EH-LS650B/EH-LS650W User's Guide

Advertisement

Table of Contents
loading

Related Manuals for Epson EH-LS650B

Summary of Contents for Epson EH-LS650B

  • Page 1 EH-LS650B/EH-LS650W User's Guide...

  • Page 3: Table Of Contents

    Contents EH-LS650B/EH-LS650W User's Guide ....................... 9 Introduction to Your Projector ......................... 10 Projector Features..........................10 Product Box Contents........................11 Additional Components ........................ 11 Optional Equipment and Replacement Parts................. 12 Warranty and Registration Information (U.S. and Canada) ............13 Warranty and Registration Information (Latin America)..............13 Notations Used in the Documentation ....................
  • Page 4 Using Basic Projector Features ....................... 38 Turning On the Projector ........................38 Using the Home Screen......................... 40 Turning Off the Projector ........................41 Focusing the Image..........................41 Adjusting the Front Feet ........................43 Image Shape............................43 Correcting Image Distortion Using the Installation Menu ............... 44 Adjusting Image Color when Projecting onto a Wall ................
  • Page 5 Projector Security Features........................ 67 Installing a Security Cable ......................67 Updating the Firmware ........................67 Resetting the Projector........................68 Adjusting the Menu Settings ........................70 Using the Projector's Menus....................... 70 Image Quality Settings - Picture Menu ....................71 Sound Quality Settings - Sound Menu....................75 Projector Installation Settings - Installation Menu................
  • Page 6 Solutions When the Image is Flipped or Too Small ..............101 Solutions When the Image is Fuzzy or Blurry ................101 Solutions When the Image Brightness or Colors are Incorrect ............ 102 Solutions to Sound Problems ...................... 103 Solutions to Bluetooth Audio Problems ..................104 Solving Projector or Remote Control Operation Problems ...............
  • Page 7 Copyright Notice..........................138 A Note Concerning Responsible Use of Copyrighted Materials........... 139 Copyright Attribution ........................139...

  • Page 9: Eh-Ls650B/Eh-Ls650W User's Guide

    EH-LS650B/EH-LS650W User's Guide Welcome to the EH-LS650B/EH-LS650W User's Guide. For a printable PDF copy of this guide, click here. Note: Availability of products in this guide varies by country.

  • Page 10: Introduction To Your Projector

    Additional Projector Software and Manuals Projector Part Locations Projector Features The EH-LS650B/EH-LS650W projector includes these special features: Bright, high-resolution projection system • Up to 3600 lumens of color brightness (color light output) and white brightness (white light output) Note: Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions.

  • Page 11: Product Box Contents

    Additional Components Optional Equipment and Replacement Parts Warranty and Registration Information (U.S. and Canada) Warranty and Registration Information (Latin America) Parent topic: Introduction to Your Projector Product Box Contents Save all the packaging in case you need to ship the projector. Always use the original packaging (or equivalent) when shipping.

  • Page 12: Optional Equipment And Replacement Parts

    This allows you to mirror your smartphone or tablet screens, watch movies, and more. Contact your device manufacturer for compatible adapter options. Unless listed as available from Epson in this table, see your local computer or electronics dealer for purchase information.

  • Page 13: Warranty And Registration Information (U.s. And Canada)

    Epson offers the following optional accessories and replacement parts for your projector: U.S. and Canada: Option or part Part number Replacement air filter (ELPAF60) V13H134A60 Ultra Short Throw Screen 100" (ELPSC35) V12H002AL0 Ultra Short Throw Screen 120" (ELPSC36) V12H002AM0 In addition to the accessories listed above, extended service plans are available.

  • Page 14: Notations Used In The Documentation

    • If you still need help after checking this manual and any other sources listed here, you can use the Epson PrivateLine Support service to get help fast (U.S. and Canada only). For details, see "Where to Get Help."...

  • Page 15: Projector Part Locations

    Note: If you still need help after checking this manual and the sources listed here, you can use the Epson PrivateLine Support service to get help fast (U.S. and Canada only). For details, see "Where to Get Help." Projector software...

  • Page 16: Projector Parts - Front/Top

    Projector Parts - Front/Top Front adjustable feet (turn the feet to adjust the horizontal tilt) Remote receiver (receives signals from the remote control) Speaker (outputs audio) Focus lever cover (open to access the focus lever) Air filter cover (open to access the air filter) Power button (turns the projector on or off) Status light (indicates the projector's status) Parent topic:...

  • Page 17: Projector Parts - Top/Side

    Projector Parts - Top/Side Motion sensor (detects movement near the projection window and reduces the brightness of the light source for safety) Note: The detection range may vary depending on the temperature in the surrounding environment. Movement may not be detectable through glass or other transparent materials. Projection window (images are projected from the lens inside the projector) Kensington security slot Air exhaust vent (cools the projector internally)

  • Page 18: Projector Parts - Rear

    Projector Parts - Rear USB-A port (for connecting an external USB device (such as a webcam, external HDD, or keyboard) or an RJ45 adapter to enable wired LAN connections) HDMI1/HDMI2 (eARC/ARC) ports (inputs video signals from HDMI compatible video equipment and computers) Note: This product is compatible with HDCP 2.3.

