Table Of Contents - Promis COLpro222DX-OZview User Manual

SEC. 1 PREFACE
SEC. 2 DESCRIPTION OF COLpro222DX-OZview
SEC. 3 GENERAL WARNINGS AND PRECAUTIONS
SEC. 4 INSTALLATION
SEC. 5 TECHNICAL SPECIFICATIONS
SEC. 6 LIST OF REPLACEMENT PARTS
SEC. 7 SYSTEM MAINTENANCE
SEC. 8 WARRANTY TERMS AND CONDITIONS (WORLD-WIDE PURCHASE)
SEC. 9 LABELLING FORMAT FOR TRACEABILITY
SEC. 10 ACCESSORIES CHECK LIST
Sec 1 PREFACE
This manual contains information, which may not be copied or duplicated, in full or in part, without the explicit
approval of Promis Medical (Australia) Pty Ltd. We reserve the right to make any change in the operator manual,
which may affect instructions in this manual, without giving prior notice. The user of this equipment shall be solely
responsible for any kind of damage, malfunction to the unit or user as a result of improper use or any kind of repair or
alteration done by anyone other than us or a technician duly authorized by the manufacturer to do so.
This operator manual provides directions for using COLpro222DX-OZview Digital Video Colposcope. Read all
instructions, cautions and warnings prior to use. Failure to follow instructions or to heed warnings could lead to
patient or operator injury. COLpro222DX-OZview version is our newest, most advanced and recently upgraded model
of our COLpro222DX series. Many additional facilities have been added according to the feedback received from
various users and stakeholders of our widely acclaimed COLpro222DX series. The Delivered Product may vary
slightly in color or shape or specifications due to continuous product development.
Sec 2 DESCRIPTION OF COLpro222DX-OZview
COLpro222DX-OZview is an aid to colposcopy. Colposcopy is a gynecological procedure in which the doctor, using
colposcope looks at the cervix. It comprises of a camera head mounted on a vertical stand. This instrument magnifies
the cervix, vagina and external genital area when the doctor points out the camera head at the vagina where a
speculum has been placed.
It incorporates latest digital signal processing technology to provide high-resolution images for effective colposcopy. It
is a latest generation video colposcope incorporating advanced CCD imaging & illumination technology, aerodynamic
design, compact size and offers powerful features like automatic as well as manual focus, electronic multi-grade
green filter and magnification indicator among many others. The extra innovative features added are e-flip & mirror
image, facility to vary the light intensity, facility to choose various color contrasts to make colposcopy more effective.
COLpro222DX-OZview is designed to detect the presence of pre-cancerous tissue or cancerous tissue or any
abnormality in cervix area. So far colposcopy plays a significant role in evaluation and treatment of cervical infection
like cervical cancer, erosion and inflammation. This manual has been prepared to provide authorized personnel with
information on the assembly, functions and routine performance related to the COLpro222DX-OZview. It is provided
together with the device and should be available near the device all the time. The user must read and be familiar with
the contents of this manual before using the video colposcope. Operation must be performed in accordance with
stipulated safety standard thus to ensure patient and operator's safety.
Sec 3 GENERAL WARNINGS & PRECAUTIONS
Intended Use: For examination of the tissues of the vagina, cervix and external genitalia by means of magnification
to investigate abnormal cervical cytology or suspicious lesions of the lower female genital tract. Also used for
corresponding biopsy and treatment, when indicated.
Environmental Requirements:
•
Area of camera & Floor stand pole: 0. 4m
•
0
Ambient temperature: 5 C - 40
•
Humidity: < 80%
•
Atmospheric pressure: 70 kPa-106kPa
•
AC 100~240 V, 50/60 Hz
•
Well-grounded
Operator's Manual Ver: PMA-VYR-0218NA-GIMA
