https://wiki.teltonika-networks.com/view/QSG_TRB255
QSG TRB255
Main Page
>
TRB Gateways
This Wiki page contains the online version of the Quick Start Guide (QSG) for the TRB255
Gateway. Here you will find an overview of the various components on the front and back of a
TRB255 device, hardware installation instructions, first login information, device specifications, and
general safety information. It is highly recommended to acquaint yourself with the Quick Start Guide
before using the device. You can also locate a printed version of the Quick Start Guide in the
packaging box of your device.
Contents
1 Safety information
-
1.1 General
-
-
-
-
-
Safety information
Before starting operating the device, please review recommendations and precautions to minimize
the possibility of accidents. Safety precautions presented are supplementary and subject to the local
safety regulations. When various operations are executed on the device, the user must fully follow
the safety instructions and recommendations provided with the device.
General
RF technologies EGPRS, NB-IoT, LTE (Cat-M1), GNSS
Max RF power 33 dBm@GSM, 23 dBm@LTE
Power adapter Input: 0.45 A@100-240 VAC, Output: 9 VDC, 1A, 2-PIN, with cord end terminals
698~960/1710~2690 MHz, 50 Ω, VSWR<3, gain** 4 dBi, omnidirectional, SMA
Mobile antenna
male connector
>
TRB255
> QSG TRB255
Radio specifications
Bundled accessories specifications*

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRB255 and is the answer not in the manual?

Questions and answers

Summary of Contents for Teltonika TRB255

  • Page 1: Table Of Contents

    TRB255 > QSG TRB255 This Wiki page contains the online version of the Quick Start Guide (QSG) for the TRB255 Gateway. Here you will find an overview of the various components on the front and back of a TRB255 device, hardware installation instructions, first login information, device specifications, and general safety information.
  • Page 2 ** Higher gain antenna can be connected to compensate for cable attenuation when a cable is used. The user is responsible for the compliance with the legal regulations. TRB255 gateway must be used in compliance with any and all applicable national and international laws and with any special restrictions regulating the utilization of the communication module in prescribed applications and environments.
  • Page 3 [MT] Maltese mar-rekwiżiti essenzjali u dispożizzjonijiet rilevanti oħra tad Direttiva 2014/53/EU TELTONIKA NETWORKS Erklærer herved at TRB255 er i samsvar med de [NO] Norwegian grunnleggende krav og øvrige relevante krav i direktiv 2014/53/EU Niniejszym TELTONIKA NETWORKS deklaruje że TRB255 jest zgodny z [PL] Polish zasadniczymi wymaganiami i innymi właściwymi postanowieniami Dyrektywy...
  • Page 4: Rf Exposure

    This sign on the package means that all used electronic and electric equipment should not be mixed with general household waste. Hereby, TELTONIKA NETWORKS declares that this TRB255 is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://wiki.teltonika-networks.com/view/TRB255_CE/RED.
  • Page 5: Operating Conditions

    External antennas used with TRB255 must be installed to provide a distance of at least 20 cm from any people and must not be co-located or operated in conjunction with any other antenna or transmitter. Any external antenna gain must meet RF exposure and maximum radiated output power limits of the applicable rule section.
  • Page 6: Electrical Safety

    Electrical safety Only use approved accessories. Do not connect with incompatible products or accessories. It is recommended to ground devices with grounding terminals before connecting them to power. Failure to ground appropriately might result in a shock hazard. The cross-sectional area of the protective grounding conductor should be at least 1mm2.
  • Page 7: Front View

    POWER SOCKET PINOUT Video Quick Start Guide Need some help setting up your new Teltonika Networks TRB255 Industrial 5G Gateway? Watch our quick start guide video and follow the step-by-step instructions to easily set up your new gateway for operation.
  • Page 8: Hardware Installation

    Hardware installation...
  • Page 9: Configure Your Computer Lan (Windows)

    Configure your computer LAN (Windows) 1. Ensure the Network connection is Enabled. Go to Start — Control Panel — Network and Internet — Network and Sharing Center. Click on the Change adapter settings in the left panel, then right-click on Network Adapter, and select Enable.
  • Page 10: Login To Device

    2. Check if IP and DNS are obtained automatically. Right-click on Wireless Network Adapter and select Properties. Then select Internet Protocol Version 4 and click Properties. 3. If not selected, check to obtain an IP address and obtain DNS server address automatically.
  • Page 11: Sim Card Recommendations

    3. After logging in, you must set a new password for security reasons. You will not be able to interact with the gateway’s WebUI until the default password is changed. The new password must consist of a minimum of 8 characters.
  • Page 12 environments with extreme temperatures, corrosive or extra humid climates, or hard-to- reach locations.