  • Page 19: Projector Parts - Base

    Power inlet (connects the power cord to the projector) Parent topic: Projector Part Locations Related concepts Projector Connections Projector Parts - Base Rear foot (provides stability when projecting on a flat surface) Air intake vent (air filter) (takes in air to cool the projector internally) Front adjustable feet (turn the feet to adjust the horizontal tilt) Air intake vent (takes in air to cool the projector internally) Parent topic:...

  • Page 20: Projector Parts - Remote Control

    Projector Parts - Remote Control...
  • Page 21 Microphone (listens for voice commands after pressing the mic button) power button apps button (displays available Android TV apps) Directional pad (move through on-screen options) esc button (cancels/exits function) Brightness up and brightness down buttons blank button (turns off picture) Corner Adjustment button (displays the Corner Adjustment screen to adjust the image shape) Flexible Picture menu button (opens Flexible Picture menu) mute button (turns off sound)

  • Page 22: Setting Up The Projector

    Setting Up the Projector Follow the instructions in these sections to set up your projector for use. Projector Placement Projector Connections Installing Batteries in the Remote Control Setting Up Android TV Projector Placement You can place the projector on almost any flat surface to project an image. Warning: The projector is not intended to be ceiling- or wall-mounted.

  • Page 23: Projector Setup And Installation Options

    • If you are using the projector at altitudes above 4921 feet (1500 m), set the High Altitude Mode setting to On in the projector's Settings menu to ensure the projector's internal temperature is regulated properly. Projector Setup and Installation Options Projection Distance Parent topic: Setting Up the Projector...

  • Page 24: Projection Distance

    Be sure to leave the following amount of space around the projector so as to not block the air exhaust or intake vents. 3.9 inches (10 cm) 12 inches (30 cm) Parent topic: Projector Placement Projection Distance The distance at which you place the projector from the screen determines the approximate size of the image.
  • Page 25 You can also use the Projection Distance Calculator here (U.S.), here (Canada), or here (Caribbean). Projection distance (from image to rear of projector) Distance from projector to the bottom of the screen Distance from projector to the top of the screen...
  • Page 26 12.13 inches (30.83 cm) (distance from the center of the lens to the rear of the projector) Note: The distance from the table surface to the top of the projector is 6.22 inches (15.8 cm). 16:9 Aspect Ratio Image or Screen Screen or image size Projection distance (1) Offset from top of Offset from top of...

  • Page 27: Projector Connections

    16:10 Aspect Ratio Image or Screen Screen or image size Projection distance (1) Offset from top of Offset from top of projector (2) projector (3) 56 inches (142.2 cm) 12.9 inches (32.8 cm) 4.6 inches (11.7 cm) 34.3 inches (87.1 cm) 60 inches (152.4 cm) 14 inches (35.6 cm) 5.1 inches (13 cm)

  • Page 28: Connecting To An Hdmi Video Source

    Related references Additional Components Projector Feature Settings - Settings Menu Connecting to an HDMI Video Source If your video source has an HDMI port, you can connect it to the projector using an optional HDMI cable. Caution: Do not turn on the video source before connecting it to the projector. Doing so could damage the projector.

  • Page 29: Connecting To A Usb Device

    Parent topic: Projector Connections Related references Projector Feature Settings - Settings Menu Connecting to a USB Device You can connect a USB device or cable to the projector's USB-A port to project images from the device. Use the USB cable supplied with the device. You may need to use an app that supports your file type on the projector to project the content from your USB device.

  • Page 30: Connecting To An Earc/Arc Compatible Av System

    The projector displays images stored on the USB device. Parent topic: Projector Connections Connecting to an eARC/ARC Compatible AV System If your external speakers or A/V receiver are HDMI ARC-compatible, you can connect them to the projector's HDMI2 (eARC/ARC) port using an optional HDMI cable. Make sure the HDMI CEC setting is enabled and then enable HDMI2 ARC.

  • Page 31: Connecting To External Speakers

    3. Select any HDMI control settings on the connected speakers or receiver, as necessary. See your device's documentation for more information. eARC/ARC Supported Audio Format • LPCM: 2ch (Max 48kHz/24bit) • Dolby Digital (AC-3) • Dolby Digital Plus • Dolby Atmos (eARC only) •...

  • Page 32: Connecting A Streaming Device

    4. Connect the optical digital audio connector end of the cable to your projector's Optical Out port. Note: Digital audio out volume levels cannot be controlled with the projector remote. To adjust the volume levels, use the volume controls on the external audio device instead. Parent topic: Projector Connections Connecting a Streaming Device...

  • Page 33: Connecting To A Bluetooth Audio Device

    2. Connect the device's USB power cable to the projector's DC Out (2.0A) USB power port. 3. Connect the other end of the cable to the streaming media player. Parent topic: Projector Connections Connecting to a Bluetooth Audio Device You can connect your projector to Bluetooth audio devices such as speakers or headphones to output audio.

