Read and save these instructions.
Write Model and Serial Numbers
here:
Model:
Serial No.:
ADA-COMPLIANT
RANGE HOOD
H24RSS
H24RSSADA
H24RBADA
H24RWADA
H30RSS
H30RSSADA
H30RBADA
H30RWADA
H36RSS
H36RSSADA
H36RBADA
H36RWADA
User Manual
Models:
H24SSCVADA
H24BCVADA
H24WCVADA
H30SSCVADA
H30BCVADA
H30WCVADA
H36SSCVADA
H36BCVADA
H36WCVADA
An ISO 9001:2015 registered company
770 Garrison Avenue Bronx, New York
Felix Storch, Inc.
Summit Appliance Division
10474
www.summitappliance.com
Advertisement
Table of Contents
Related Manuals for Summit H24RSSADA
Summary of Contents for Summit H24RSSADA
- Page 1 H36SSCVADA H36RBADA H36BCVADA H36RWADA H36WCVADA User Manual Read and save these instructions. Write Model and Serial Numbers Felix Storch, Inc. here: Summit Appliance Division An ISO 9001:2015 registered company Model: 770 Garrison Avenue Bronx, New York Serial No.: 10474 www.summitappliance.com...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS APPROVED FOR RESIDENTIAL APPLIANCES FOR RESIDENTIAL USE ONLY READ AND SAVE THESE INSTRUCTIONS BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS INSTALLATION MUST COMPLY WITH ALL LOCAL CODES. IMPORTANT: Save these Instructions for the Local Electrical Inspector’s use. INSTALLER: Please leave these Instructions with this unit for the owner. -
Page 3: Equipment Safety
Refrigeration and Air Conditioning Engineers (ASHRAE), and local code authorities. • When replacing an existing range hood with your new SUMMIT Range Hood, turn OFF the electrical power to the existing unit before removal. • Before servicing or cleaning the unit, unplug the unit first. - Page 4 Cooking Safety Information: 1. Never leave the range hood unattended when in use. 2. Never cook over open flames under the range hood. 3. Always turn the range hood on when cooking at high heat or when cooking flaming foods. 4.
-
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS CAUTION: Before beginning the installation, switch the power off at the circuit breaker and lock the service, disconnecting means to prevent power from being switched on accidentally. When the service disconnecting means cannot be locked, securely fasten a prominent warning device, such as a tag, to the breaker. -
Page 6: Wiring Connection
Wiring Connection Installation work and electrical wiring must be done by a qualified person(s) in accordance with all applicable codes and standards, including fire-rated construction. • Electrical grounding is required for this range hood. Check with a qualified electrician if you are not sure whether the range hood is properly grounded. - Page 7 Installation Instructions WORKSHEET—CALCULATE TOTAL EQUIVALENT DUCTWORK LENGTH EQUIVALENT NUMBER DUCT EQUIVALENT NUMBER DUCT LENGTH x USED PIECES = TOTAL PIECES LENGTH X USED = TOTAL ⁄ ″ x 10″ 1 Ft. 6″ Round 53 Ft. Rect., wall cap (39 ft. w/o straight with damper)
- Page 8 Choosing a Vent Option Determine the vent option that your installation will require and that is available for your model from the below choices. NOTE: If the hood is to be installed in a recirculating, non-vented, ductless manner, do not knock out any vent openings in the hood.
- Page 9 Duct Installation Remove the Filter Take out filters from the accessory bag. Tear off film from grease filter. Put charcoal filter on grease filter. Slip the back edge of the filter into the retaining slot. Rotate the filter block pin to fix the filters into place.
- Page 10 For 3 ¼” x 10” Rectangular Ducted Installation 1. Remove tape from damper flap. 2. Attach exhaust adaptor/damper over the appropriate knockout opening (for vertical or horizontal, depending on installation) with six exhaust adaptor screws. Make sure damper pivot is nearest to top/back edge of hood.
-
Page 11: Cabinet Front
Mark Holes Select the vent option that your installation will require and proceed to that section: Outside Top Exhaust – 3 ¼” x 10” Rectangular ⁄ ⁄ (36 hood) (36 hood) Use the diagram to the ⁄ ⁄ right or the hood itself as a (30 hood) (30 hood) template and mark the... - Page 12 Outside Rear Exhaust – 3 ¼” x 10” Rectangular Use the diagram to the right or the hood itself as a template and mark the locations on the cabinet for ductwork and keyhole screw slots. Wood shims (Recessed-bottom cabinets only–shims must be a minimum of 3/8 thick and cut to fit the width of the inner recessed cabinet bottom) Cabinet front...
- Page 13 Secure the Hood Slide the hood back against the wall. Tighten the mounting screws. Be sure the screw heads are in the narrow neck of the keyhole slot. NOTE: DO NOT push the fan blade. Pushing on the blade may cause it to interfere with other hood parts.
-
Page 14: Operating Your Range Hood
Replace the Filter Make sure fan blade turns freely and replace the filter. NOTE: Install the metal grease filter if ducted or the charcoal filter if recirculated. The installation is complete. Turn on the power at the breaker box and test the hood for proper operation. -
Page 15: Remote Switch Installation
REMOTE SWITCH INSTALLATION (models with ADA suffix) NOTE: Installation and service must be performed by a qualified installer/electrician WARNING: To avoid fire or electrical shock, turn off the power at the circuit breaker Test to ensure that the power is off before starting the wiring. -
Page 16: Cleaning And Care
CLEANING AND CARE CAUTION: Be sure the range hood is disconnected from the power supply and all surfaces are cool before cleaning any part of the vent hood. Reusable Metal Grease Filter – Ducted Installations Only The efficiency of your hood depends on a clean filter. Frequency of cleaning depends on hood use and the type of cooking you do. -
Page 17: Troubleshooting
Surfaces CAUTION: When cleaning the hood surfaces, be certain that you do not touch the light bulb with moist hands or cloth. A warm or hot light bulb may break if touched with a moist surface. Always let the light bulb cool completely before cleaning around it. •... -
Page 18: Limited Warranty
LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory- specified parts and repair labor to correct defects in materials or workmanship.
