- Page 1 - EN - Safety is our concern! Art.Nr. 175 1296 EN-2/08.03 LEMKEN GmbH & Co. KG Weseler Straße 5, D-46519 Alpen / Postfach 11 60, D-46515 Alpen Telefon (0 28 02) 81-0, Telefax (0 28 02) 81-220 eMail: lemken@lemken.com, Internet: http://www.lemken.com...
- Page 3 Only use genuine Lemken spare-parts. Spurious parts negatively influence the function of the implement, show a shorter lifetime and increase in nearly all cases additional maintenance. We trust that you will understand that LEMKEN unable to guarantee poor operation and damage caused by using spurious parts!
-
Page 4: Table Of Contents
• Under "defined use" the manufacturer's prescribed operation-, maintenance- and repair conditions are to be adhered to! • The SMARAGD 7 may only be operated, maintained and repaired by such persons who have been made acquainted with it and who have been advised about the dangers! •... - Page 5 4 ATTACHING AND DETACHING THE IMPLEMENT........10 4.1 Attaching to the tractor................10 4.2 Detaching from the tractor ..............10 5 THREE-POINT-LINKAGE ................11 5.1 General Instructions ................11 5.2 Vertical Adjustment of Drawbar ............. 11 5.3 Change of the Drawbar Position ............11 6 SHARE POSITION ..................
-
Page 6: Safety Instructions
1 SAFETY INSTRUCTIONS General Safety Instructions • Before using the machine, always check both it and the tractor for roadworthiness and operational safety! • As well as the notes in these instructions the operator is advised to comply with the generally applicable safety at work regulations and those relating to use of the public highway! •... - Page 7 • On all pivoting parts actuated by power assistance (e.g. hydraulics) exists danger of injury by bruising and crushing! • Before leaving the tractor lower the machine to the ground. Apply the parking brake, stop the engine and remove the ignition key! •...
-
Page 8: Warning Stickers
2 WARNING STICKERS 2.1 General Instructions The LEMKEN Smaragd is equipped with all features to ensure safe operation. Where potential danger areas of the implement can not be fully safeguarded, warning stickers are fitted which draw attention to these. Damaged, lost or unreadable warning stickers must be replaced immediately. -
Page 9: Position Of Warning Stickers
WARNING: Pinch Point! 390 0506 WARNING: Keep well clear of the working and swinging area of the implement! 390 0510 2.3 Position of warning stickers... -
Page 10: Reparation Of Tractor
3 REPARATION OF TRACTOR 3.1 Tyres Ensure that all tyres- especially the rear ones - are at identical pressure. 3.2 Lift rods Adjust lift rods to equal length. Where there are alternative positions for the lift rods on the lower links, use the rearmost position, in order to unload the tractor hydraulics. - Page 11 How to calculate the minimum front ballast and the increasing of the rear axle load, is described in detail as follows: = Weigth of front ballast (front implement) = Front axle load of the tractor without mounted implement = Tractor dead weight = Rear axle load of the tractor without mounted implement = Weight of the implement combination Calculation of the minimum front ballast G...
-
Page 12: Attaching And Detaching The Implement
4 ATTACHING AND DETACHING THE IMPLEMENT 4.1 Attaching to the tractor Set tractor hydraulics to "Position control". − Attach tractor lower links to the drawbar − (1) and secure. Fit top link so that it raises towards the − implement when in working position. Secure top link (3) by means of spring clip −... -
Page 13: Three-Point-Linkage
5 THREE-POINT-LINKAGE 5.1 General Instructions The mounting categories of the tractor and the implement must be compatible or must be made compatible. If there is no correspondence, the three-point-linkage of the tractor must be adapted or the drawbar (1) and the top link pin (3) of the disc cultivator must be replaced by a corresponding version. -
Page 14: Share Position
6 SHARE POSITION The share position of SMARAGD and SMARAGD Ü can be altered. A flat share position ensures an even seedbed depth (point (5) and wings (6) work nearly at the same depth) and reduces the traction requirement; steep share position ensures a good penetration, even in hard... -
Page 15: Depth Adjustment Of The Tines
7 DEPTH ADJUSTMENT OF THE TINES The tines respectively shares should be set at a working depth of 8 - 12 cm; with greater soil unevenness or deep wheel marks a deeper cultivation depth may be required. Adjust working depth of the tines after raising the implement some cm by means of the adjusting device (10) as follows: Placing the lower pin (2) in a deeper hole =... -
Page 16: Depth Adjustment Of The Discs
8 DEPTH ADJUSTMENT OF THE DISCS The hollow discs (18) should be set at approximate half working depth of the tines (19). They should mix and for level the ridges and grooves left by the rear tines. When working too deep, new ridges and grooves will be built, and when working too shallow, the grooves and ridges left by the tines will be levelled insufficiently. -
Page 17: Rollers
9 ROLLERS The SMARAGD 7 can be equiped with a D400 or D540 tube bar roller. The re- consolidation effect of the roller (14) can be influenced by setting the top link steeper or more horizontal; in doing so the tractor hydraulics must be set to "Floating position". -
Page 18: Outer Discs
10 OUTER DISCS The outer discs (25) will be bolted to the frame (R) of the discs. They should not work so deep as the inner discs; their purpose is only to move the soil which has been thrown beyond the working width, into the grooves left by the outer tines. -
Page 19: Shearbolts
Disc carrier SMARAGD 7 301 7314 301 3240 M 10x55 B=13/10.9 M 10x45 B=10/8.8 SMARAGD 7 Ü 301 3870 301 3240 M 26x65 B=20/10.9 M 10x45 B=10/8.8 • Read and adhere to the General Safety Instructions! • When changing shearbolts, use suitable tools, only! -
Page 20: Smaragd - With Automatic Overload Safety Device
12 SMARAGD - WITH AUTOMATIC OVERLOAD SAFETY DEVICE The tines (19) of the SMARAGD 7 Ü cultivator are equipped with an automatic overload safety device with springs (35), especially designed for stony soils. The tines trip back upon impact automatically return to the working position once the obstacle has been passed. -
Page 21: Maintenance
∗ Worn points, wings and guideboards etc. must be replaced in time, so that the carrying parts will not be involved. Use only genuine Lemken spare parts! Important: Do not clean this implement with a Pressure Washer during the first 6 weeks. -
Page 22: Weights
(weight with tube bar roller RSW 400) 16 NOISE, AIRBORNE SOUND The noise level of the SMARAGD 7 does not exceed 70 dB (A) during work. 17 NOTES It must be stated that these instructions apply only to the current design.