  • Page 34: Installing Batteries In The Remote Control

    4. Turn on your device and start the pairing process on it. See the documentation supplied with the device for more information. Compatible devices are displayed on-screen when discovered by the projector. You cannot connect multiple devices by Bluetooth at the same time. 5.

  • Page 35: Setting Up Android Tv

    2. Insert the batteries with the + and – ends facing as shown. Warning: Make sure the batteries are inserted in the correct positions. If the batteries are not inserted correctly, they could explode or leak, causing a fire, injury, or damage to the product. 3.
  • Page 36 Note: A Google account is required to use certain features. Some apps require a paid subscription. After initial setup, you can change the settings by selecting the Android TV settings icon at the top right of the Android TV Home screen. 1.
  • Page 37 • Select Skip to use the projector without signing in to a Google account. 7. Follow the on-screen instructions to proceed with initial setup, selecting settings as desired. The Home screen is displayed when initial setup is completed. Parent topic: Setting Up the Projector...

  • Page 38: Using Basic Projector Features

    Using Basic Projector Features Follow the instructions in these sections to use your projector's basic features. Turning On the Projector Turning Off the Projector Focusing the Image Adjusting the Front Feet Image Shape Adjusting Image Color when Projecting onto a Wall Remote Control Operation Using Voice Commands to Control Your Projector Pairing the Remote Control...
  • Page 39 2. Connect the power cord to the projector's power inlet. 3. Plug the power cord into an electrical outlet. The projector enters standby mode. This means the projector is receiving power, but has not yet been turned on. 4. Press the power button on the projector or remote control to turn on the projector. The Status light flashes blue as the projector warms up.

  • Page 40: Using The Home Screen

    Note: If this is the first time you are turning on the projector, you need to pair the remote control and complete initial setup. Follow any on-screen instructions to complete the settings. Make sure to point the front of the remote at the front of the projector when attempting to pair the remote. Using the Home Screen Parent topic: Using Basic Projector Features...

  • Page 41: Turning Off The Projector

    Displays recommended content from your applications Note: The content of the Home screen may change depending on the Android TV version. Parent topic: Turning On the Projector Turning Off the Projector Before turning off the projector, shut down any computer connected to it so you can see the computer display during shutdown.
  • Page 42 2. Open the focus lever cover. 3. Raise or lower the focus lever to sharpen the image.

  • Page 43: Adjusting The Front Feet

    4. Close the focus lever cover. Parent topic: Using Basic Projector Features Adjusting the Front Feet If you are projecting from a table or other flat surface, you can adjust the image using the projector's adjustable feet. To adjust the image height, set the projector higher or lower while keeping it level and parallel to the screen.

  • Page 44: Correcting Image Distortion Using The Installation Menu

    To correct distortion more easily, you can use the Epson Setting Assistant app on a smartphone or tablet that has a camera function. You can download it from the Apple App Store or Google Play Store. Install the application by using the QR code displayed on the projected screen.

  • Page 45: Adjusting Image Color When Projecting Onto A Wall

    Parent topic: Image Shape Adjusting Image Color when Projecting onto a Wall When projecting onto a wall, you can use the preset color correction to compensate for the color of the wall. You can make other detailed color adjustments in the projector's Picture menu. 1.

  • Page 46: Remote Control Operation

    You see a screen like this: 4. Select the color that is closest to the color of the wall and select OK. Parent topic: Using Basic Projector Features Remote Control Operation The remote control lets you control the projector from almost anywhere in the room, up to 19.7 feet (6 m) away.

  • Page 47: Using Voice Commands To Control Your Projector

    ± 30° ± 15° Note: Avoid using the remote control in conditions with bright fluorescent lights or in direct sunlight, or the projector may not respond to commands. If you will not use the remote control for a long time, remove the batteries.

  • Page 48: Selecting An Image Source

    A message appears on the screen and the indicator stops blinking when the remote control is paired. Parent topic: Using Basic Projector Features Selecting an Image Source If you connected multiple image sources to the projector, such as a computer and DVD player, you may want to switch from one image source to the other.

  • Page 49: Image Aspect Ratio

    Related tasks Setting Up Android TV Image Aspect Ratio The projector can display images in different width-to-height ratios called aspect ratios. Normally the input signal from your video source determines the image's aspect ratio setting. However, for certain images you can change the aspect ratio to fit your screen. If you always want to use a particular aspect ratio for a certain video input source, you can select it using the projector's menus.

  • Page 50: Available Image Aspect Ratios

    3. Select the Picture menu and press Enter. 4. Select Aspect Ratio and press Enter. 5. Select the aspect ratio setting you want to use for your input signal and press Enter. 6. Press the esc button to exit the menus. Parent topic: Image Aspect Ratio Related references...

  • Page 51: Color Mode

    Note: Using the aspect ratio function to reduce, enlarge, or split the projected image for commercial purposes or for public viewing may infringe upon the rights of the copyright holder of that image based on copyright law. Aspect ratio setting Description Normal Displays images using the full projection area and maintains the...

  • Page 52: Available Color Modes

    4. Select the Picture menu and press Enter. 5. Select Color Mode and press Enter. 6. Use the directional pad to select a color mode setting and press Enter. 7. When you are finished, press esc. Parent topic: Color Mode Related references Image Quality Settings - Picture Menu Available Color Modes...

