Summary of Contents for Synology DVA3219
- Page 1 Synology Network Video Recorder DVA3219 Hardware Installation Guide...
-
Page 2: Table Of Contents
Table of Contents Chapter 1: Before You Start Package Contents Synology Network Video Recorder at a Glance Safety Instructions Chapter 2: Hardware Setup Tools and Parts for Drive Installation Install Drives Start Up Your Network Video Recorder Add a RAM Module on Network Video Recorder... -
Page 3: Chapter 1: Before You Start
Chapter Before You Start Thank you for purchasing this Synology product! Before setting up your new Network Video Recorder, please check the package contents to verify that you have received the items below. Also, make sure to read the safety instructions carefully to avoid harming yourself or damaging your Network Video Recorder. -
Page 4: Synology Network Video Recorder At A Glance
Network Video Recorder to “Not Installed” status so that DiskStation Manager (DSM) can be reinstalled. For more information about Synology Expansion Unit supported by your Network Video Recorder, please visit www.synology.com. 4 Chapter 1: Before You Start... -
Page 5: Safety Instructions
Safety Instructions Keep away from direct sunlight and away from chemicals. Make sure the environment does not experience abrupt changes in temperature or humidity. Place the product right side up at all times. Do not place near any liquids. Before cleaning, unplug the power cord. Wipe with damp paper towels. Do not use chemical or aerosol cleaners. -
Page 6: Chapter 2: Hardware Setup
Tools and Parts for Drive Installation • A screwdriver (only for 2.5" drives) • At least one 3.5” or 2.5” SATA drive (please visit www.synology.com for compatible drive models.) Warning: If you install a drive that contains data, the system will format the drive and erase all existing data. Please back up any important data before installation. - Page 7 3 Load drives in the drive trays. • For 3.5” drives: Remove the fastening panels from the sides of the drive tray. Place the drive in the drive tray. Then insert the fastening panels to secure the drive in place. •...
- Page 8 4 Push the upper part of the loaded hard drive tray and insert it into the empty hard drive bay. Make sure the tray is pushed in all the way. Otherwise, the drive might not be able to function properly. Note: 5 Press the handle in flush with the front panel to hold the hard drive tray in place.
-
Page 9: Start Up Your Network Video Recorder
Start Up Your Network Video Recorder 1 Use the LAN cable to connect the Network Video Recorder to your switch, router or hub. 2 Connect the AC adapter to the power port of the Network Video Recorder. Connect one end of the AC power cord to the AC power adapter, and the other to the power outlet. -
Page 10: Add A Ram Module On Network Video Recorder
Add a RAM Module on Network Video Recorder The optional Synology DDR4 RAM module is designed for Network Video Recorder memory expansion. Follow the steps below to install, check, or remove a RAM module on your Network Video Recorder. To install the RAM module: 1 Shut down your Network Video Recorder. - Page 11 This behavior is normal and will only occur once. • Synology will not provide complete product warranty or technical support if non-Synology RAM modules are used for memory upgrade. 5 Replace the bottom panel. Replace and tighten the 2 screws you removed in step 3.
- Page 12 To remove the RAM Module: 1 Follow step 1 to 3 of the "To install the RAM module" section to shut down your Network Video Recorder, disconnect the cables, and then remove the bottom panel. 2 Push the levers on both sides of the memory module outwards. The module will be released from the slot. 3 Hold the memory module by its notches and remove it from the slot.
-
Page 13: Replace System Fan
Replace System Fan Your Network Video Recorder will beep if the system fan is not working. Follow the steps below to replace the malfunctioning fan with a good one. To replace the system fan: 1 Shut down your Network Video Recorder and disconnect all connected cables to prevent any possible damages. - Page 14 c Remove the 4 screws that secure the malfunctioning fan, and then remove the fan. 4 Install the new fan: a Replace the malfunctioning fan with a good one (with the fan cable within the fan pointing at the bottom-right corner), and then tighten the 4 screws to secure the new fan.
-
Page 15: Chapter 3: Install Dsm On Network Video Recorder
Chapter Install DSM on Network Video Recorder After hardware setup is finished, please install DiskStation Manager (DSM) – Synology’s web-based operating system – on your Network Video Recorder. Install DSM with Web Assistant Your Network Video Recorder comes with a built-in tool called... - Page 16 • Basic • JBOD • RAID 0 • RAID 1 Supported RAID Types • RAID 5 • RAID 6 • RAID 10 • Synology Hybrid RAID (Up to 2-Disk Fault Tolerance) Agency Certifications • FCC Class B • CE Class B • BSMI Class B...
-
Page 17: Appendix B: Led Indicator Table
Please try to restart your Network Video Recorder or re-insert the drive(s), and then run the HDD/SSD manufacturer's diagnostic tool to check the health status of the drive(s). If you can log into DSM, please run the built-in S.M.A.R.T. test to scan the drive(s). If the problem remains unresolved, please contact Synology Technical Support for help. - Page 18 Section 5. License Limitations. The license set forth in Sections 1, 2 and 3 applies only to the extent that you have ordered and paid for the Product and states the entirety of your rights with respect to the Software. Synology reserves all rights not expressly granted to you in this EULA.
- Page 19 Arbitration Law and related enforcement rules of the country in which Synology Inc. was organized. In such cases, the arbitration will be limited solely to the dispute between you and Synology. The arbitration, or any portion of it, will not be consolidated with any other arbitration and will not be conducted on a class-wide or class action basis.
- Page 20 Section 3. Limited Warranty and Remedies 3.1 Limited Warranty. Subject to Section 3.2, Synology warrants to the Customer that each Product (a) will be free of material defects in workmanship and (b) under normal use will perform substantially in accordance with Synology's published specifications for the Product during the Warranty Period.
- Page 21 Section 4. Limitations of Liability 4.1 Force Majeure. Synology will not be liable for, or be considered to be in breach of or default under this Warranty on account of, any delay or failure to perform as required by this Warranty as a result of any cause or condition beyond its reasonable control (including, without limitation, any act or failure to act by Customer).
- Page 22 Association, except as otherwise provided below. The arbitration will be conducted before a single arbitrator, and will be limited solely to the dispute between Customer and Synology. The arbitration, or any portion of it, will not be consolidated with any other arbitration and will not be conducted on a class-wide or class action basis.
- Page 23 FCC Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 24 この装置は、クラス B 機器です。この装置は、住宅環境で使用することを 目的 としていますが、この装置がラジオやテレビジョン受信機に近接して使 用され ると、受信障害を引き起こすことがあります。 取扱説明書に従って正しい取り扱いをして下さい。 VCCI 一 B...
