- Page 1 LM58 5.8GHz Clip Microphone System Item ref: 171.858UK User Manual Version 1.0 Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty...
- Page 2 Introduction Thank you for choosing the Citronic LM58 wireless clip microphone system. This compact system offers convenient and discreet wireless microphone system for presentations, tuition, and demonstrations. Please read this manual before using this equipment to avoid damage through incorrect operation and to get the best performance from this equipment.
- Page 3 The LM58-T transmitter has an inbuilt condenser microphone with an omnidirectional pickup pattern. Alternatively, the transmitter has a mono 3.5mm jack which can accept a lavalier or headset microphone and provides 3V phantom power voltage for condenser types.
- Page 4 40 seconds of inactivity. Pairing The LM58-T transmitter pairing indicator is lit continuously when paired, or flashes when not paired. To enter pairing mode, hold down the Pair button for 5 seconds and the indicator will double flash.
- Page 5 Output Mode The next menu page sets the Output Mode, which can be either Stereo or Mono. In Stereo Mode, MIC1 (TX1) appears on the left audio output and MIC2 (TX2) appears on the right audio output. In Mono Mode, both mics appear on both outputs.
- Page 6 Specifications Power supply Internal rechargeable Li-ion battery Carrier frequency 5.8GHz ISM band Max. range Up to 60m Microphone: polar pattern Omnidirectional SPL max. 100dBu (internal microphone) Dynamic range 90dB Max. mic in -30dB Frequency response 30Hz - 18kHz S/N ratio 102dB Transmitter: power 7dBm...