  • Page 53: Turning On Automatic Luminance Adjustment

    Color Mode Description Vivid Best for enjoying content in a bright environment Cinema Best for movies projected in a dark room with natural tone images Natural Best for projecting the image as-is (choose this mode when making color adjustments) Parent topic: Color Mode Turning On Automatic Luminance Adjustment You can turn on the Dynamic Contrast setting to automatically optimize the image luminance.

  • Page 54: Adjusting Image Quality In Detail

    4. Select the Dynamic Contrast setting and press Enter. 5. Select one of the following options and press Enter. • Normal to adjust brightness at the standard speed. • High Speed to adjust brightness as soon as the scene changes. 6.
  • Page 55 3. Select the Picture menu and press the Enter button. 4. Select Custom Settings and press the Enter button. 5. Adjust each setting in the projector's Picture menu, as necessary: • Adjust the Brightness setting to lighten or darken the color. •...

  • Page 56: Adjusting The Image Resolution

    Adjusting the Image Resolution You can adjust the image resolution to project a clear image with an emphatic texture and material feel. 1. Turn on the projector and switch to the image source you want to use. 2. Press the settings button on the remote control.

  • Page 57: Using Frame Interpolation

    Using Frame Interpolation You can use the projector's Frame Interpolation feature to smooth fast-moving video by comparing consecutive image frames and inserting an intermediate image frame between them. 1. Turn on the projector and switch to the input source you want to use. 2.

  • Page 58: Controlling The Volume With The Volume Buttons

    4. Select the Frame Interpolation setting and press Enter. 5. Select the level of interpolation and press Enter. 6. When you are finished, press the esc button to exit the menus. Parent topic: Using Basic Projector Features Controlling the Volume with the Volume Buttons You can use the Volume buttons on the remote control to adjust the volume of your projected content.
  • Page 59 3. Select the Sound menu and press Enter. 4. Select Sound Mode and press Enter. 5. Select a sound mode and press Enter. 6. Select any additional sound settings according to your listening environment. 7. When you are finished, press the esc button to exit the menus.

  • Page 60: Adjusting Projector Features

    Adjusting Projector Features Follow the instructions in these sections to use your projector's feature adjustments. Using the Projector as a Bluetooth Speaker Operating Connected Devices Using the HDMI Link Features Adjusting the Color Convergence (Panel Alignment) Muting the Sound Temporarily Shutting Off the Picture Temporarily Changing the Projected Image Using Flexible Picture Projector Security Features...

  • Page 61: Operating Connected Devices Using The Hdmi Link Features

    4. To exit Bluetooth Speaker mode, disable it from the projector's menu. Note: While the projector is in Bluetooth Speaker mode, you can connect input devices such as smartphones or tablets, but you cannot pair output devices such as headphones or external speakers.

  • Page 62: Adjusting The Color Convergence (Panel Alignment)

    2. Select the Settings menu and press Enter. 3. Select HDMI CEC and press Enter. 4. Select the HDMI CEC setting and press Enter to enable it, if necessary. 5. Select the following HDMI Link options as necessary: • Device Auto Power Off: select whether to automatically turn off the connected device when you turn off the projector.
  • Page 63 Note: You can adjust only the red or blue color convergence. Green is the standard color panel and cannot be adjusted. Note: Image quality may decline after you perform Panel Alignment. Note: Images for pixels that extend beyond the edge of the projected screen are not displayed. 1.
  • Page 64 7. Select the Pattern Color setting and choose one of the following as the grid color you want to use when making adjustments. (The available color varies depending on the Select Color setting.) • R/G/B to display the grid color in white. •...

  • Page 65: Muting The Sound Temporarily

    Muting the Sound Temporarily You can temporarily mute the sound from your projection. 1. Press the mute button on the remote control to temporarily mute the audio. The audio from the projection is interrupted. 2. To turn the audio back on, press the mute button again.
  • Page 66 • If you made the image smaller, use the directional pad on the remote control to change the position of the image. • Press the Flexible Picture menu button on the remote control to flip the image horizontally. Press the button again to flip the image back. •...

  • Page 67: Projector Security Features

    Projector Security Features You can secure your projector to deter theft or prevent unintended use by setting up the following security features: • Security cabling to physically cable the projector in place. Installing a Security Cable Parent topic: Adjusting Projector Features Installing a Security Cable You can use the security slot on the side of the projector to attach a Kensington lock.

  • Page 68: Resetting The Projector

    When the latest projector firmware is available, a notification is automatically displayed on the screen. Follow the on-screen instructions to update the firmware. 1. Press the apps button on the remote control. You see a menu like this: 2. Select Projector Firmware Update from the application list and press Enter. 3.
  • Page 69 Parent topic: Adjusting Projector Features...

  • Page 70: Adjusting The Menu Settings

    Adjusting the Menu Settings Follow the instructions in these sections to access the projector menu system and change projector settings. Using the Projector's Menus Image Quality Settings - Picture Menu Sound Quality Settings - Sound Menu Projector Installation Settings - Installation Menu Projector Feature Settings - Settings Menu Projector Information Settings - Information Menu Using the Projector's Menus...

