DATA PROJECTOR
MODEL
XG-F315X

OPERATION MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Sharp XG-F315X

Summary of Contents for Sharp XG-F315X

  • Page 1: Operation Manual

    DATA PROJECTOR MODEL XG-F315X OPERATION MANUAL...
  • Page 2 IMPORTANT • For your assistance in reporting the loss or theft of your Projector, please record the Model and Serial Number located on the bottom of the projector and retain this information. • Before recycling the packaging, please ensure that you have checked the con- tents of the carton thoroughly against the list of “Supplied accessories”...
  • Page 3 SPECIAL NOTE FOR USERS IN THE U.K. The mains lead of this product is fitted with a non-rewireable (moulded) plug incorporat- ing a 10A fuse. Should the fuse need to be replaced, a BSI or ASTA approved BS 1362 fuse marked and of the same rating as above, which is also indicated on the pin face of the plug, must be used.
  • Page 4 The supplied CD-ROM contains operation instructions in English, German, French, Swedish, Spanish, Italian, Dutch, Portuguese, Chinese and Korean. Carefully read through the operation instructions before operating the projector. Die mitgelieferte CD-ROM enthält Bedienungsanleitungen in Englisch, Deutsch, Französisch, Schwedisch, Spanisch, Italienisch, Niederländisch, Portugiesisch, Chinesisch und Koreanisch. Bitte lesen Sie die Bedienungsanleitung vor der Verwendung des Projektors sorgfältig durch.
  • Page 5 Before using the projector, please read this operation manual carefully. Introduction There are two important reasons for prompt warranty registration of your new SHARP Projector, using the REGISTRATION CARD packed with the projector. 1. WARRANTY This is to assure that you immediately receive the full benefit of the parts, service and labor warranty applicable to your purchase.

  • Page 6: Product Disposal

    United States of America, the Electronic Industries Alliance: www.eiae.org. Caution Concerning Lamp Replacement See “Replacing the Lamp” on page 57. This SHARP projector uses a DLP ® chip. This very sophisticated panel contains 786,432 pixels (micromirrors). As with any high technology electronic equipment such as large screen TVs, video systems and video cameras, there are certain acceptable tolerances that the equipment must conform to.

  • Page 7: How To Read This Operation Manual

    How to Read this Operation Manual ■ The specifications are slightly different, depending on the model. However, you can connect and operate all models in the same manner. • • • • • In this operation manual, the illustration and the screen display are simplified for explanation, and may differ slightly from the actual display.

  • Page 8: Table Of Contents

    Contents Preparing Introduction How to Read this Operation Manual ... 3 Contents ... 4 IMPORTANT SAFEGUARDS ... 6 How to Access the PDF Operation Manuals ... 10 Accessories ... 11 Part Names and Functions ... 12 Projector ... 12 Rear View ... 13 Inserting the Batteries ...
  • Page 9 Resetting the Lamp Timer ... 59 Storing the Projector ... 60 How to Use the Storage Case ... 60 Computer Compatibility Chart ... 61 Troubleshooting ... 62 For SHARP Assistance ... 64 Specifications ... 65 Dimensions ... 66 Index ... 67...

  • Page 10: Important Safeguards

    IMPORTANT SAFEGUARDS CAUTION: Please read all of these instructions before you operate this product and save these instructions for later use. Electrical energy can perform many useful functions. This product has been engineered and manufactured to assure your personal safety. BUT IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARDS.
  • Page 11 15. Overloading Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock. 16. Object and Liquid Entry Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock.
  • Page 12 Internal cleaning should only be performed by a Sharp Authorized Projector Dealer or Service Center. Do not set up the projector in places exposed to direct sunlight or bright light.
  • Page 13 Caution regarding usage of the projector ■ If you are not to use the projector for a long time or before moving the projector, make certain you unplug the power cord from the wall outlet, and disconnect any other cables connected to it.

  • Page 14: How To Access The Pdf Operation Manuals

    How to Access the PDF Operation Manuals PDF operation manuals in several languages are included in the CD-ROM. To uti- lize these manuals, you need to install Adobe ® ® dows or Macintosh Please download Adobe Accessing the PDF Manuals ®...

  • Page 15: Accessories

    ■ Ceiling-mount bracket ■ Extension tube Note • Some of the optional accessories may not be available depending on the region. Please check with your nearest Sharp Authorized Projector Dealer or Service Center. RGB cable (10' (3.0 m)) <QCNWGA045WJPZ> DIN-D-sub RS-232C adaptor "...

