SERVICE MANUAL
MULTIMEDIA PROJECTOR
MODELS
OUTLINE
CONTENTS
Parts Guide
XR-40X/XR-41X/XG-F260X
No. S57J1XR-40X//
XR-40X
XR-41X
XG-F260X
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
Advertisement
Table of Contents
Related Manuals for Sharp XR-41X
Summary of Contents for Sharp XR-41X
-
Page 1: Table Of Contents
TopPage XR-40X/XR-41X/XG-F260X SERVICE MANUAL No. S57J1XR-40X// MULTIMEDIA PROJECTOR XR-40X XR-41X XG-F260X MODELS In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig- inal condition and only parts identical to those specified should be used. -
Page 2: Outline And Modified Parts List
OUTLINE AND MODIFIED PARTS LIST Service Manual OUTLINE This Service Manual covers the differences from XR-30X/XG-F210X. For other technical information, refer to the XR-30S/XR-30X/XG-F210X (No. S47E3XR-30XS/) Service Manual. MODIFIED PARTS (XR-30X/XG-F210X → XR-40X/XR-41X/XG-F260X) Ref.No. Description XR-30X/XG-F210X XR-40X/XR-41X/XG-F260X Note PRINTED WIRING BOARD ASSEMBLIES ←... -
Page 3: Safety Precaution
XR-40X/XR-41X/XG-F260X XR-40X SAFETY PRECAUTION Service Manual IMPORTANT SERVICE SAFETY NOTES IMPORTANT SERVICE SAFETY NOTES (for USA) Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and servicing guidelines as follows: WARNING Use an AC voltmeter with sensitivity of 5000 ohm per volt., or higher, sensitivity to measure the AC voltage... - Page 4 XR-40X/XR-41X/XG-F260X PRECAUTIONS A PRENDRE LORS DE LA REPARATION Ne peut effectuer la réparation qu' un technicien spécialisé qui s'est parfaitement accoutumé à toute vérification de sécurité et aux conseils suivants. AVERTISSEMENT Utiliser un voltmètre CA d'une sensibilité d'au moins 1. N'entreprendre aucune modification de tout circuit.
-
Page 5: Note To Service Personnel
XR-40X/XR-41X/XG-F260X NOTE TO SERVICE NOTE POUR LE PERSONNEL PERSONNEL D’ENTRETIEN ////////////////////////////////////////////////////////////// ////////////////////////////////////////////////////////////// UV-RADIATION PRECAUTION PRECAUTION POUR LES RADIATIONS UV ////////////////////////////////////////////////////////////// ////////////////////////////////////////////////////////////// La source de lumière, la lampe, dans le projecteur émet The light source, lamp, in the projector emits small de petites quantités de radiation UV. -
Page 6: Lamp Replacement
XR-40X/XR-41X/XG-F260X //////////////////////////////////////////////////////////////// //////////////////////////////////////////////////////////////// UV-RADIATION PRECAUTION (Continued) PRECAUTION POUR LES RADIA TIONS UV (Suite) //////////////////////////////////////////////////////////////// //////////////////////////////////////////////////////////////// Lamp Replacement Remplacement de la lampe Note: Remarque: Since the lamp reaches a very high temperature during Comme la lampe devient très chaude pendant le units operation replacement of the lamp should be fonctionnement de l’unité, son remplacement ne doit... -
Page 7: Power Unit
XR-40X/XR-41X/XG-F260X WARNING: High brightness light source, do not stare into the beam of light, or view directly. Be especially careful that children do not stare directly into the beam of light. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO MOISTURE OR WET LOCATIONS. -
Page 8: Precautions For Using Lead-Free Solder
XR-40X/XR-41X/XG-F260X Precautions for using lead-free solder Employing lead-free solder • "PWBs" of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder. -
Page 9: Chapter 1. Operation Manual Specifications
Weight (approx.) 6.4 lbs. (2.9 kg) As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specifica- tion figures indicated are nominal values of production units. There may be some deviations from these values in individual units. -
Page 10: Chapter 2. Electrical Adjustment Electrical Adjustment
(Process menu) 1. Set as below. 1. Select the following group and subject. XR-40X : 1 Group: CONFIRM XR-41X : 4 Subject: MODEL XG-F260X : 3 Adjustment of CW index 1. Signal input: Send 256 STEP color bar. 1. The signal is input into computer 1. - Page 11 DVI input operation check Send the video signal to the DVI terminal. 1. For XR-40X/XR-41X, check that an image is prop- erly projected through the digital input. 2. For XG-F260X, check that an image is properly pro jected through the digital input and analog input.
- Page 12 XR-40X/XR-41X/XG-F260X Adjusting point Adjusting conditions Adjusting procedure RS232C operation check 1. Connect the unit and a PC with the 1. Send a command from the PC, and check it func- RS232C cable. tions correctly. Model name and version check 1. Select the following group.
