Operating Instructions
Cultivator
Karat 9 KA
- en -
Item no. 175_4385
06/07.21
LEMKEN GmbH & Co. KG
Weseler Straße 5, 46519 Alpen / Germany
Telephone +49 28 02 81 0, Fax +49 28 02 81 220
lemken@lemken.com, www.LEMKEN.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Karat 9 KA and is the answer not in the manual?

Questions and answers

Related Manuals for LEMKEN Karat 9 KA

Summary of Contents for LEMKEN Karat 9 KA

  • Page 1 Operating Instructions Cultivator Karat 9 KA - en - Item no. 175_4385 06/07.21 LEMKEN GmbH & Co. KG Weseler Straße 5, 46519 Alpen / Germany Telephone +49 28 02 81 0, Fax +49 28 02 81 220 lemken@lemken.com, www.LEMKEN.com...
  • Page 3 However, this brief instruction is not a substitute for thorough study of the operating instructions. These operating instructions will help to familiarise you with the LEMKEN GmbH & Co. KG device and the options available for using it.
  • Page 4 Remember that you should only use genuine LEMKEN spare parts. Reproduction parts have a negative influence on the function of the device, have a shorter ser- vice life and present risks and hazards that cannot be estimated by LEMKEN GmbH & Co. KG. They also increase the maintenance costs.

  • Page 5: Table Of Contents

    CONTENTS General information ....................11 Liability ......................... 11 Guarantee ........................11 Copyright ........................12 Optional accessories ....................12 Type plate ........................13 Symbols used in the Operating Instructions ............15 Hazard classes ......................15 Information........................15 Environmental protection ................... 15 Indication of passages ....................
  • Page 6 Applicable rules and regulations ................28 Operation on public highways ................... 28 3.9.1 Lighting system and identification ................28 3.9.2 Requirements of the tractor ..................28 3.9.3 Permissible transport speed ..................29 3.9.4 Permissible lateral inclination during transportation ........... 30 3.9.5 Check before departure .....................
  • Page 7 Preparation of the Tractor ..................44 Tyres ..........................44 Lift Rods ........................44 Check Chains or Sway Blocks of the Three Point Linkage ........44 Required voltage sources ..................44 Hydraulic equipment required ..................45 Brake system ....................... 46 6.6.1 Air brake system ......................46 6.6.2 Hydraulic brake system .....................
  • Page 8 Traction increase device .................... 65 Safety chain ......................... 65 Folding the lateral parts in and out ............... 67 Folding in ........................67 Folding out ........................69 10 Driving on public highways ................... 71 10.1 General information ....................71 10.2 Preparation for driving on public roads ..............71 10.3 Hydraulic transport lock .....................
  • Page 9 11.7 Automatic overload protection .................. 90 11.7.1 Tines ........................90 11.7.2 Concave discs ......................91 11.7.3 Edge discs ......................91 11.8 Mounting and dismantling the weed harrow ............. 92 11.9 Adjusting the weed harrow..................94 11.10 Rollers .......................... 96 11.10.1 General .......................
  • Page 10 13 Detaching ....................... 113 13.1 General information ....................113 13.2 Braking system ......................114 13.2.1 Compressed air brake ..................114 13.2.2 Hydraulic braking system ..................114 13.3 Uncoupling......................... 115 13.3.1 Machine with hydraulic drawbar ................115 13.3.2 Machine with traction increase device ..............116 14 Switching over to different share systems ............
  • Page 11 16.4 Maintenance intervals ....................130 16.4.1 After the initial start-up (at the latest after 2 hours) ..........130 16.4.2 Daily inspection ....................130 16.4.3 Weekly checks ..................... 131 16.4.4 Annual check ......................131 16.4.5 Lubrication chart ....................132 16.4.6 Overview of lubricating points................133 16.5 Draining the compressed air tank ................
  • Page 12 17 Technical data ....................... 150 18 Noise, Airborne Sound ..................153 19 Notes ........................153 Index ..........................154...

  • Page 13: General Information
