3. Add the required amount of marks. power steering fluid. Use only Holden specified power Do not overfill the reservoir. steering fluid. See Recommended If the power steering fluid requires fluids, lubricants and parts on regular topping up, contact a page 130.
  • Page 99 Use the correct amount of remove the reservoir cap, as brake washer fluid additive. Refer to fluid exposed to the atmosphere will a Holden Dealer. quickly absorb moisture. Do not use ordinary soap or Adding brake fluid detergent as they froth up and damage the wiper rubbers.
  • Page 100 For battery location, see Engine 4. Top up with the recommended compartment overview on page 92. Warning brake fluid. For replacement, refer to a Holden Batteries emit an explosive gas Dealer or authorised repairer. mixture which may be ignited. Warning...
  • Page 101: Bulb Replacement

    1. Lift the wiper arm. methylated spirits. page 121. 2. Press the release lever and Bulbs to be changed by detach the wiper blade. a Holden Dealer For wiper blade cleaning, see • Fog lamps Windows and windscreen wiper blades on page 126.
  • Page 102 3. Press the spring clip to in a dry environment or the lamp disengage. is on. If water does collect in the lamp contact a Holden Dealer. 2. Remove the protective cover. 4. Remove the bulb from the reflector housing.
  • Page 103 8. Attach the plug connector onto the bulb. 9. Check lamp operation. Headlamp aiming 3. Remove the side lamp, bulb If the headlamps require adjustment, holder from the reflector. contact a Holden Dealer. 2. Remove the protective cover. 4. Remove the bulb from the socket.
  • Page 104 Vehicle care 5. Insert a new bulb. Front turn signal lamps 6. Place the side lamp, bulb holder into the reflector. 7. Replace the headlamp protective cover into position and close. 8. Attach the plug connector onto the bulb. 9. Check lamp operation. 2.
  • Page 105 Vehicle care Tail lamps, turn signals, stop lamps and reverse lamps • Tail lamp/stop lamp (1) 3. Rotate the bulb holder anticlockwise. • Turn signal lamp (2) • Reverse lamp (3) 1. Unscrew both screws. 2. Remove the tail lamp assembly. Note Make sure the cable duct remains in position.
  • Page 106 Vehicle care Side turn signal lamps Centre High-Mounted 1. Push the lamp holder towards Stop lamp (CHMSL) the rear of the vehicle and remove. 2. Rotate the bulb holder anticlockwise. 3. Pull the bulb out of the bulb holder. 4. Insert a new bulb. 5.
  • Page 107 Vehicle care 7. Place the bulb into the bulb Number plate lamp Interior lamps holder. Courtesy lamps 8. Replace the reflector assembly 1. Using a flat-blade screwdriver, and the two screws. prise the lamp assembly 9. Reconnect the wiring harness. outwards, from the side opposite 10.
  • Page 108: Electrical System

    Vehicle care Load compartment lamp Electrical system Fuses Warning Turn off the ignition (LOCK position) and any electrical equipment before changing a fuse. • Replace blown fuses promptly. 2. Remove the bulb. • A blown fuse can be recognised 1. Using a flat-blade screwdriver, 3.
  • Page 109 To maintain your own safety and the cover. that of the vehicle, have any work involving the electrical system or the replacement of high current fuses or relays carried out by a Holden Dealer.
  • Page 110 Vehicle care 1. Fuel pump Engine compartment fuse box 2. Parking lamp relay 3. Fan low relay 4. Fan high 5. Air conditioning 6. Fan high relay 7. Air conditioning relay 8. ABS2 9. Park LH 10. Park RH 11. Front fog 12.
  • Page 111 Vehicle care 23. Ignition2/starter Instrument panel Instrument panel fuse box 24. Ignition1/accessory fuse box 25. Hazard lamps 26. Horn 27. Headlamp low relay 28. Horn relay 29. Engine main relay 30. Ignition 31. EMS1 32. EMS2 33. Instrument panel battery 1.
  • Page 112: Vehicle Tools

    Vehicle care 12. Instrument panel Vehicle tools Spare tyre 13. Blower 14. Airbag Tools 15. Theft deterrent/data link Tyre repair kit connector The vehicle may have an emergency 16. - tyre sealant and compressor kit in 17. Rear power windows place of a spare tyre.
  • Page 113: Wheels And Tyres

