INSTALLATION &
OPERATION MANUAL
IS SERIES
OVENS *
MODELS:
750-IS
1000-IS
1200-IS
1400-IS
RT SERIES
OVENS *
MODELS:
RT-32-IS
RT-32-COR
*
Manufactured 2010
For additional information on Wittco or to locate an authorized parts
and service provider in your area, visit our website at
www.wittco.com
WITTCO FOODSERVICE EQUIPMENT
7737 NORTH 81 STREET
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
MILWAUKEE, WI 53223
www.wittco.com
F-41163 (07-12)
©2012 Wittco Foodservice Equipment
Advertisement
Table of Contents
Related Manuals for Wittco IS Series
Summary of Contents for Wittco IS Series
- Page 1 OVENS * MODELS: RT-32-IS RT-32-COR Manufactured 2010 For additional information on Wittco or to locate an authorized parts and service provider in your area, visit our website at www.wittco.com WITTCO FOODSERVICE EQUIPMENT 7737 NORTH 81 STREET DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC MILWAUKEE, WI 53223 www.wittco.com...
-
Page 2: Important For Your Safety
IS & RT SERIES OVENS F-41163 (07-12) IMPORTANT FOR YOUR SAFETY THIS MANUAL HAS BEEN PREPARED FOR PERSONNEL QUALIFIED TO INSTALL ELECTRICAL EQUIPMENT, WHO SHOULD PERFORM THE INITIAL FIELD START- UP AND ADJUSTMENTS OF THE EQUIPMENT COVERED BY THIS MANUAL. FOR YOUR SAFETY DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS OR LIQUIDS IN THE... -
Page 3: Table Of Contents
IS & RT SERIES OVENS F-41163 (07-12) TABLE OF CONTENTS IMPORTANT FOR YOUR SAFETY ........1 GENERAL . -
Page 4: General
The principles of Low satisfactory performance. Temperature Cooking and Holding can be summarized into several objectives: The Wittco Cook & Hold Oven is more increased product yields, increased than just an oven – it’s a “System”; profits from increased... -
Page 5: Benefits Of Cook & Hold Ovens
“You can taste the difference.” Can bake anything from meat, Reduced Energy Costs: It costs poultry, fish, cakes, cookies, puff significantly less to run a Wittco Cook & pastries, and even popovers. hold Oven instead of a conventional... -
Page 6: Installation
Refer to do not proceed with unpacking and cleaning instructions in this manual. installation. Contact your Wittco Customer Service Department LOCATION: immediately. For efficient oven operation, choose a location that will provide easy loading... -
Page 7: Electrical Requirements
IS & RT SERIES OVENS F-41163 (07-12) RT TOP VIEW MOUNTING BRACKETS (2 per side) MOUNTING BRACKETS RT SIDE VIEW Fig. 2 B Fig. 2 A ELECTRICAL REQUIREMENTS ELECTRICAL CODES & STANDARDS: ELECTRICAL CONNECTIONS: The oven is factory wired for single oven must installed... -
Page 8: Operation
IS & RT SERIES OVENS F-41163 (07-12) OPERATION ADJ / SET CONTROLS ADJ / SET Knob allows Adjustment and Setting changes. The Oven and its parts are hot. Be very careful when operating, START cleaning, or servicing the oven. Start Button will start the operation or pre-set settings. -
Page 9: Setting Adjustment
IS & RT SERIES OVENS F-41163 (07-12) Turn ADJ/SET Knob to desired PRE-PROGRAMMED CYCLES cook temperature. The Oven can be programmed for 9 Push ADJ/SET Knob to set cooking/holding cycles. To program cooking temperature. each cycle, P-1 through 9, use the following instructions. -
Page 10: Testing The Oven
IS & RT SERIES OVENS F-41163 (07-12) Rotate the ADJ/SET Knob to desired holding temperature. The oven has cooling/exhaust fans located at the left side of the unit. Press the ADJ/SET Knob to These fans may not operate when the accept Hold Temp. -
Page 11: Err Too Hot - Alarm
