2.5.6

Onboard Devices Configuration

HD Audio Controller [Enabled]
[Enabled]
[Disabled]
The following item appears only when you set the HD Audio Controller item to [Enabled].
Front Panel Type [HD]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC'97 or high-
definition audio depending on the audio standard that the front panel audio module supports.
[HD]
[AC97]
SPDIF Out Type [SPDIF]
[SPDIF]
[HDMI]
Realtek LAN Controller [Enabled]
[Enabled]
[Disabled]
Realtek PXE OPROM [Disabled]
This item appears only when you set the previous item to [Enabled] and allows you to enable
or disable the PXE OptionRom of the Realtek LAN controller.
Configuration options: [Enabled] [Disabled]

Serial Port Configuration

The sub-item in this menu allow you to set the serial port configuration.
This item functions only if there is a serial port (COM1) connector on the motherboard.
Serial Port [Enabled]
Allows you to enable or disable the serial port (COM).
Configuration options: [Enabled][Disabled]
Change Settings [IO=3F8h; IRQ=4]
Allows you to select the Serial Port base address.
Configuration options: [IO=3F8h; IRQ=4][IO=2F8h; IRQ=3][IO=3E8h; IRQ=4][IO=2E8h;
IRQ=3]
2.5.7

APM

ErP Ready [Disabled]
This item allows user to switch off some power at S5 to get the system ready for ErP
requirement. When set enabled to Enabled, all other PME options will be switched off.
Configuration options: [Disabled] [Enabled]
2-22
Enables the High Definition Audio Controller.
Disables the controller.
Sets the front panel audio connector (AAFP) mode to high definition audio.
Sets the front panel audio connector (AAFP) mode to legacy AC'97.
Sets to [SPDIF] for SPDIF audio output.
Sets to [HDMI] for HDMI audio output.
Enables the Realtek LAN controller.
Disables the controller.
ASUS P8Z77-M