  • Page 71: Image Quality Settings - Picture Menu

    4. Use the arrow and Enter buttons to adjust the menu settings as desired. 5. When you finish changing settings on a menu, press esc to exit the menus. Parent topic: Adjusting the Menu Settings Image Quality Settings - Picture Menu Settings on the Picture menu let you adjust the quality of your image for the input source you are currently using.
  • Page 72 Setting Options Description Color Temperature Varying levels available Sets the color temperature according to the selected color mode; lower values tint the image red, and higher values tint the image blue Noise Reduction Strong Reduces flickering in analog images Standard Weak Note: This setting is not available when Image Processing is set to...
  • Page 73 Setting Options Description Custom Settings Brightness Brightness: Lightens or darkens the overall image Contrast Saturation Note: This function is not available when the light source Tint brightness dims because the Sharpness surrounding temperature gets too high or when a problem has occurred.
  • Page 74 Setting Options Description HDMI Video Range Auto Sets the video range to match the setting of the device Full connected to the HDMI input port Limited Image Processing Fast Improves the response speed for images projected at high speed. Fine If you select Fast, the following functions are disabled to speed up the response speed.

  • Page 75: Sound Quality Settings - Sound Menu

    Sound Quality Settings - Sound Menu Settings on the Sound menu allow you to optimize the audio for a variety of projected content. You can select from presets or experiment with available modes.
  • Page 76 Setting Options Description Sound Mode Theatre Sets a sound mode for the projector's speakers based on the type of playback content (music, movie, etc.) Studio Theatre: Recreates the acoustic Stadium environment of a movie theatre with realistic and powerful sound. Concert TV: Ideal for watching news, Karaoke Mode...
  • Page 77 Setting Options Description Sound Space Right Adjusts the sound quality to suit your viewing position Center Left Sound Output Selects the sound output device and format for input sources Auto Note: If sound is not output correctly, select PCM. Speaker/Optical (PCM) or Speaker/Optical (Auto): outputs sound from the projector's speakers and to the Optical Out port in PCM (2 ch) format or...

  • Page 78: Projector Installation Settings - Installation Menu

    You can make the following corrections to the image shape and the projected image from this menu: • Quickly correct distortion in the projected image using the Epson Setting Assistant app • Correct the position of the four corners of the projected image or fine-tune point correction using the remote control •...

  • Page 79: Projector Feature Settings - Settings Menu

    • Select Adjust color to compensate the color of the projected image to match colored walls Note: When you use the Epson Setting Assistant app, the Flexible Picture settings are reset. Parent topic: Adjusting the Menu Settings Projector Feature Settings - Settings Menu Options on the Settings menu let you customize various projector features.
  • Page 80 Setting Options Description Menu Timer 0 to 240 seconds Sets the interval before automatically closing the projector's menu Indicators Allows for control of the indicator lights on the projector. If this setting is Off, the indicator lights on the projector are only lit when an error or warning occurs High Altitude Mode Regulates the projector’s...

  • Page 81: Projector Information Settings - Information Menu

    Setting Options Description Panel Alignment Panel Alignment Adjusts the color convergence (the alignment of the red and Select Color blue colors) in the projected Pattern Color image Panel Alignment: select On to correct color misalignment in the projected image Select Color: select the color to correct Pattern Color: selects the pattern used for color correction.
  • Page 82 Setting Options Description Projector Operation Log Sets whether or not to allow Information Epson to receive projector operation logs Parent topic: Adjusting the Menu Settings...

  • Page 83: Maintaining And Transporting The Projector

    The only parts you should replace are the air filter and remote control batteries. If any other part needs replacing, contact Epson or an authorized Epson servicer. This projector uses a sealed laser light source which does not need servicing and cannot be replaced.
  • Page 84 • To remove dust or smudges, gently wipe the projection window with clean and dry lens-cleaning paper. Caution: Do not wipe the projection window right after you turn off the projector or you may damage it. • If the projection window is dusty, blow off the dust and then wipe the projection window. Warning: Do not use any flammable gas sprays such as air dusters to blow off dust.

  • Page 85: Cleaning The Motion Sensor

    Cleaning the Motion Sensor Clean the projector's motion sensor periodically, or if you see a message telling you to remove any obstacles that are interfering with the projection area. To remove dust or smudges, gently wipe the sensor with lens-cleaning paper. Warning: Do not use a lens cleaner that contains flammable gas to clean the motion sensor.

  • Page 86: Air Filter And Vent Maintenance

    Filter maintenance intervals will depend on the environment. If regular maintenance is not performed, your Epson projector will notify you when the temperature inside the projector has reached a high level. Do not wait until this warning appears to maintain your projector filter as prolonged exposure to high temperatures may reduce the life of your projector or laser.
  • Page 87 2. Slide the air filter cover latch and pull out the air filter cover. 3. Pull the air filter out of the projector.
  • Page 88 4. Vacuum the front of the air filter (the side with the tabs) to remove any remaining dust. Caution: Do not rinse the air filter in water, or use any detergent or solvent to clean it. Do not use canned air; the gases may leave a flammable residue, or push dust and debris into the projector's optics or other sensitive areas.

