Chapter 1. Product Overview

With the excellent design of circuit and high quality production, we guarantee ADSL2+ MODEM a
high performance, very good stability and easy to use.
TD-8610/TD-8610B is a complete plug-and-play solution. With standard Ethernet interface, it can
be directly connected to any 10M/100M Ethernet devices, support Auto-MDIX.
TD-8610/TD-8610B not only use html (web mode through Ethernet port) to configure the MODEM
but also use external utility software too. You can download it from our website
(http://www.tp-link.com).

1.1 Product main specification

High speed and asymmetry data transmit mode, adapt to wide-band internet access
Point to point connection, provide safe and exclusive bandwidth
Support All ADSL industrial standards
Advanced DMT modulation and demodulation
Firmware upgradeable
Compatible with all mainstream DSLAM (CO)
Real-time Configuration and device monitoring
Quick response semi-conductive surge protect circuit, provides reliable ESD and
surge-protect function

1.2 Supporting protocol

- G.992.1 (G.dmt) - Annex A/B
- G.992.2 (G.lite) - Annex A/B
- ANSI T1.413
- G.992.3 (ADSL2) - Annex A/B compliant
- G.992.5 (ADSL2+) Annex A/B compliant
- ADSL dual latency (fast path and interleaved path)
- I.432 ATM physical layer compliant
-Supports RFC2516 (PPPoE) *
- Supports RFC1483 (EoA) ( Bridged)
Note:
"*"Need third-party software.

1.3 Transmit data-rate

Max download data-rate: 24Mbps
TD-8610/8610B
1
External ADSL MODEM
