Berker 8536 51 00 Operating Instructions

z
IP55
Operation instructions
KNX-RF controller 220°
surface-mounted + 90°/- 30°
KNX-RF controller 220°/switch
actuator 1 gang surface-mounted
Order no.
8536 51 00, 8536 51 99
+/-80°
Description
IP55
Vertical adjustment
Wall fixing plate
+/-80°
Detection zone
m 16
m 4
m 2,5 IP 5 5
m 0,5 m 8 m 16
Optimal installation height is 2.5m.
The detection zone shall remain free of obstacle.
Installation
2,5 m
1 01
Adjustments
Delay Brightness
(lighting time)
+ 90°/- 30°
Adjustment potentiometers
Directional detection head LED A
Shutters
1
Angle fixing support 8590 02 00
Caution :
- This device must be installed only by
a qualified electrician according to the
installation standards in force in the
country.
Product Description and working
principles
This detector allows remotely control of one
or more receivers for a given time when a
movement is detected in its detection zone.
This product can be used in two types of
configuration: one detector controls one/seve-
ral receiver(s); several transmitters control the
receiver(s).
Operation
The receiver(s) is(are) under control as soon
as the brightness level as set by potentiometer
is considered too low and a movement is
2
detected.
Upon detection, the time delay is restarted.
Sensitivity
If LED A flashes quickly during configuration,
level (change
the position of potentiometer
(of range
tible with the selected function.
If LED B flashes quickly or nothing occurs
when starting configuration, check that the
batteries are correctly installed and replace
them if necessary. Product factory reset is
recommended before any new configuration.
Factory reset
Maintain button down until LED cfg flic-
J
kers > 10 s, then release. cfg LED turns OFF
to signal reset to factory settings end.
This operation removes the entire product
configuration in any configuration mode.
After power switch-on or reset to factory set-
LED B
tings, wait for 15 s before to do a new configu-
ration.
Action Adjustments
2
Use Auto (factory) Auto Settings
settings to set Put the Lux potentiometer on
automatic lighting "auto test".
turn-on for
The settings are predefined :
ech40%
a given time.
Lux =
Only available when
(operating at night only)
a detector's time
time = 3 min,
delay is set.
sensitivity = max
Turn automatic Installer settings
lighting on for
a given time.
Only available when
a detector's time
delay is set.
Adjust sensitivity. Allows setting the range
to avoid disturbance.
6LE003134B
02 2
Installing batteries
Configuration (button )
J
These detectors can be configured in 3 different
ways :
• quicklink& : configuration without tool, directly
on the device via button and LED (see confi-
J
guration instructions quicklink& ).
• tebis TX: configuration using connection device
from Hager
1 is not compa-
• ETS3/ETS4 via KNX-RF/TP gateway: database
and description of application software available
from the manufacturer.
Configuration by ETS
Press button for addressing by means of radio/
J
KNX gateway
Product factory reset is required to change
O
the configuration mode.
Potentiometer
,
Button
J
LED cfg
Button J
cfg
Test and validation of detection
zone
Set potentiometer 2 to mode " auto test " .
The test mode is available only once
O
the product has been configured.
The Test mode is available for 3 minutes time
and does not take brightness level into
version à pile
account.
Each detected movement turns LED A on for
2 seconds.
The associated receiver is controlled.
After 3 minutes without detection, the product
is set back to auto mode.
Limitation of detection zone :
You can limit the detection zone using the
shutters supplied or by inclining the head.
Mounting
Projection or ceiling mount :
- Fix the wall plate using the supplied screws.
- Clip the detector onto the wall plate
- Tighten the screws to close.
For angle mounting, the wall fixing plate is
fitted between the accessory and
the detector.
Precautions for installation
For optimum detection conditions, please fol-
low these recommendations :
- Keep the detector protected from solar radia-
tion and bad weather, as it is sensitive to
these conditions.
- Maintain 1m distance between the light
source and the detector and keep the detec-
tor out of the light source.
Correct Disposal of This product
(Waste Electrical & Electronic
Equipment).
(Applicable in the European Union and other European
countries with separate collection systems).
This marking shown on the product or its literature
indicates that it hould not be disposed with other
household wasted at the end of its working life. To
prevent possible harm to the environment or human
health from uncontrolled waste disposal, please
separate this from other types of wastes and recycle it
responsibly to promote the sustainable reuse of
material resources.
Household users should contact either the retailer
where they purchased this product, or their local
government office, for details of where and how they
can take this item for environmentally safe recycling.
Business users should contact their supplier and
check the terms and conditions of the purchase
contract. This product should not be mixed with other
commercial wastes of disposal.
å
Usable throughout Europe and in Switzerland
Hager Controls hereby declares that the 8536 51 00, 8536
51 99 device complies with the essential requirements and
other relevant provisions of Directive 2014/53/EU.
The CE declaration is available on the:
www.hagergroup.com
6LE003134B
6LE003134C - 09/2021