  • Page 16: Part Names And Functions

    Part Names and Functions Numbers in refer to the main pages in this operation manual where the topic is explained. Projector Top View Power indicator STANDBY/ON button For turning the power on and putting the projector into standby mode. ENTER button For setting items selected or adjusted on...

  • Page 17: Rear View

    Numbers in refer to the main pages in this operation manual where the topic is explained. Rear View Terminals MONITOR OUT terminal (Output terminal for computer RGB, component and DVI analog signals. Shared for COMPUTER/COMPONENT and DVI-I) Terminal for connecting a monitor. DVI-I input terminal Terminal for DVI digital, computer...
  • Page 18 Part Names and Functions (Continued) STANDBY button For putting the projector into the standby mode. COMPUTER, DVI, S-VIDEO, VIDEO buttons For switching to the respective input modes. BREAK TIMER button For displaying the break time. MAGNIFY buttons For enlarging/reducing part of the image. PAGE UP/PAGE DOWN buttons Same as the [Page Down] and...

  • Page 19: Inserting The Batteries

    Inserting the Batteries Pull down the tab on the cover and remove the cover towards the direction of the arrow. Insert the batteries. • Insert the batteries making sure the polarities correctly match the m and n marks inside the battery compartment. Insert the lower tab of the cover into the opening, and lower the cover until it clicks in place.

  • Page 20: Quick Start

    Quick Start This section shows the basic operation (projector connecting with the computer). For details, see the page described below for each step. Setup and Projection In this section, connection of the projector and the computer is explained using one example. 1.
  • Page 21 4. Adjust the projected image with the Setup Guide After the projector turns on, the Setup Guide appears. (When “Setup Guide” is set to “On”. See page 45.) Follow the steps in the Setup Guide and adjust the focus, picture size, and height (angle). After adjusting the focus, height (angle) and picture size, press ENTER to finish the Setup Guide.

  • Page 22: Setting Up The Projector

    “Screen Size and Projection Distance”. Ceiling-mount Setup ■ It is recommended that you use the optional Sharp ceiling-mount bracket for this installa- tion. Before mounting the projector, contact your nearest Sharp Authorized Projector Dealer or Service Center to obtain the rec- ommended ceiling-mount bracket (sold separately).

  • Page 23: Projection (Prj) Mode

    Projection (PRJ) Mode The projector can use any of the 4 projection modes shown in the diagram below. Select the mode most appropriate for the projection setting in use. (You can set the PRJ mode in “SCR-ADJ” menu. See page 45.) ■...

  • Page 24: Screen Size And Projection Distance

    Setting up the Projector (Continued) Screen Size and Projection Distance NORMAL Mode (4:3) Picture (Screen) size Diag. [ χ ] Width 300 (762 cm) 610 cm (240 ) 457 cm (180 ) 270 (686 cm) 549 cm (216 ) 411 cm (162 ) 250 (635 cm) 508 cm (200 ) 381 cm (150 )

  • Page 25: Connecting The Projector To Other Equipment

    • Depending on the computer you are using, an image may not be projected unless the computer’s external output port is switched on (e.g. Press “Fn” and “F5” keys simultaneously when using a SHARP notebook computer). Refer to the specific instructions in your computer's operation manual to enable your computer’s external output port.
  • Page 26 Connecting the Projector to Other Equipment (Continued) Terminal on Equipment connected equipment Video equipment HDMI output terminal DVI digital output terminal Component video output terminal S-video output terminal Video output terminal Camera/Video game Component video output terminal S-video output terminal Video output terminal...
  • Page 27 • RGB signals and Component signals can be output to the monitor. Cable ø3.5 mm stereo or mono audio cable (commercially available or available as Sharp service part QCNWGA038WJPZ) RCA audio cable (commercially available) Cables for a camera or a video game RGB cable (supplied or commercially available) ø3.5 mm stereo or mono audio cable...

  • Page 28: Controlling The Projector By A Computer

    Controlling the Projector by a Computer When the RS-232C terminal on the projector is connected to a computer with a DIN-D-sub RS- 232C adaptor and an RS-232C serial control cable (cross type, commercially available), the computer can be used to control the projector and check the status of the projector. Refer to the “SETUP MANUAL”...

  • Page 29: Connecting The Power Cord

    When connecting to the LAN terminal using a LAN cable LAN cable (Category 5 type, commercially available) Note • When connecting to a hub, use a straight-through Category 5 (CAT.5) type cable (commercially available). • When connecting to a computer, use a cross-over Category 5 (CAT.5) type cable (commercially available).

