SUMAKE
Air Vibration Reduction 190mm Pittsburgh
Specification:
Blow Per Min
Piston Stroke
Air Consumption
Overall Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
Hammer (Round)
ST-2260/R
3,000 b.p.m.
2-19/25" (70mm)
7.8 CFM (221 L/min)
11-21/50" (290mm)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
5.28 lbs (2.4 kg)
Noise and Vibration:
Vibration
EN ISO 28927-10
Sound Pressure Level
No load: 101 dB(A)
No Load:
10.55 m/s²
Sound power level
No load: 112 dB(A)
Uncertainty
K= 1.5 m/s
²
Noise
Remark
EN ISO 15744
Please always
wear ear
protector at
environment
noise level > 80
dB(A) due to
risk of impaired
Uncertainty
hearing!
K= 3dB
ST-2260/R-S-2103A-JIF
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sumake ST-2260/R
Summary of Contents for Sumake ST-2260/R
- Page 1 3/8” (10 mm) dB(A) due to risk of impaired Air Pressure 90 psi (6.3 bar) Uncertainty Uncertainty hearing! K= 1.5 m/s ² K= 3dB Net Weight 5.28 lbs (2.4 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-2260/R-S-2103A-JIF...
-
Page 2: Ec Declaration Of Conformity
DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： AIR VIBRATION REDUCTION 190MM PITTSBURGH HAMMER (ROUND) Model/ Serial No.：ST-2260/R to which this declaration applies, complies with these normative documents: ... - Page 3 A portion of the water content, however, is Foreword screw condensed in the piping, and can enter the tool Sumake is a manufacturer and exporter of air mechanism, and may cause trouble. So, install an Warning tools since established. We have devote all our...
-
Page 4: Parts List
AIR VIBRATION REDUCTION 150MM PITTSBURGH HAMMER (ROUND) PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty 2260-01 Handle 2260-14 Piston [ST-2260/R] 2260-02 O-Ring (d1.8xW2.4) (P12) 2261-14 Piston [ST-2261/R] 2260-03 O-Ring (d3.8xW1.9) (P4) 2260-15 Valve Block Dowel Pin 2260-04 Throttle Valve... - Page 5 HAMMER Original instructions SUMAKE Industrial Co. Ltd.
- Page 6 The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
- Page 7 avoiding awkward off-balanced postures. The operator should change posture during extended tasks, which can help avoid discomfort and fatigue. 3. If the operator experiences symptoms, such as persistent or recurring discomfort, pain, throbbing, aching, tingling, numbness, burning sensations or stiffness, these warning signs should not be ignored. The operator should tell the employer and consult a qualified health professional.
- Page 8 7. Whenever universal twist couplings (claw couplings) are used, lock pins shall be installed and whipcheck safety cables shall be used to safeguard against possible hose-to-tool and hose-and-hose connection failure. 8. Do not exceed the maximum air pressure stated on the tool. 9.