  • Page 89: Replacing The Air Filter

    Parent topic: Air Filter and Vent Maintenance Related references Optional Equipment and Replacement Parts Related tasks Turning Off the Projector Replacing the Air Filter You need to replace the air filter in the following situations: • After cleaning the air filter, you see a message telling you to clean or replace it •...
  • Page 90 3. Pull the air filter out of the projector. Note: Air filters contain polypropylene. Dispose of used air filters according to local regulations. 4. Place the new air filter in the projector as shown (with the four tabs facing down). Caution: Do not try to force the air filter cover closed if the tabs of the air filter are facing up.

  • Page 91: Cleaning The Air Vents

    Cleaning the Air Vents Clean the projector's air vents if they get dusty, or if you see a message telling you to clean them. 1. Turn off the projector and unplug the power cord. 2. Turn the projector upside down. 3.
  • Page 92 Caution: Use only the type of batteries specified in this manual. Do not install batteries of different types, or mix new and old batteries. 1. Open the battery cover as shown. 2. Remove the old batteries. Warning: If the battery fluid has leaked, wipe it away with a soft cloth and avoid getting the fluid on your hands.

  • Page 93: Transporting The Projector

    • When shipping the projector for repairs, place it in its original packing materials, if possible, or use equivalent materials with cushioning around the projector. Mark the box "Fragile." Note: Epson shall not be liable for any damages incurred during transportation. Parent topic:...

  • Page 94: Solving Problems

    If none of these solutions help, you can contact Epson for technical support. Note: After repairing the projector, Epson may return the projector to you in its initial status. Make sure you make a note of the account information of each online service before you contact your local dealer or the nearest Epson repair center.

  • Page 95: Projector Light Status

    Replacing the Air Filter Projector Light Status The light on the projector indicates the projector status and lets you know when a problem occurs. Check the status and color of the light and look for a solution in the table here. Status light Status light Status and solution...

  • Page 96: Solving Image Or Sound Problems

    • Clean or replace the air filter. • If operating the projector at high altitude, turn on High Altitude Mode. • If the problem persists, unplug the projector and contact Epson for help. Movement detection warning. A beep sounds and a warning message is displayed.

  • Page 97: Solutions When No Image Appears

    Solutions When No Image Appears Solutions When "No Signal" Message Appears Solutions When Only a Partial Image Appears Solutions When the Image is Not Rectangular Solutions When the Image Contains Noise or Static Solutions When the Image is Flipped or Too Small Solutions When the Image is Fuzzy or Blurry Solutions When the Image Brightness or Colors are Incorrect Solutions to Sound Problems...

  • Page 98: Solutions When "No Signal" Message Appears

    • Make sure the computer's display resolution does not exceed the projector's resolution and frequency limits. If necessary, select a different display resolution for your computer. (See your computer manual for details.) • If you are trying to view online content, make sure you have an active Internet connection. •...

  • Page 99: Displaying From A Pc Laptop

    Displaying From a PC Laptop Displaying From a Mac Laptop Parent topic: Solving Image or Sound Problems Related concepts Projector Connections Related tasks Selecting an Image Source Displaying From a PC Laptop If you see the "No Signal" message when you display from a PC laptop, you need to set up the laptop to display on an external monitor.

  • Page 100: Solutions When Only A Partial Image Appears

    Solutions When Only a Partial Image Appears If only a partial computer image appears, try the following solutions: • If Aspect Ratio in the Picture menu is set to Zoom, change it to Normal. • If you adjusted the size of the projected image, press the Flexible Picture menubutton on the remote control to display the Flexible Picture menu, and then press the brightness up button until the...

  • Page 101: Solutions When The Image Is Flipped Or Too Small

    • Not connected to an extension cable • Adjust the Noise Reduction setting in the projector's Picture menu. • Select a computer video resolution and refresh rate that are compatible with the projector. • If you adjusted the image shape using the projector controls, try decreasing the Sharpness setting in the Picture menu to improve image quality.

  • Page 102: Solutions When The Image Brightness Or Colors Are Incorrect

    • Adjust the Sharpness setting to improve image quality. • If you are projecting from a computer, use a lower resolution or adjust the computer's resolution to match the projector's native resolution, if possible. • If you blurred the edges of the projected image using the Edge Blur function, press the Flexible Picture menu button on the remote control to display the Flexible Picture menu, and then press the blank button to disable the function.

  • Page 103: Solutions To Sound Problems

    Related references Image Quality Settings - Picture Menu Solutions to Sound Problems If there is no sound when you expect it or the volume is too low or high, try the following solutions: • Adjust the projector's volume settings. • Check your computer or video source to make sure the volume is turned up and the audio output is set for the correct source.

  • Page 104: Solutions To Bluetooth Audio Problems

    Solutions to Bluetooth Audio Problems If you cannot connect to a Bluetooth audio device, try the following solutions: • If you are trying to use the projector as a speaker, enable Bluetooth Speaker Mode in the projector's menu. • Select Projector from the available Bluetooth device list displayed on your device. •...