  • Page 30: Turning The Projector On/Off

    Turning the Projector On/Off Turning the Projector on Note that the connections to external equip- ment and power outlet should be done be- fore performing the operations written be- low. (See pages to 25.) Remove the lens cap and press STANDBY/ON on the projector or ON on the remote control.

  • Page 31: Image Projection

    Image Projection About the Setup Guide After turning on the projector, the Setup Guide screen appears to assist you with projector setup. Guidance items 1 FOCUS 2 HEIGHT ADJUST 3 ZOOM Press ENTER to exit the Setup Guide screen. Note •...

  • Page 32: Adjusting The Height

    Image Projection (Continued) 3 Adjusting the Height The height of the projector can be ad- justed using the adjustment feet at the front and rear of the projector. When the screen is above the projec- tor, the projection image can be made higher by adjusting the projector.

  • Page 33: Correcting Trapezoidal Distortion

    Correcting Trapezoidal Distortion When the image is projected either from the top or from the bottom towards the screen at an angle, the image becomes distorted trapezoidally. The function for correcting trapezoidal distortion is called Keystone Correction. Note • The Keystone Correction can be adjusted up to an angle of approximately ±40 degrees and the screen can also be set up to an angle of approximately ±40 degrees (when the resize...

  • Page 34: Switching The Input Mode

    Image Projection (Continued) Switching the Input Mode Select the appropriate input mode for the connected equipment. Press COMPUTER, DVI, S-VIDEO or VIDEO on the remote control to select the input mode. • When you press INPUT on the projector or DVI on the remote control, the INPUT list appears.

  • Page 35: Resize Mode

    Resize Mode This function allows you to modify or customize the resize mode to enhance the input image. De- pending on the input signal, you can choose a desired image. Press RESIZE. • See page for setting on menu screen. COMPUTER SVGA (800 ×...
  • Page 36 Image Projection (Continued) VIDEO/DTV VIDEO Input signal Video/DTV Image type 4:3 aspect ratio 480I, 480P, 576I, 576P, NTSC, PAL, SECAM Squeeze Letter box 720P, 1035I, 1080I, 1080P 16:9 aspect ratio 16:9 aspect ratio 540P (4:3 aspect ratio in 16:9) : Cutout area on which images cannot be projected : Area on which the image is not included in the original signals *The Image Shift function can be used for these images.

  • Page 37: Operating With The Remote Control

    Operating with the Remote Control BREAK TIMER button FREEZE button MAGNIFY buttons POINTER button SPOT button Adjustment buttons (P/R/O/Q) PICTURE MODE button ECO+QUIET button AUTO SYNC button Displaying and Setting the Break Timer Press BREAK TIMER. • The timer starts to count down from 5 minutes.

  • Page 38: Auto Sync (Auto Sync Adjustment)

    Operating with the Remote Control (Continued) Auto Sync (Auto Sync Adjustment) Auto Sync function works when detect- ing input signal after the projector turns Press AUTO SYNC to manually adjust with Auto Sync function. Note • When the optimum image cannot be achieved with Auto Sync adjustment, use the help menu for manual adjustments.

  • Page 39: Using The Remote Control As The Wireless Computer Mouse

    • You cannot use this function when displaying the menu screen. • Confirm that the computer recognizes the USB connection. To USB terminal To USB terminal USB cable (commercially available or available as Sharp service part QCNWGA014WJPZ) ® Windows ® OS and Mac OS ®...

  • Page 40: Menu Items

    The following shows the items that can be set in the projector. “Picture” menu PAGE 1 Picture Net. Picture Mode Standard Contrast Bright Color Tint Sharp Blue SEL./ADJ. ENTER PAGE 2 Picture Net. Picture Mode Standard CLR Temp BrilliantColor C.M.S. Setting C.M.S.
  • Page 41 “Screen adjustment (SCR-ADJ)” menu Pict. SCR-ADJ Net. Resize Border Image Shift Keystone Auto Keystone OSD Display Background Logo Setup Guide PRJ Mode Front English Language SEL./ADJ. ENTER “Projector adjustment (PRJ-ADJ)” menu Pict. PRJ-ADJ Net. Auto Sync Auto Power Off Auto Restart STANDBY Mode Standard System Sound...
  • Page 42 Menu Items (Continued) “Network” menu Pict. Network Password Disable DHCP Client TCP/IP MAC Address X X : X X : X X : X X : X X : X X Projector X X - X X X X SEL./ADJ. ENTER “Help”...

