Summary of Contents for TP-Link TD-8610
- Page 2 Specifications are subject to change without notice. is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK Technologies Co., Ltd.
-
Page 3: Table Of Contents
Package contents......................1 Chapter 1: Product Overview .................... 2 1.1 Product main specification ................... 2 1.2 Supporting protocol....................2 1.3 Transmit data-rate....................3 1.4 ATM property......................3 1.5 System support ....................3 1.6 Working environment ................... 3 1.7 Electric parameter....................3 Chapter 2: Hardware Installation Guide ................ -
Page 4: Package Contents
Other Helpful Information One RJ45 cable Two RJ11 cable One ADSL splitter Note: If any of the listed cable are damaged or missing, please contact the retailer from whom you purchased the TD-8610 External ADSL MODEM for assistance. - 1 -... -
Page 5: Chapter 1: Product Overview
TD-8610 is a complete plug-and-play solution. With standard Ethernet interface, it can be directly connected to any 10M/100M Ethernet devices,support Auto-MDIX. TD-8610 not only use html (web mode through Ethernet port) to configure the MODEM but also use external utility software，too. You can download it from our website (http://www.tp-link.com). -
Page 6: Transmit Data-Rate
TD-8610 External ADSL MODEM User Guide -Supports RFC2516 (PPPoE) * - Supports RFC1483 (EoA)( Bridged) NOTE. “*”Need third-party software. 1.3 Transmit data-rate Max download data-rate: 24Mbps Max upload data-rate: 1Mbps Max line length: 6Km 1.4 ATM property AAL0, AAL5, OAM, RM, and raw cell types supported... -
Page 7: Chapter 2: Hardware Installation Guide
TD-8610 External ADSL MODEM User Guide Chapter 2: Hardware Installation Guide 2.1 System requirement Confirm your computer has been installed with networking interface card (NIC) before connecting ADSL MODEM to your computer, with operating system supporting the TCP/IP protocol. 2.2 LED explanation... -
Page 8: Hardware Installation Procedures（Figure2-1
External ADSL MODEM User Guide 2.4 Hardware installation procedures（figure2-1） First Step: Connecting the MODEM of Splitter with the LINE port of the TD-8610 ADSL MODEM by telephone line. While you need to use a telephone, please attach telephone line into the phone of Splitter. -
Page 9: Chapter 3: How To Use
TD-8610 External ADSL MODEM User Guide Chapter 3: How to use 3.1 Computer Configuration Connect the cable according to Chapter 2, turn on the power. Change the IP address of your PC （Figure 3-1） : Open TCP/IP Properties of the LAN card in your PC, enter the IP address as 192.168.1.* (* is any value between 2 to... -
Page 10: Login
TD-8610 External ADSL MODEM User Guide The users of Windows 2000/NT/XP can do the following: Right-press Network Neighbor -> Choose Properties -> Right-press Local Connection -> Choose Properties -> Double-press Internet Protocol (TCP/IP). NOTE: The words in fact maybe are different with this guide. -
Page 11: Setup
TD-8610 External ADSL MODEM User Guide go to"Management","Password"changing them. (Figure 3-3) (Figure 3-3) 3.3 Setup Choose ATM PVCs Config (See Figure 3-4) Enter VPI/VCI value which is provided by your ADSL service provider, press Save to finish the configuration.You can press Next to add VPI/VCI value. -
Page 12: Software Dial
External ADSL MODEM User Guide 3.4 Software Dial TD-8610 work in bridged(RFC 1483 Bridged) mode connecting Internet.you need to install dial software on your PC.There are some software working on WINDOWS in market,example for EnterNet3000 、 RASPPPoE 、 WinPeET.How to use the software?Please refer to everyone’s operation instructions. -
Page 13: Appendix A: Default Config
TD-8610 External ADSL MODEM User Guide Appendix A: Default Config USER NAME admin PASSWORD admin IP ADDRESS 192.168.1.1 VPI/VCI 0/32,1/33,0/35,0/100,0/200,8/35,8/81 - 10 -... -
Page 14: Appendix B: Contact Information
TD-8610 External ADSL MODEM User Guide Appendix B: Contact Information For help with the installation or operation of the TP-LINK TD-8610 External ADSL MODEM, please contact us. E-mail: support@tp-link.com Website: http://www.tp-link.com - 11 -...