  • Page 105: Solutions To Projector Power Or Shut-Off Problems

    • If the power button on the remote control does not turn on the projector, check its batteries. • The power cord may be defective. Try another power cord. If that doesn't work, disconnect the cord and contact Epson. • The cooling fans may run in standby status depending on the projector settings. Also, when the projector wakes from standby status, the fans may cause an unexpected noise.

  • Page 106: Solutions To Hdmi Link Problems

    Dim the lights or move the projector away from the sun or interfering equipment. • If you lose the remote control, you can purchase another from an Epson parts distributor. Parent topic: Solving Projector or Remote Control Operation Problems...

  • Page 107: Solving Network Problems

    Solving Network Problems Related tasks Setting Up Android TV Where to Get Help (U.S. and Canada) If you need to contact Epson for technical support services, use the following support options. Internet Support Visit Epson's support website at epson.com/support (U.S.) or epson.ca/support...

  • Page 108: Where To Get Help (Latin America)

    Speak to a Support Representative To use the Epson PrivateLine Support service, call (800) 637-7661. This service is available for the duration of your warranty period. You may also speak with a projector support specialist by dialing (562) 276-4394 (U.S.) or (905) 709-3839 (Canada).
  • Page 109 • Product serial number (located on the bottom or rear of the projector, or in menu system) • Proof of purchase (such as a store receipt) and date of purchase • Computer or video configuration • Description of the problem Then call: Country Telephone...
  • Page 110 Purchase Supplies and Accessories You can purchase optional accessories and replacement parts from an Epson authorized reseller. To find the nearest reseller, go to latin.epson.com. Or you can contact your nearest sales office as described in "Where to Get Help."...

  • Page 111: Technical Specifications

    Technical Specifications These sections list the technical specifications of your projector. General Projector Specifications Projector Light Source Specifications Remote Control Specifications Projector Dimension Specifications Projector Electrical Specifications Bluetooth Specifications Projector Environmental Specifications Projector Safety and Approvals Specifications Supported Video Display Formats General Projector Specifications Type of display Poly-silicon TFT active matrix...
  • Page 112 Brightness Normal light source mode: White light output 3600 lumens (Dynamic color mode) Color light output 3600 lumens (Dynamic color mode) Medium light source mode: White light output 2000 lumens (Vivid color mode) ECO light source mode: White light output 1800 lumens (Dynamic color mode) Note: Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions.

  • Page 113: Projector Light Source Specifications

    USB Type mini-B port One USB 2.0 compliant port for firmware updates compatibility Parent topic: Technical Specifications Projector Light Source Specifications Type Laser diode Light source output power Up to 66 W Wavelength 449 to 461 nm Light source life Normal light source mode: (approximate) Up to about 20000 hours...
  • Page 114 Depth 15.7 inches (400 mm) Weight Approximately 16.31 lb (7.4 kg) Center of projection window 18.4 inches (467 mm) 19.2 inches (233.5 mm) 3.6 inches (92.2 mm)
  • Page 115 15.7 inches (400 mm)

  • Page 116: Projector Electrical Specifications

    7.6 inches (193 mm) 19.2 inches (233.5 mm) 1.9 inches (47.5 mm) 12.2 inches (311 mm) 5.7 inches (146 mm) 5.2 inches (133 mm) 6 inches (153 mm) Parent topic: Technical Specifications Projector Electrical Specifications Rated frequency 50/60 Hz Power supply 100 to 240 V AC ±10% 2.8 to 1.3 A Power consumption...

  • Page 117: Bluetooth Specifications

    Bluetooth Specifications Version Bluetooth Ver. 5.0 Output Class 1 Communication distance Approximately 32.8 feet (10 m) Supported profiles A2DP, AVRCP Frequency used 2.4 GHz band (2.402 to 2.480 GHz) Supported codecs Caution: Do not use the device near any medical equipment or equipment that is automatically controlled, such as automatic doors or fire alarms.

  • Page 118: Projector Safety And Approvals Specifications

    For best results, your computer's monitor port or video card resolution should be set to display in the projector's native resolution. However, your projector includes Epson's SizeWise chip that supports other computer display resolutions, so your image will be resized to fit automatically.
  • Page 119 Compatible signals are converted for output as an HDR image. For example, a 4K 60 Hz 4:4:4 8-bit signal is converted to a 4:2:2 10-bit HDR signal. Refresh rate (in Hz) Resolution (in pixels) 23.98/24/29.97/30/50/59.94/60 1920 × 1080 23.98/24/25/29.97/30 3840 × 2160 23.98/24/25/29.97/30 4096 ×...
  • Page 120 Output audio format eARC Supported Supported DTS-HD High Resolution — — Audio DTS-HD Master Audio — — DTS:X — — — — — Parent topic: Technical Specifications...

