Beam Walker, Easy Slider
4"-14" BEAM 5000lb rated
Model # ST14SH
WARNING:
ALL PERSONS USING THIS EQUIPMENT MUST
READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO
SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD
BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS
EQUIPMENT. ALL INDIVIDUALS WHO USE THIS PRODUCT MUST
BE PROPERLY INSTRUCTED ON HOW TO USE THE DEVICE. AVOID
CONTACT WITH PHYSICAL HAZARDS (THERMAL, CHEMICAL,
ELECTRICAL, ETC.). MAKE ONLY COMPATIBLE CONNECTIONS.
Patent # US 8,312,966 / 8,646,575
V3.1-A
Advertisement
Table of Contents
Related Manuals for FrontLine ST14SH
Summary of Contents for FrontLine ST14SH
- Page 1 Beam Walker, Easy Slider 4”-14” BEAM 5000lb rated Model # ST14SH WARNING: ALL PERSONS USING THIS EQUIPMENT MUST READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS EQUIPMENT.
- Page 2 PURPOSE The ST14SH is an anchorage connector designed to function as an interface between the anchorage and a fall protection, work positioning, rope access, or rescue system for the purpose of coupling the system to the anchorage. Any references to “anchorage connector”...
- Page 3 PERFORMANCE: REGULATORY COMPLIANCE: Static Tensile Strength: 5000-lbf (22kN) ANSI Z359.18 Type A, ANSI Z359.7-2011, Maximum Capacity: One worker with max OSHA 1926.502, OSHA 1910.66, weight of 310-lbs when used as a single COMPONENT MATERIALS: point anchorage connector for personal fall Aluminum: Cross Bar arrest or restraint system Bronze: Clamps...
- Page 4 LOADING CONDITIONS DIAGRAM Placement at or below a user’s working height requires integration of a compatible ANSI Z359.1 shock-absorbing lanyard that does not allow the user to extend more than 6 feet (in any direction) from the anchorage connector before the shock absorber is activated. The beam anchor must be attached to the I-beam flange facing the user (top flange if above, bottom flange if below, etc.).
- Page 5 *The user shall be equipped with a means of limiting the maximum dynamic forces exerted on the user during the arrest of a fall to a maximum of 8 kN (1800-lbf ). In the EU these forces must be limited to 6 kN (1350-lbf ). (ANCHOR POINT) WORK SURFACE Inspect retaining...
- Page 6 WARNING LABEL LOCATIONS MFG:YYYYMMDD BREAKING STRENGTH: 5000 lbf (22.2 kN) MFG: YYYY/MM/DD WARNING: All persons using this equipment must read, understand and follow all instructions. Failure to do so could result in serious injury or death. Compliance: OSHA 1926.502, OSHA 1910.66, ANSI Z359.18 Type A, ANSI Z359.7(11) WARNING: ALL PERSONS USING THIS EQUIPMENT MUST READ AND UNDERSTAND ALL INSTRUCTIONS.
- Page 7 MAINTENANCE, CLEANING AND STORAGE Cleaning periodically will prolong the life and proper functioning of the product. The frequency of cleaning should be determined by inspection and by severity of the environment. Clean with compressed air and/or a stiff brush using plain water or a mild soap and water solution. Do not use any corrosive chemicals that could damage the product.
- Page 8 Warranty does not cover equipment damage resulting from wear, abuse, damage in transit, failure to maintain the product or other damage beyond the control of Frontline Fall Protection. Frontline Fall Protection shall be the sole judge of product condition and warranty options. This warranty applies only to original purchaser and is the only warranty applicable to this product.
