H
OFFMANN GmbH
Operation - Maintenance - Care | www.Hoffmann-Schwalbe.de
M
aschinenbau
Copy of USER MANUAL
Hoffmann Frame Joiner 10585
01/2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 10585 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hoffmann 10585

  • Page 1 01/2023 Copy of USER MANUAL OFFMANN GmbH Operation - Maintenance - Care | www.Hoffmann-Schwalbe.de Hoffmann Frame Joiner 10585 aschinenbau...
  • Page 2: Table Of Contents

    Hoffmann GmbH Maschinenbau Intended Use ................................3 Safety instructions and safety devices ........................4 Technical data HOFFMANN Frame Joiner ........................6 Noise level at the machine ............................7 Warranty Statement ..............................8 EC Declaration of Conformity ............................. 9 Function and operation of the machines ........................10 Scope of delivery, transport and storage ........................11...
  • Page 3: Intended Use

    It is imperative that the instructions accompanying this sign are followed. The use of the machines is only permitted for grooves of the Hoffmann This symbol indicates a possible hazard works standards W-0, W-1, W-2, W-3 and for wood or wood-like that can lead to serious, moderate or light materials, as well as MDF and multiplex.
  • Page 4: Safety Instructions And Safety Devices

    The manual should be kept ready to hand as a reference work. Only persons who are authorized to do this and who are familiar with the handling may work on the HOFFMANN Frame Jointing machines ! Keep all persons not working on the milling machine away! The operating personnel must switch off the machine electrically as long as the machine is not being supervised or is not being worked on.
  • Page 5 Hoffmann GmbH Maschinenbau If damage or errors are found on the Frame Joiner routing machine that could endanger persons or property, the Frame Joiner machine must be shut down immediately and further use prevented until it has been completely repaired! The operating personnel must report any faults on the machine and its protective devices immediately after they have been noticed.
  • Page 6: Technical Data Hoffmann Frame Joiner

    Hoffmann GmbH Maschinenbau Technical data HOFFMANN Frame Joiner Frame Joiner Speed control Number of engines 1 = 13.000 rpm Direction of rotation to the right 2 = 17.000 rpm Speed (milling spindle) adjustable 10.000-30.000 rpm 3 = 22.000 rpm Tool holder, collet Ø6 mm...
  • Page 7: Noise Level At The Machine

    Hoffmann GmbH Maschinenbau Noise level at the machine The continuous sound pressure level emanating from the machine is approx. 88.43 dB(A). Depending on local conditions, a higher sound pressure level can result, causing hearing damage. In this case, the operating personnel must be protected with appropriate protective equipment or protective measures.
  • Page 8: Warranty Statement

    Hoffmann GmbH Maschinenbau Warranty Statement Our general terms and conditions (VDMA) apply to warranty services. Warranty period The guarantee period is 12 months from the date of delivery. It extends to the free elimination of all faults that arise as a result of poor workmanship or material defects. A warranty repair does not extend the warranty period for either the replaced parts or the device.
  • Page 9: Ec Declaration Of Conformity

    EC Declaration of Conformity in terms of EU Directive 2006/42/EC Hoffmann GmbH Maschinenbau We hereby declare, Mergelgrube 5 76646 Bruchsal Deutschland Hoffmann Frame Joiner 10585 that the machine Machine designation Machine type Keyway routing machine Machine number __________________ The version supplied complies with the following relevant provisions: 2014/35/EU u.
  • Page 10: Function And Operation Of The Machines

    Hoffmann GmbH Maschinenbau Function and operation of the machines Type Function and working method Manual table routing machine The milling position on the workpiece is determined by moving the stop elements and the desired milled groove length is pre-set using the measuring pin.
  • Page 11: Scope Of Delivery, Transport And Storage