    Contact a as reducing fuel consumption and • Always inflate the spare tyre Holden Dealer, if in doubt. increasing the life of the tyres. to the pressure specified for maximum load. •...
  • Page 114 Vehicle care • If there is more wear on the front Tread depth Buying new tyres tyres than on the rear tyres, Check tread depth at regular Refer to the tyre placard on the swap the front and rear wheels. intervals.
  • Page 115 Vehicle care Wheel covers Tyre chains Warning Use wheel covers and tyres that are factory approved for the vehicle Tyre chains may only be used and which comply with all of the at speeds up to 50 km/h. Tyre relevant wheel and tyre combination chains should only be used for requirements.
  • Page 116 1. Apply the park brake. tyre’s side wall, near the rim. 2. Place the shift lever into either Take the vehicle to a Holden Dealer first or reverse gear. to have the tyre repaired or replaced as soon as possible.
  • Page 117 Vehicle care 7. Screw the compressor air hose 14. Press the switch on the to the connection on the sealant compressor to I. bottle. The tyre fills with sealant. 8. Connect the compressor plug to The compressor pressure gauge the accessory socket. briefly indicates up to 6 bar while 9.
  • Page 118 Unsecured loads 18. Move the vehicle one tyre Contact a Holden Dealer. increase the risk of injury during rotation. heavy braking, sudden avoidance 20. Drain excess tyre pressure with 19.
  • Page 119 32. Dispose of the used tyre sealant Do not jack a vehicle with a trailer canister at a Holden Dealer or in attached. Remove the trailer first. accordance with local and State Only jack the vehicle on hard, codes and practices.
  • Page 120 Vehicle care 7. Chock the wheel diagonally Removing the spare tyre Do not get under a vehicle that is opposite the flat tyre with a supported by a jack. No person suitable solid object. should place any portion of their body under a vehicle that is Note Do not change more than one...
  • Page 121 Vehicle care 12. Place the wheel wrench over the 11. Remove the spare wheel from 13. Position the jack beneath the wheel nuts and loosen by half the load compartment: jack location closest to the wheel a turn, but do not remove the being changed.
  • Page 122 Vehicle care 18. Unscrew the wheel nuts and place in a clean, dry place. Warning 19. Exchange the wheel on the Failure to position the jack as vehicle with the spare wheel. described could cause the 20. Clean the wheel nuts and vehicle to slip off the jack.
  • Page 123: Jump Starting

    26. Have the flat tyre renewed or to reach the catalytic converter If you are still unsure about repaired. and ignite, the converter could jump starting, Holden strongly overheat or be destroyed by recommends for your safety and Warning backfire. Therefore, if the battery...
  • Page 124 Vehicle care 1. Position the two vehicles so that • Do not use open flames or • If a permanently connected they are not touching. sparks near the battery. hands free telephone kit is fitted 2. Apply the park brakes. to the vehicle, remove the fuse •...
  • Page 125: Towing

    Vehicle care 7. Connect the other end of the RED 12. Allow both engines to idle for Towing lead to the positive terminal of the approximately 3 minutes with the discharged battery (2). leads connected. Towing the vehicle 8. Connect the BLACK lead to the 13.
  • Page 126 Vehicle care Towing another vehicle Caution The rear towing eye is located under the rear bumper. To prevent damage, do not use the front lashing points for towing The towing eye must only be used the vehicle. for towing and not for recovering a vehicle.
  • Page 127: Appearance Care

    Have the door hinges of all doors which can cause paint damage. greased by a Holden Dealer. Failure to do so may result in permanent damage, particularly in Caution hot weather conditions.
  • Page 128 Do not use hard objects to remove clean glass. spots of tar. Use tar removal spray Air intakes • Refer to a Holden Dealer for on painted surfaces. Clear debris from the air intakes, windscreen washer additive. between the bonnet and windscreen •...
  • Page 129 • Remove oil and grease with soap Have more extensive damage or Many cleaning products are and water or detergent. rust areas repaired by your Holden toxic, flammable or may damage Dealer. the interior. When cleaning the • Do not use petrol to clean tyres.
  • Page 130 Vehicle care Plastic and rubber parts Interior and upholstery Plastic and rubber parts can be Only clean the vehicle interior, cleaned with the same cleaner as including the instrument panel fascia used to clean the body. Use interior and panelling, with a dry cloth or cleaner if necessary.
  • Page 131: Service And Maintenance

