Page 2
FRONT VIEW Power socket RS232 interface Power LED BACK VIEW Mobile signal strength indication LEDs Mobile network type LEDs Reset button USB port Mobile antenna connector...
Page 3
POWER SOCKET PINOUT HARDWARE INSTALLATION 1. Unscrew two back panel hex bolts. 2. Remove the back panel. 3. Insert your SIM card into the SIM socket. 4. Attach the panel and tighten the hex bolts. 5. Attach the LTE antenna torque (max torque 0.4 Nm 3.5 in-lbs) and connect the USB cable.
Page 4
DEVICE CONFIGURATION 1. Power on the device and connect the USB cable to your computer. 2. Allow the gateway to boot up. This might take up to 30 seconds. 3. Your computer's OS should detect the USB device and install the drivers for the virtual NDIS network adapter.
DECLARATION OF CONFORMITY TRB142 gateway must be used in compliance with any and all applicable national and international laws and with any special restrictions regulating the utilization of the communication module in prescribed applications and environments. Hereby, TELTONIKA declares that this TRB142 is in compliance with the essential requirements and other relevant provisions of [EN] English Directive RED.
Page 6
[SE] Instruktionsmanual: Anslut nätadap tern för att slå på enheten. Öppna 192.168.2.1 i en webbläsare för att konfigurera produkten. Mer information på https://wiki.teltonika.lt [SI] Navodila: Priključite napajalnik za vklop naprave. Odprite 192.168.2.1 v spletnem brskalniku nastaviti izdelek. Več informacij v https://wiki.teltonika.lt [SK] NávoZd na použitie: Pripojte napájací adaptér k zapnutiu prístroja. Otvorte 192.168.2.1 vo webovom prehliadači pre konfiguráciu produktu. Viac informácií...
