TURBO HD
D8T Series Turret Camera

User Manual

UD05330B
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Type I
Camera
Type II
Camera
This manual may contain technical incorrect places or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or
update the products or procedures described in the
manual.
Model
DS-2CE56D8T-IT1(E)
DS-2CE56D8T-IT3(E)
DS-2CE56D8T-ITM(E)
0100001070415

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-2CE56D8T-IT1 and is the answer not in the manual?

Questions and answers

Summary of Contents for HIKVISION DS-2CE56D8T-IT1

  • Page 1: User Manual

    User Manual Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Type Model DS-2CE56D8T-IT1(E) Type I Camera DS-2CE56D8T-IT3(E) Type II DS-2CE56D8T-ITM(E) Camera...
  • Page 2 Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 4: Installation

    1 Introduction 1.1 Product Features The camera is applicable for both indoor and outdoor conditions, and the application scenarios include road, warehouse, underground parking lot, bar, etc.. The main features are as follows: High performance CMOS sensor  Low illumination, 0.005 Lux @ (F2.0, AGC ON), 0 Lux ...
  • Page 5 If the wall is cement, insert expansion screws before  installing the camera. If the wall is wooden, use self-tapping screw to secure the camera. If the product does not function properly, contact  your dealer or the nearest service center. Do NOT disassemble the camera for repair or maintenance by yourself.
  • Page 6 Figure 2-4 Secure the Camera with Mounting Base 8. Connect the corresponding cables, such as power cord, and video cable. 9. Power on the camera to check whether the image on the monitor is gotten from the optimum angle. If not, adjust the camera according to the figure below to get an optimum angle.
  • Page 7 Figure 2-8 Fix the Inclined Base Body 6. Combine inclined base’s cover with its body with supplied screws. 7. Repeat steps 6 to 9 of the 2.1.1 Ceiling/Wall Mounting without Junction Box to complete the installation. Figure 2-9 Fix the Camera to the Inclined Base 2.2 Installation of Type II Camera Before you start: Both wall mounting and ceiling mounting are suitable...
  • Page 8 Note: Drill the cable hole in the center of the drill template, when adopting the ceiling outlet to route the cable. Secure the mounting base to the ceiling with the supplied screws. Expansion Bolts Fixing Screw Figure 2-12 Fix the Mounting Base to the Ceiling Note: The supplied screw package contains self-tapping ...
  • Page 9: Type I Camera

    Type I Camera Figure 2-15 Drill Template of the Junction Box Note: Drill the cable hole, when adopting the ceiling outlet to route the cable. 3. Take apart the junction box, and align the screw holes of the turret camera’s mounting base with those on junction box’s cover.
  • Page 10: Menu Description

    Type I Camera Figure 2-18 Install the Mounting Base to the Bracket Route the cables through the bracket. 6. Repeat steps 7 to 9 of 2.1.1 Ceiling/Wall Mounting without Junction Box to complete the installation. 3 Menu Description Purpose: Call the menu by clicking button on the PTZ Control interface, or call preset No.95.
  • Page 11: Main Menu

    5. Click the direction arrow to control the camera. (1) Click up/down direction button to select the item. (2) Click Iris + to confirm the selection. (3) Click left/right direction button to adjust the value of the selected item. 3.1 FORMAT PAL (Phase Alternating Lines) PAL is a color encoding system for analog television used in broadcast television systems in most countries.
  • Page 12 SENSE UP Sense up increases the exposure on a signal frame, which makes a camera more sensitive to light so it can produce images even in low lux conditions. You can set the SENS-UP as OFF or AUTO according to different light conditions.
  • Page 13: Video Setting

    3.3.4 VIDEO SETTING Move the cursor to VIDEO SETTING and click Iris+ to enter the submenu. CONTRAST, SHARPNESS, COLOR GAIN, 3D DNR, and MIRROR are adjustable. Figure 3-6 VIDEO SETTING CONTRAST This feature enhances the difference in color and light between parts of an image.
  • Page 14: Save And Exit

    be triggered. Up to 4 motion detection areas can be configured. Figure 3-8 MOTION Select a MOTION area. Set the DISPLAY status as ON. Click the up/down/left/right button to define the position and size of the area. Set the SENSITIVITY from 0 to 100.
