OPERATION AND INSTRUCTION MANUAL
Swivel Anchor Model: COM3410K, STM5810K
and STMP10K-WO + STM10K-SA
Patent # US 8,424,638
WARNING:
ALL PERSONS USING THIS EQUIPMENT MUST
READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO
SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD
BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS
EQUIPMENT. ALL INDIVIDUALS WHO USE THIS PRODUCT MUST
BE PROPERLY INSTRUCTED ON HOW TO USE THE DEVICE. AVOID
CONTACT WITH PHYSICAL HAZARDS (THERMAL, CHEMICAL,
ELECTRICAL, ETC.). MAKE ONLY COMPATIBLE CONNECTIONS.
V4.7-A
Advertisement
Related Manuals for FrontLine STMP10K-WO
Summary of Contents for FrontLine STMP10K-WO
- Page 1 OPERATION AND INSTRUCTION MANUAL Swivel Anchor Model: COM3410K, STM5810K and STMP10K-WO + STM10K-SA WARNING: ALL PERSONS USING THIS EQUIPMENT MUST READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS EQUIPMENT.
- Page 2 Read This Instruction Manual Carefully Before Using This Equipment. User Instructions must always be available to the user and are not to be removed except by the user of this equipment. For proper use, see supervisor, User Instructions, or contact the manufacturer. Compliant fall protection and emergency rescue systems help prevent serious injury during fall arrest.
- Page 3 LABEL LOCATIONS 180° 2.25”ø 8”ø (57.15mm) (203.2mm) 5.5” (139.7mm) 360° 3” 1” (76.2mm) (25.4mm) Tensile Strength (UTS): 10,000-lbf (44kN) Working Load: 2,000-lbs (907kg) Weight: 1.2-lbs (544.3g) Materials: Zinc Plated Steel Regulatory Compliance: Meets or exceeds ANSI Z359.18 Type A, ANSI Z359.7-2011 OSHA 1926.502 LOADING CONDITIONS DIAGRAM LOAD...
- Page 4 STEEL MOUNTING 1. Use a proper drill and bit for steel. 2. Drill a 5/8” (16mm) hole no less than .75” (6mm) deep 3” (76mm) away from any edge. 3. Hole must be straight and perpendicular to surface. 4. Hole must be free of debris. 5/8”-11 Lock Nut 5/8”...
-
Page 5: Concrete Mounting
CONCRETE MOUNTING 1. Use a proper drill and bit for concrete (SDS drill bit). 2. Drill a .75” (19mm) hole no less than 5” (114mm) deep 9” (229mm) away from any edge. 3. Hole must be straight & perpendicular to surface. 4. - Page 6 WELD ON MOUNTING Grade - 5 or 8 bolt 5/8”-11 x 1-3/4” Internal Tooth Lock Washer Torque Range: 75 to 90 ft-lbs (100-120Nm) Weld Puck * Weld (AISI 1018) 3/8” min (9.5mm) * Welding procedure must be approved by an engineer or other qualified person to be compatible with any and all structural &...
- Page 7 STRAIGHT LOOP INSERT See Straight Loop Insert Manual for anchorage casting instructions. 1. Strip decking to expose the Straight Loop Insert. 2. Ensure that anchorage was properly installed. Orange indicator should be flush with concrete surface, and at least 9” from any edge or corner. Concrete should be at least 6”...
- Page 8 *The user shall be equipped with a means of limiting the maximum dynamic forces exerted on the user during the arrest of a fall to a maximum of 8 kN (1800-lbf ). In the EU these forces must be limited to 6 kN (1350-lbf.) (ANCHOR POINT) WORK SURFACE *The structure the...
- Page 9 KIT CONTENTS PART NUMBER STM5810KRB (Steel Mounting Hardware Kit) STM5810K (Swivel with Steel Mounting kit) Call for more info. (Straight Loop Insert Mounting Kit) Call for more info. (Swivel with Straight Loop Insert Mounting kit) COM3410KRB (Concrete Hardware Kit) COM3410K (Swivel with Concrete Mounting Kit) Call for more info.
-
Page 10: Inspection And Maintenance Log
MAINTENANCE, CLEANING AND STORAGE Cleaning periodically will prolong the life and proper functioning of the product. The frequency of cleaning should be determined by inspection and by severity of the environment. Clean with compressed air and/or a stiff brush using plain water or a mild soap and water solution. Do not use any corrosive chemicals that could damage the product. - Page 11 NOTES...
- Page 12 Warranty does not cover equipment damage resulting from wear, abuse, damage in transit, failure to maintain the product or other damage beyond the control of Frontline Fall Protection. Frontline Fall Protection shall be the sole judge of product condition and warranty options. This warranty applies only to original purchaser and is the only warranty applicable to this product.