  • Page 43: Using The Menu Screen

    Using the Menu Screen ENTER button Adjustment buttons (P/R/O/Q) MENU/HELP button Menu Selections (Adjustments) Example: Adjusting “Bright”. • This operation can also be performed by using the buttons on the projector. Press MENU/HELP. • The “Picture” menu screen for the se- lected input mode is displayed.
  • Page 44 Using the Menu Screen (Continued) Press P or R and select “Bright” to adjust. • The selected item is highlighted. To adjust the projected image while watching it Press ENTER. • The selected item (e.g. “Bright”) is dis- played by itself at the bottom of the screen.

  • Page 45: Picture Adjustment ("Picture" Menu)

    Picture Adjustment (“Picture” Menu) Q PAGE1 Picture Net. Picture Mode Contrast Bright Color Tint Sharp Blue SEL./ADJ. ENTER 1 1 1 1 1 Selecting the Picture Mode Selectable Description items Standard For standard image Presentation Brightens portions of image for more enhanced presentations.

  • Page 46: Adjusting The Image

    Bright For less brightness. Color* For less color intensity. Tint* For making skin tones purplish. Sharp* For less sharpness. Red* For weaker red. Blue* For weaker blue. BrilliantColor™* For making the effect weaker. *1 Not displayed in the RGB input mode.

  • Page 47: Progressive

    Menu operation n Page 5 5 5 5 5 Progressive Selectable Description items Useful to display fast-moving images Progressive such as sports. Useful to display relatively slow- Progressive moving images such as drama and documentary more clearly. Film Mode Reproduces the image of film source* clearly.

  • Page 48: Adjusting The Projector Image ("Scr - Adj" Menu)

    Adjusting the Projected Image (“SCR - ADJ” Menu) 1 1 1 1 1 Setting the Resize Mode Note • For details of the Resize mode, see pages 31and 32. • You can also press RESIZE on the remote con- trol to set the resize mode. (See page 31.) 2 2 2 2 2 Adjusting the Image Position You can move the projected image vertically.

  • Page 49: Setting The On-Screen Display

    ECO+QUIET/MAGNIFY/ “An invalid button has been pressed.” are not displayed. 5 5 5 5 5 Selecting the Background Image Selectable items Description Logo Sharp logo screen Blue Blue screen None — 6 6 6 6 6 Selecting the Setup Guide Selectable items...

  • Page 50: Adjusting The Projector Function

    Adjusting the Projector Function (“PRJ - ADJ” Menu) Pict. PRJ-ADJ Auto Sync Auto Power Off Auto Restart STANDBY Mode System Sound Speaker Audio Input RS-232C Fan Mode System Lock Lamp Timer(Life) SEL./ADJ. ENTER 1 1 1 1 1 Auto Sync (Auto Sync Adjustment) Selectable Description...

  • Page 51: Audio Input

    Info • If you lose or forget your keycode, contact your nearest Sharp Authorized Projector Dealer or Service Center (see page 64). Even if the product warranty is valid, the keycode reset will incur a charge.

  • Page 52: Checking The Lamp Life Status

    Adjusting the Projector Function (“PRJ - ADJ” Menu) (Continued) Enter the same keycode in “Re- confirm”. Note To cancel the keycode that you have already • Press R on the projector for four times in steps 4 and 5 above. When the System Lock is set •...

  • Page 53: Setting Up The Projector Network Environment ("Network" Menu)

    Setting up the Projector Network Environment (“Network” menu) Password DHCP Client TCP/IP 1 1 1 1 1 Setting a Password If you do not want others to change the setting for the “Network” menu, set a password. a Setting a Password Select “Password”, then press ENTER or Q.

  • Page 54: Dhcp Client Setting

    Setting up the Projector Network Environment (“Network” menu) (Continued) 2 2 2 2 2 DHCP Client Setting Connect the LAN cable before turning the pro- jector on. If not, the DHCP Client function does not work. Selectable items Obtains configuration parameters for TCP/IP network automatically.

  • Page 55: Troubleshooting With The "Help" Menu

    Troubleshooting with the “Help” Menu This function advises you to solve the problems during usage. Utilizing the “Help” Menu Functions Example: When image flickering appears Operation to solve image flickering when pro- jecting the computer RGB signal. Press MENU/HELP. Press O or Q to select “Help”, then press ENTER.

