3.3.7
M.2 Detection Configuration
This item allows you to configure M.2 device option settings.
M.2 (Socket3) (PCIE x4 MODE)
Allows you to enable or disable the M.2 (socket 3) (PCIE x4 mode) slot.
Configuration options: [Disabled] [Enabled]
3.3.8
NVMe Configuration
The NVMe Configuration menu displays the NVMe controller and drive information
of the devices connected and allows you to configure NVMe device options
settings.
3.3.9
Onboard Devices Configuration
LAN_X2_P1
Allows you to enable or disable LAN1 I219LM.
Configuration options: [Disabled] [Enabled]
LAN_X1_P1
Allows you to enable or disable LAN2 I226V.
Configuration options: [Disabled] [Enabled]
3.3.10
Network Stack Configuration
Network Stack
Allows you to disable or enable the UEFI network stack. Configuration options:
[Disabled] [Enabled]
The following items appear only when you set the previous item to [Enabled].
Ipv4 PXE Support
Allows you to disable or enable the Ipv4 PXE Boot support. If disabled, IPv4 PXE
Boot support will not be available. Configuration options: [Disabled] [Enabled]
Ipv4 HTTP Support
Allows you to disable or enable the Ipv4 HTTP Boot support. If disabled, IPv4
HTTP Boot support will not be available. Configuration options: [Disabled]
[Enabled]
Chapter 3: BIOS setup
3-9