  • Page 121: Notices

    Binding Arbitration and Class Waiver Trademarks Copyright Notice Recycling (U.S. and Canada) Epson offers a recycling program for end of life products. Please go to this site for information on how to return your products for proper disposal. Parent topic:...
  • Page 122 • If an error occurs in the projector, turn off the power and unplug the projector immediately. Continuing to use the projector could result in an electric shock, fire, or visual impairment. Contact Epson support. • Do not attempt to disassemble or modify the projector. The projector contains a high-power laser component.
  • Page 123 Laser warning labels are attached to the projector. • Inside • Top...
  • Page 124 As with any bright source, do not stare into the beam (RG2 IEC/EN 62471-5:2015). • Bottom The label attached on the projector varies depending on the countries and regions.

  • Page 125: Important Safety Instructions

    Complies with FDA performance standards for laser products except for conformance as a Risk Group 2 LIP as defined in IEC 62471-5: Ed. 1.0. For more information see Laser Notice No. 57, dated May 8, 2019. Parent topic: Notices Important Safety Instructions Follow these safety instructions when setting up and using the projector: •...
  • Page 126 • Do not use the device near any medical equipment or equipment that is automatically controlled, such as automatic doors or fire alarms. Electromagnetic interference from the device may cause such equipment to malfunction and cause an accident. • Use the type of power source indicated on the projector. Use of a different power source may result in fire or electric shock.
  • Page 127 • Follow the maintenance schedule for this projector. If the interior of the projector has not been cleaned for a long time, dust may build up, which could cause the internal temperature of the projector to rise, resulting in malfunctions, early deterioration of optical parts, and even fire or electric shock. Replace your air filter periodically and contact your dealer to clean the interior of the projector, as needed.
  • Page 128 • Do not stand on the projector or place heavy objects on it. You may fall over, resulting in injury and damage to the projector. • If you are using the projector at altitudes above 4,921 feet (1,500 m), enable the High Altitude Mode setting in the projector's menu to ensure the projector's internal temperature is regulated properly.

  • Page 129: Restriction Of Use

    • Remove the batteries from the remote control before storing the projector. If the batteries are left in the remote control for long periods, they may leak. • Do not disassemble the projector when disposing of it. Dispose of the projector according to your local or national laws and regulations.
  • Page 130 Symbol Approved Standards Description IEC60417 Stand-by No. 5009 To identify the switch or switch position by means of which part of the equipment is switched on in order to bring it into the stand- by condition. ISO7000 Caution No. 0434B, To identify general caution when using the product.
  • Page 131 Symbol Approved Standards Description IEC60417 Battery, general No. 5001B On battery powered equipment. To identify a device for instance a cover for the battery compartment, or the connector terminals. IEC60417 Positioning of cell No. 5002 To identify the battery holder itself and to identify the positioning of the cell(s) inside the battery holder.
  • Page 132 Symbol Approved Standards Description IEC60417 Class II equipment No. 5172 To identify equipment meeting the safety requirements specified for Class II equipment according to IEC 61140. ISO 3864 General prohibition To identify actions or operations that are prohibited. ISO 3864 Contact prohibition To indicate injury that could occur due to touching a specific part of the equipment.

  • Page 133: Fcc Compliance Statement

    Symbol Approved Standards Description ISO3864 Caution, movable parts IEC60417 To indicate that you must keep away from movable parts according to protection No. 5057 standards. IEC 60417 Caution (movable fan blades) No. 6056 To indicate that you must keep away from movable parts according to protection standards.

  • Page 134: Binding Arbitration And Class Waiver

    1. DISPUTES, BINDING INDIVIDUAL ARBITRATION, AND WAIVER OF CLASS ACTIONS AND CLASS ARBITRATIONS 1.1 Disputes. The terms of this Section 1 shall apply to all Disputes between you and Epson. The term "Dispute" is meant to have the broadest meaning permissible under law and includes any dispute, claim,...
  • Page 135 1.3 Pre-Arbitration Steps and Notice. Before submitting a claim for arbitration, you and Epson agree to try, for sixty (60) days, to resolve any Dispute informally. If Epson and you do not reach an agreement to resolve the Dispute within the sixty (60) days), you or Epson may commence an arbitration. Notice to Epson must be addressed to: Epson America, Inc., ATTN: Legal Department, 3131 Katella Ave., Los...
  • Page 136 Award in Your Favor. For Disputes in which you or Epson seeks $75,000 or less in damages exclusive of attorney's fees and costs, if the arbitrator's decision results in an award to you in an amount greater than Epson's last written offer, if any, to settle the Dispute, Epson will: (i) pay you $1,000 or the amount...

  • Page 137: Trademarks

    Dispute in arbitration. Except as agreed upon by you and Epson in writing, the arbitrator shall determine the amount of fees, costs, and expenses to be paid by Epson pursuant to this Section 1.6d).
  • Page 138 Seiko Epson Corporation. The information contained herein is designed only for use with this Epson product. Epson is not responsible for any use of this information as applied to other products.
  • Page 139 A Note Concerning Responsible Use of Copyrighted Materials Epson encourages each user to be responsible and respectful of the copyright laws when using any Epson product. While some countries' laws permit limited copying or reuse of copyrighted material in certain circumstances, those circumstances may not be as broad as some people assume. Contact your legal advisor for any questions regarding copyright law.

This manual is also suitable for:

Eh-ls650wV11hb07120V11hb07020

Table of Contents
