Turbo hd d8t series bullet & turret cameras
Hide thumbs

Advertisement

Table of Contents

TURBO HD
D8T Series
Bullet & Turret Camera

User Manual

UD05333B-A
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Model
DS-2CE16D8T-(A)IT3Z(E)
Type I Camera
Type II Camera
DS-2CE56D8T-IT3Z(E)
This manual may contain technical incorrect places or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or
update the products or procedures described in the
manual.
0100001070426

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-2CE16D8T-AIT3ZE and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION DS-2CE16D8T-AIT3ZE

Summary of Contents for HIKVISION DS-2CE16D8T-AIT3ZE

  • Page 1: User Manual

    TURBO HD D8T Series Bullet & Turret Camera User Manual UD05333B-A User Manual Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Type Model DS-2CE16D8T-(A)IT3Z(E)

  • Page 2: Regulatory Information

    Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.

  • Page 4: Product Features

    1 Introduction 1.1 Product Features The camera is applicable for both indoor and outdoor conditions, and the application scenarios include road, warehouse, underground parking lot, bar, etc.. The main features are as follows: High performance CMOS sensor  Low illumination, 0.005 Lux @ (F1.8, AGC ON), 0 Lux ...

  • Page 5: Installation

    2 Installation Before you start: Make sure that the device in the package is in good  condition and all the assembly parts are included. Make sure that all the related equipment is power-off  during the installation. Check the specification of the products for the ...
  • Page 6 For cement wall, expansion bolts are required to fix  the camera. For wooden wall, self-tapping screws are required. 5. Connect the corresponding power cord, and video cable. 6. Power on the camera to check whether the image on the monitor is gotten from the optimum angle. If not, adjust the surveillance angle.
  • Page 7 Figure 2-5 Fix the Camera to the Ceiling 7. Route the cables through the cable hole, or the side opening of the junction box. 8. Combine the junction box cover with its body. Figure 2-6 Fix the Junction Box Cover back to its Body 9.
  • Page 8 Figure 2-9 Fix the Mounting Base on the Ceiling Note: The supplied screw package contains self-tapping  screws, and expansion bolts. For cement wall, expansion bolts are required to fix  the camera. For wooden wall, self-tapping screws are required. 5.
  • Page 9 Figure 2-12 Drill Template of the Junction Box Note: Drill the cable hole, when adopting the ceiling outlet to route the cable. 3. Refer to step 3 of 2.2.1 Ceiling/Wall Mounting without Junction Box to take out the camera’s main body.

  • Page 10: Menu Description

    3 Menu Description Purpose: Call the menu by clicking button on the PTZ Control interface, or call preset No.95. Steps: 1. Connect the camera with the TVI DVR, and the monitor shown as the Figure 3-1. Figure 3-1 Connection 2. Power on the analog camera, TVI DVR, and the monitor to view the image on the monitor.

  • Page 11: Exposure Mode

    3.3 FOCUS Move the cursor to FOCUS, and press the Iris+ to enter the submenu. Click FOCUS+, FOCUS-, ZOOM+, and ZOOM- to adjust the focus. 3.4 MAIN MENU 3.4.1 AE (AUTO EXPOSURE) Auto Exposure describes the brightness-related parameters, which can be adjusted by BRIGHTNESS, EXPOSURE MODE, AGC, and SENSE UP.

  • Page 12: Video Setting

    the environment. It can remove unrealistic color casts in the image. You can set WB mode as ATW, or MWB. ATW (Aoto Tracking White Balance) Under ATW mode, white balance is being adjusted automatically according to the color temperature of the scene illumination.
  • Page 13 CONTRAST This feature enhances the difference in color and light between parts of an image. You can set the CONTRAST value from 1 to 10. SHARPNESS Sharpness determines the amount of detail an imaging system can reproduce. You can set the SHARPNESS value from 1 to 10.

  • Page 14: Save And Exit

    position and size of the area. Set the SENSITIVITY from 0 to 100. CAMERA ID Edit the camera ID on this section. Figure 3-9 CAM ID SETTING Set the MODE as on. Click up/don left/right button to choose the camera ID and the position. 3.4.6 RESET Reset all the settings to the default.