IS & RT SERIES OVENS F-41163 (07-12) ERR TOO HOT – ALARM SHUTDOWN oven reports “Over The Oven and its parts are hot. Be very careful when operating, Temperature Condition” any time the cleaning, or servicing the oven. oven temperature reaches 400⁰F or higher. -
Page 12: Maintenance
IS & RT SERIES OVENS F-41163 (07-12) MAINTENANCE HEAVY-DUTY CLEANING: CLEANING For heavy-duty cleaning, use warm water, a degreaser, and a plastic, The Oven and its parts stainless steel, or scotch-brite pad. are hot. Be very careful when operating, Never rub in a circular motion. Always cleaning, or servicing the oven. -
Page 13: Door Gasket Care
IS & RT SERIES OVENS F-41163 (07-12) Never use steel wool – which unsightly, but is not a sign of permanent will leave behind particles that will damage. rust. To remove heat tint, follow the routine Never acid-based cleaning procedure. Stubborn heat tint chloride containing cleaning will require heavy-duty cleaning. -
Page 14: Cooking
Gastronome) and the product which is This cooking guide has been produced to be cooked and held is placed on top for your Wittco Cook & Hold Oven of the cooking rack. When more than System. It should be used as a handy one product is being prepared, the food reference when using your oven. -
Page 15: Bakery Products
IS & RT SERIES OVENS F-41163 (07-12) Proof yeast products about 50% BAKERY PRODUCTS less than usual. The Cook & Hold Oven System is much Rotate pans, when product is more than a prime rib oven. Unlike our about ½ done, as you would with competitors, you can do a full range of any oven. -
Page 16: Cooking And Holding Guide
IS & RT SERIES OVENS F-41163 (07-12) COOKING AND HOLDING GUIDE Please note that as products vary, as well as other elements such as altitude, so shall actual cooking times and temperatures. These should be adjusted as needed based upon your actual experience. Finished product temperatures should be verified manually, prior to serving, in order to insure food safety. - Page 17 IS & RT SERIES OVENS F-41163 (07-12) MAX. (DETAILS) COOK COOK HOLD INTERNAL LOADING PRODUCT WEIGHT TIME TEMP. HOLD TIME TEMP. TEMP. GUIDELINES Chicken Wings 150⁰ F 165⁰ F 10 lbs. 45 min. 350⁰ F 10 lbs. per shelf Chicken Pieces 150⁰...
-
Page 18: Rethermalization Guide
IS & RT SERIES OVENS F-41163 (07-12) RETHERMALIZATION GUIDE OVEN REHEAT HOLD MIN. HOLD ENTRÉE TEMP. TIME TEMP. TIME 225⁰F 160⁰F Baked Rotini 60 min. 20 min. Beef & Noodles 225⁰F 54 min. 160⁰F 20 min. 225⁰F 165⁰F Breaded Chicken Pattie on Bun 60 min. -
Page 19: Grams - Lbs / Oz Conversions
IS & RT SERIES OVENS F-41163 (07-12) -
Page 20: Temperatures
IS & RT SERIES OVENS F-41163 (07-12) -
Page 21: Lockout / Tagout Procedure
SERVICE & PARTS INFORMATION To obtain Service and Parts information concerning this model, contact Wittco Service Department at the address listed on the front cover of this manual or refer to our website: www.wittco.com... -
Page 22: Troubleshooting
IS & RT SERIES OVENS F-41163 (07-12) TROUBLESHOOTING SYMPTOMS POSSIBLE CAUSES REMEDY Oven not connected to Connect oven to power power source source ON/OFF switch not Press Power ON/OFF switch Oven not operating to ON No power Check circuit breaker This is normal when unit is cold. -
Page 23: Specifications
IS & RT SERIES OVENS F-41163 (07-12) SPECIFICATIONS SHIP MODEL WEIGHT QTY. PAN SIZE HEIGHT WIDTH DEPTH VOLTS (Approx.) WATTS AMPS 5 ea. 18" x 26" 1900 35¼" 25¾" 37¼" 233# 750-IS 947 mm 106 kg. 8 mm 10 ea. 12"x20"x2½... -
Page 24: Wiring Diagram
IS & RT SERIES OVENS F-41163 (07-12) WIRING DIAGRAM All Models with Contactors (Elements & Motors Vary) - Page 25 IS & RT SERIES OVENS F-41163 (07-12) All Models without Contactors (Elements & Motors Vary)
