- Page 1 INTERCULTIVATOR/POWER WEEDER AM-RT-1252-7PR- HIGH POWER ENGINE DIAGRAM...
- Page 2 INTRODUCTION Dear Sir/ Madam, Thank you for choosing Agrimate product. You are the proud owner of high technology & durable machine. Trust that our Franchisee/Dealer installed the product & installed the product and explained you about the usage & service instrcuctions. Please visit our autorised dealer for your future requirement of our other equipments, genuine spares, accessories and services.
- Page 3 ENGINE DIAGRAM OF AM-RT-1252-7PR- HIGH POWER...
- Page 4 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-177FP-RC-E01 CAP COMP FUEL FILLER AM-177FP-RC-E17 BOLT COMP HEAD COVER AM-177FP-RC-E02 FILTER FUEL AM-177FP-RC-E18 TUBE BREATHER AM-177FP-RC-E03 TANK COMP FUEL AM-177FP-RC-E19 GASKET EX PIPE AM-177FP-RC-E04 JOINT ASSY FUEL TANK AM-177FP-RC-E20 PIPE COMP EX AM-177FP-RC-E05 CLIP TUBE...
- Page 5 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-177FP-RC-E33 NOSE SILENCER AM-177FP-RC-E49 REEL RECOIL STARTER AM-177FP-RC-E34 ELEMENT ASSY AIR CLEANER AM-177FP-RC-E50 KNOB RECOIL STARTER AM-177FP-RC-E35 COVER AIR CLEANER AM-177FP-RC-E51 SRPING FRICTION AM-177FP-RC-E36 NUT BUTTERFLY AM-177FP-RC-E52 SPRING RETURN AM-177FP-RC-E37 ROD GOVERNOR AM-177FP-RC-E53 ROPE...
- Page 6 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-177FP-RC-E65 VALVE EX AM-177FP-RC-E81 PACKING CARBURETOR AM-177FP-RC-E66 VALVE IN AM-177FP-RC-E82 CARBURETOR AM-177FP-RC-E67 SEAT VALVE SPRING AM-177FP-RC-E83 PACKING AIR CLEANER AM-177FP-RC-E68 SEAL VALVE STEM AM-177FP-RC-E84 BOLT FLANGE AM-177FP-RC-E69 SPRING VALVE AM-177FP-RC-E85 COIL ASSY IGNITION AM-177FP-RC-E70 RETAINER EX VALVE SPRING...
-
Page 7: Fan Cooling
SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-177FP-RC-E97 SHAFT GOVERNOR AM-177FP-RC-E106 ALERT UNIT OIL AM-177FP-RC-E98 SLIDER GOVERNOR AM-177FP-RC-E107 TIE CABLE AM-177FP-RC-E99 CRANKSHAFT ASSY AM-177FP-RC-E108 CRANKCASE AM-177FP-RC-E100 KEY SPECIAL WOODRUFF AM-177FP-RC-E109 GROMMET CORD AM-177FP-RC-E101 CAMSHAFT ASSY AM-177FP-RC-E110 FLYWHEEL COMP AM-177FP-RC-E102 SWITCH ASSY OIL LEVEL AM-177FP-RC-E111... -
Page 8: Warranty Card
WARRANTY CARD CUSTOMER COPY DEALERS SIGN DEALERS OFFICIAL SEAL DATE DATE OF DELIVERY PURCHASERS NAME & ADDRESS CUSTOMER SIGN INVOICE/DN NO. PRODUCT SERIAL NO. PRODUCT NAME I/Will accept the terms and conditions of warranty as in the warranty card DEALERS COPY DEALERS SIGN DEALERS OFFICIAL SEAL DATE... - Page 9 1.LIMITED WARRANTY PERIOD : For a period of six months from the date of Sale / delivery of the product which ever is earlier. 2. LIMITED WARRANTY OBLIGATION : Replacement of defective part(s) by authorized dealer are free of charges. If found defective by reasons of defective material / poor workmanship, parts will be replaced and there will be no value re-imbursement. 3. TERMS & CONDlTlONS : a. Claims under warranty will be accepted on submission of Warranty Card duly filled and stamped by authorized dealer together with the original purchase document.
- Page 10 1st service coupon ISO 9001 : 2015 CERTIFIED COMPANY FREE SERVICE COUPON (30DAYS/30HRS. WHICHEVER IS EARLIER SERIAL NUMBER MODEL SERVICE NO. PURCHASE BILL NO. DATE PDI DATE OPERATIONS DEALERS OFFICE SEAL 1. Check and test the fuel mixture 2. check and clean the air filter 3.Check , clean and adjust the spark plug 4.
- Page 11 DONTS attempting to use the equipments. Always read the instruction manual supplied along with the equipments and understand the correct installation and operating procedures before trousers and jackets while operating potentially dangerous machines 2. It is important to use the personal protection equipments such as head helmet with visor, ear defenders, goggles, safety gloves, cut resistant shoes, 3.