    Scope of delivery, transport and storage Scope of delivery: The HOFFMANN Frame Joiner machines consist of: • HOFFMANN Frame Joiner machine, ready for connection, ready for operation • Tool kit, consisting of: Size 22 open-end wrench and a 4mm Allen key.
  • Page 12 Hoffmann GmbH Maschinenbau Commissioning and maintenance Setting up the machine Remove the transport packaging and clean the machine with a suitable machine cleaning agent (e.g. WD40). The machine is set up on a sufficiently stable table. The table plane must be sufficiently large, evenly flat and level so that the machine is stable.
  • Page 13 Hoffmann GmbH Maschinenbau Maintenance and care of the machine Attention: Always pull out the mains plug for all maintenance and care work. Maintenance Module Action interval Daily Tool and chip breaker Checking the tool and the chip breaker for wear, damage and cracks.
  • Page 14 Hoffmann GmbH Maschinenbau The Hoffmann Frame Joiner system Due to the extremely precise double wedge shape of the Hoffmann-dovetail, the parts to be connected are pressed together exactly and permanently due to the forced guidance. The milling cutter setting dimension must be adhered to exactly for optimal matching.
  • Page 15: Cutter Change And Cutter Adjustment

    Hoffmann GmbH Maschinenbau Cutter change and cutter adjustment Attention: Always pull out the mains plug for all adjustment work on the milling motor. The milling tool has very sharp cutting edges. Protect your hands! Removing the milling motor from the motor mount ...
  • Page 16 Hoffmann GmbH Maschinenbau Adjust cutters and change chip breakers The cutter setting gauge is part of the 90° stop plate. To use the gauge, the stop plate must be removed from the machine table and turned over so that it can be placed directly on the stop edge.
  • Page 17 Close the collet by turning the union nut while holding the gear shaft with the locking button.  Test the newly adjusted milling depth by making two test pieces and joining them with a Hoffmann dovetail connector. Cutter type Setting Dimension ...
  • Page 18: Adjusting The Routing Groove Length

    Hoffmann GmbH Maschinenbau Adjusting the routing groove length The milling groove length of the machine is limited by setting the measuring bolt. By setting the measuring pin depending on the corresponding workpiece thickness, a faster work cycle is possible and accidental "milling through" of the workpiece is prevented.
  • Page 19 Hoffmann GmbH Maschinenbau Working with the Hoffmann stop system. Thanks to the special stop system of the Hoffmann machines, the workpieces can be precisely milled in different variants. Here, workpieces with different angles as well as workpieces with radii can be processed without any problems.
  • Page 20 Hoffmann GmbH Maschinenbau Profile shape / cut Machining workpiece 1 Machining workpiece 2 Connection of workpieces with any angle . Connection of radii and arcs with any angle. User Manual...
  • Page 21 Hoffmann GmbH Maschinenbau Application examples User Manual...
  • Page 22: Malfunctions And Troubleshooting

    "0" mm milled groove length. Set the milling groove length correctly. Hoffmann-dovetail cannot be Incorrect milling depth setting of the Hoffmann Set the cutter correctly. used or the dovetail too loose in milling cutter. If necessary, use the cutter setting gauge.
  • Page 23: Machine Plan Hoffmann Frame Joiner

    Hoffmann GmbH Maschinenbau Machine plan Hoffmann Frame Joiner User Manual...
  • Page 24: Parts List Hoffmann Frame Joiner

    Hoffmann GmbH Maschinenbau Parts list Hoffmann Frame Joiner handle Part NUMBER Identification Parts GN 310-10-80-E-NI butt stop knurled screw 7.261.00.05 GN 529-15-M5-10 Cast iron table profile rail 7.300.00.01 HM-30-30-350 Stop plate 45° fitting screw 7.300.00.02-01 ISO 7379-6-M5-30 engine mount Plain bearing with collar 7.300.00.03-03...
  • Page 25: Warranty And Liability

    These are available to the operator at • parameters the latest when the contract is • Use of "non-original Hoffmann accessories" concluded. • Poor monitoring and maintenance of machine parts that are subject to wear. • Warranty and liability claims for Improperly performed repairs.
  • Page 26 Hoffmann GmbH Maschinenbau User Manual...
  • Page 27 Hoffmann GmbH Maschinenbau User Manual...
  • Page 28 Hoffmann GmbH Maschinenbau For your notes: User Manual...
