INSTALLATION
WARNING
■ Do not install the refrigerator in a damp or wet
location as this may cause damage to the insulation
and a leakage. Condensation may also build on the
outer cabinet and cause rust.
1
Keep adequate ventilation space around the refrigerator.
• The fi gure shows the minimum required space for
installing the refrigerator. The measurement condition
of power consumption is conducted under a different
space dimension.
• By keeping greater space, the refrigerator may be
operated under a less amount of power consumption.
• If using the refrigerator in the smaller space dimension
than the below fi gure, it may cause the temperature
rise in the unit, loud noise and failure.
90mm
or more
60mm
60mm
or more
or more
Free standing type
2
Use the two front adjustable feet, to ensure that the
refrigerator is positioned fi rmly and fl at on the fl oor.
3
When right and left doors are not properly aligned, adjust
using the adjustable feet.
When the left door is
raised.
Lower the foot
at right side.
(Until the adjustable foot on the
other side is slightly off-ground.)
4
60mm
or more
1500 mm
Adjustable foot
When the right door is
raised.
Lower the foot
at left side.
4
Remove the 4 screws of the cabinet lower part, and
then set the foot cover (supplied inside the refrigerator
compartment) with removed 4 screws.
Screw
(4 screws)
NOTE
• Position your refrigerator so that the plug is accessible.
• Keep your refrigerator out of direct sunlight.
• Do not place next to heat generating appliance.
• Do not place directly on the ground. Provide suitable stand.
• To insert the power plug when the door is opened, door alarm
sounds but it is not abnormal. This sound stops when closing
the door.
Before using your refrigerator
Clean the inside parts with a cloth soaked in warm water.
If soapy water is used, wipe it off thoroughly with water.
Screw
Foot cover