  • Page 56: Maintenance

    Maintenance Cleaning the projector ■ Ensure that you have unplugged the power cord before cleaning the projector. ■ The cabinet as well as the operation panel is made of plastic. Avoid using benzene or thinner, as these can damage the finish on the cabinet.

  • Page 57: Cleaning And Replacing The Dust Filters

    Cleaning and Replacing the Dust Filters Cleaning the Dust Filters Info • The dust filters should be cleaned every 100 hours of use. Clean the filters more often when the projector is used in a dusty or smoky location. Press STANDBY/ON on the projec- tor to put the projector into standby mode.

  • Page 58: Replacing The Dust Filters

    Replacing the Dust Filters Info • If the filters become too dirty to clean effectively, purchase new ones (PFILDA025WJZZ) from your nearest Sharp Authorized Projector Dealer or Service Center. After removing the filter holders (see step 2 of “Cleaning the Dust Filters”), remove the dust filters, then replace with new ones.

  • Page 59: Maintenance Indicators

    Maintenance Indicators ■ The warning lights (power indicator, lamp indicator and temperature warning indicator) on the projector indicate problems inside the projector. ■ If a problem occurs, either the temperature warning indicator or the lamp indicator will illuminate red, and the projector will enter standby mode. After the projector has entered standby mode, follow the procedures given below.
  • Page 60 Possible Solution • Relocate the projector to an area with proper ventilation. (See page 8.) • Take the projector to your nearest Sharp Authorized Projector Dealer or Service Center (see page 64) for repair. • Disconnect the power cord from the AC outlet, and then connect it again.

  • Page 61: Regarding The Lamp

    Sharp Authorized Projector Dealer or Service Center. * If the new lamp does not light after replacement, take your projector to the nearest Sharp Authorized Projector Dealer or Service Center for repair.

  • Page 62: Removing And Installing The Lamp Unit

    Regarding the Lamp (Continued) Removing and Installing the Lamp Unit Warning! • Do not remove the lamp unit from the projec- tor right after use. The lamp and parts around the lamp will be very hot and may cause burns or injury.

  • Page 63: Resetting The Lamp Timer

    Remove the lamp unit. • Loosen the securing screws from the lamp unit. Hold the lamp unit by the handle and pull it in the direction of the arrow. At this time, keep the lamp unit horizontal and do not tilt it. Insert the new lamp unit.

  • Page 64: Storing The Projector

    Storing the Projector How to Use the Storage Case When storing the projector, attach the lens cap to the lens, and place it in the supplied storage case. Open the cover of the storage case. Place the projector into the stor- age case.

  • Page 65: Computer Compatibility Chart

    Computer Compatibility Chart Computer • Multiple signal support Horizontal Frequency: 15-110 kHz, Vertical Frequency: 45-85 Hz, The following is a list of modes that conform to VESA. However, this projector supports other signals that are not VESA standards. Horizontal Frequency PC/MAC Resolution 640 ×...

  • Page 66: Troubleshooting

    Troubleshooting Problem • Projector power cord is not plugged into the wall outlet. • Power to the external connected devices is off. • The selected input mode is wrong. • Cables are incorrectly connected to the projector. • Remote control battery has run out. •...
  • Page 67 Problem Maintenance indicator on • See “Maintenance Indicators”. the projector illuminates or blinks in red. The projector cannot • The keylock is set. be turned on or put into If the keylock is set to “ON”, all the buttons are locked. the standby mode using STANDBY/ON on the projector.

  • Page 68: For Sharp Assistance

    For SHARP Assistance If you encounter any problems during setup or operation of this projector, first refer to the “Troubleshooting” section on pages does not answer your question, please contact the SHARP Service departments listed below. U.S.A. Sharp Electronics Corporation 1-888-GO-SHARP (1-888-467-4277) lcdsupport@sharpsec.com...

  • Page 69: Specifications

    Dimensions (main body only) Weight (approx.) As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specifica- tion figures indicated are nominal values of production units. There may be some deviations from these values in individual units.

  • Page 70: Dimensions

    Dimensions Units: inches (mm) ø9 (69.2) (77.5) (80) (315) (33.8) (46.2) (65.5) (75)

  • Page 71: Index

    RGB cable ... 21 RS-232C terminal ... 24 SCR - ADJ ... 44 Screen Size and Projection Distance ... 20 Setup Guide ... 27, 45 Sharp ... 42 Speaker ... 46 SPOT button ... 33 STANDBY button ... 26 STANDBY Mode ... 46 STANDBY/ON button ...