    Service and maintenance Service and General information maintenance Service information In order to ensure economical and safe vehicle operation and to General information ....129 maintain the value of your vehicle, Recommended fluids, it is of vital importance that all lubricants and parts ....
  • Page 132 Service and maintenance Recommended fluids, lubricants and parts Engine type 1.2L petrol Engine oil specification 5W/30 (dexos™ 1); Coolant specification 50% clean fresh water and 50% Dexcool anti-freeze coolant, ® conforming to specification number GM6277M Manual transmission fluid SAE 75W-85W; API GL4 Brake fluid DOT 4 Hydraulic brake fluid, conforming to specification number GMW3356 Power steering fluid...
  • Page 133: Technical Data

    Technical data Vehicle identification Identification plate Technical data Vehicle identification Vehicle identification ....131 number (VIN) Vehicle data ........ 133 An identification label is located on the front passenger’s door frame. The label shows: 1 = Approval number Each vehicle has its own, individual 2 = Manufacturer International Standards Organisation Vehicle Identification Number...
  • Page 134 Technical data Engine serial number The engine serial number is located in the front part of the engine compartment.
  • Page 135 1.2 L DOHC Petrol Number of cylinders Engine identifier code B12D1 Engine 1206 cc Engine power Please refer to holden.com.au Engine torque Please refer to holden.com.au Octane rating (RON) Unleaded regular 91 or higher Ethanol compatibility Vehicle weight Overloading is a safety hazard and could also shorten the life of the vehicle.
  • Page 136 Technical data Axle loads Maximum front and rear axle loads Do not exceed the maximum axle loads, including the weight of any options or accessories fitted to the vehicle. Weigh at a weighbridge if unsure. Front axle load (kg) Rear axle load (kg) 5 door hatch Dimensions (mm) Width excl.
  • Page 137 Technical data Capacities Engine type 1.2 L DOHC Petrol Refill engine oil including filter (approximately) 3.8 L Coolant (approximately) 4.7 L Fuel tank 35.0 L Tyre pressure Tyre size Recommended pressure Normal load Maximum load Eco normal load Spare Front Rear Front Rear...
  • Page 138: Customer Information

    However, if you prefer to write the Therefore, we suggest you discuss address is: any concern with one of the Holden Dealer management people. The Manager Holden Customer Assistance Centre If you have not received satisfaction...
  • Page 139 Servicing dealer’s name and provisions for New Zealand. address Applicable details for New Zealand • Vehicle model are set out in the Holden Warranty • Vehicle identification number and Owner Assistance Information (I.S.O.V.I.N.), refer to the inside booklet enclosed in the New Zealand front cover of the Service/ glove box wallet.
  • Page 140: Index

    Index Child restraints......36 ABS ..........81 Battery ......... 98 Anchor points ......38 Accessories Disconnection......99 Types of restraint...... 36 Battery saver ......60 Jump starting......121 Child safety locks......17 Power outlet ......47 Specification ......130 Child safety switch ....... 22 Active safety systems Replacement ......
  • Page 141 Index Emergencies Dipping headlamps ....9, 57 Ethanol ........ 86, 133 Bulb replacement ..... 99 Dipstick Exhaust fumes, warning ....85 Changing a flat tyre ....117 Engine oil ......... 93 Exterior lighting ......57 Customer assistance....136 Display, information ..... 50 Exterior mirrors ......
  • Page 142 Index Fuel continued Head restraints ......5, 24 Instrument panel ......50 Low fuel warning ...... 54 Heated front seats ....... 27 Interior lamps ....... 59 Octane rating....86, 133 Heated mirrors ....... 21, 74 Interior mirrors ......21 Precautions ......85 Heating and ventilation ....
  • Page 143 Index Lighting continued Mirrors Park Assist (PA) ......83 High/low beam ..... 9, 57 Exterior ........20 Park brake ........82 Interior lamps ......59 Heated........ 21, 74 Park brake warning ....52 Lamp control ......57 Interior ........21 Parking ........
  • Page 144 Index Restraints Specifications ....130, 133 Tachometer ........48 Child restraints ......36 Axle loads....... 134 Tailgate ........18 Infant restraints ......37 Capacities ......135 Tank capacity ......135 Ride control systems ....82 Dimensions ......134 Technical data......131 Running-in a new vehicle ....
  • Page 145 Index USB port ........69 Vehicle care ......... 88 Vehicle Identification Number (VIN) .......... 131 Vehicle loading ......133 Vehicle storage ......89 Ventilation system......71 Vents..........74 Warning lights ......48 Washer fluid ......... 97 Washing the vehicle ....125 Wheels and tyres ......111 Windows ........

This manual is also suitable for:

Barina spark 2012

Table of Contents