-
Page 13: Adjustment Mode Process Menu
XR-40X/XR-41X/XG-F260X [2] Adjustment mode process menu 1st Layer 2nd Layer Default 1st Layer 2nd Layer Default ADJUST CW/Auto KS CW-INDEX OTHER SPECIAL USB-MODE HDCP-MODE K-SENS PULSE-MODE AD/DLP R-CONT EDID EEP-SELECT G-CONT EEP-WP B-CONT EXIT R-GAIN G-GAIN B-GAIN — — —... - Page 14 XR-40X/XR-41X/XG-F260X 1. Adjustment of ballast unit output power (lamp power) 1. List of parts requiring adjustment When replacing the following parts, adjust the ballast unit output power (lamp power). Part name Ref No. Part code Cement resistor R923 RR-FZA002WJZZ Ballast Control PWB ——...
- Page 15 XR-40X/XR-41X/XG-F260X PartsGuide PARTS GUIDE MULTIMEDIA PROJECTOR XR-40X XR-41X XG-F260X MODELS Note: The reference numbers on the PWB are arranged in alphabetical order. CONTENTS PRINTED WIRING BOARD SUPPLIED ACCESSORIES ASSEMBLIES PACKING PARTS CABINET AND MECHANICAL (NOT REPLACEMENT ITEM) PARTS SERVICE JIGS AND EQUIPMENT...
- Page 16 XR-40X/XR-41X/XG-F260X PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [1] PRINTED WIRING BOARD ASSEMBLIES BALLAST POWER Ass'y (with Ballast Control Unit) DSETUE149FMG0 BALLAST POWER Unit Order the BALLAST POWER Ass'y (DSETUE149FMG1) when Not Available replacing ballast power unit (DUNTKE149WEF1). BALLAST CONTROL Unit...
-
Page 17: Cabinet And Mechanical Parts
XR-40X/XR-41X/XG-F260X [2] CABINET AND MECHANICAL PARTS 2-11 2-10 2-1-3 2-1-1 2-1-2... - Page 18 PARTS CODE DESCRIPTION RANK MARK DELIVERY [2] CABINET AND MECHANICAL PARTS Top Body Ass'y (XR-40X) CBDYTA235WEF0 Top Body Ass'y (XG-F260X) CBDYTA236WEF0 Top Body Ass'y (XR-41X) CBDYTA245WEF0 Top Body Not Available Cover GCOVAC364WJSA Decoration Plate HDECPA034WJSA Indicator (XR-41X) HiNDPC319WJSA Indicator (XR-40X/XG-F260X)
- Page 19 XR-40X/XR-41X/XG-F260X [3] OPTICAL MECHANISM PARTS 4-33 4-33 4-11 4-33 4-27 4-33 4-33 4-25 4-16 4-24 4-36 4-33 4-34 4-29 4-13 4-34 4-33 4-33 4-33 4-12 4-33 4-33 4-30 4-31 4-33 4-31 4-31 4-26 4-33 4-31 4-31 4-31 4-31 4-28 4-18...
- Page 20 XR-40X/XR-41X/XG-F260X PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] OPTICAL MECHANISM PARTS Fixing Metal LANGKB121WJFW Chassis LCHSKA024WJFW Holder LHLDZA845WJKZ For Focus Ring, x3 LX-EZA027WJFN Spring MSPRPA095WJFW Spring MSPRPA096WJFW Spring MSPRPA097WJFW NFANRA077WJ00 Cover PCOVPA036WJSA 4-10 PCOVPA038WJSA Cover 4-11 PCOVZA089WJFW Cover...
- Page 21 RANK MARK DELIVERY [4] SUPPLIED ACCESSORIES Lens Cap CCAPHA027WJSA GCASNA021WJSA Storage case (XR-41X/XG-F260X) AC Cord (for U.K and Singapore) QACCBA036WJPZ AC Cord (for U.S.A and Canada, etc.) QACCDA007WJPZ AC Cord (for Australia, New Zealand and Oceania) QACCLA018WJPZ AC Cord (for Europe, except U.K)
- Page 22 XR-40X/XR-41X/XG-F260X [5] PACKING PARTS (NOT REPLACEMENT ITEM) For XR-40X For XR-41X/XG-F260X...
- Page 23 Accessory Case SPAKFB224WJZZ Wrapping Paper SPAKPA869WJZZ Packing Add SPAKXB477WJZZ Polyethylene Bag SSAKA0160CEZZ Polyethylene Bag (for Storage case) (XR-41X/XG-F260X) SSAKAA097WJZZ TLABV0003SEZZ Model Name Label TLABVA333WJZZ Bar Code Label (for U.S.A, Canada) TLABVA493WJZZ Bar Code Label (for Europe, U.K) Recycle Label (for Europe except U.K) TLABZA610WJZZ C.W.Mark, x2 (for Europe and Singapore)
- Page 24 XR-40X/XR-41X/XG-F260X 2007 COPYRIGHT © 2006 BY SHARP CORPORATION ALL RIGHTS RESERVED. No Part of this publication may be reproduced, stored in a retrieval system, or transmitted in any from or by any means, electronic, mechanical, photocopying , recording, or otherwise, without prior written permission of the publisher.
