- Page 1 Quickstart Guide Version PN/EtherCAT Coupler Order number: 700-161-3EC02 Helmholz GmbH & Co. KG | Hannberger Weg 2 | 91091 Großenseebach | Germany 02.08.2023 Phone +49 9135 7380-0 | Fax +49 9135 7380-110 | info@helmholz.de | www.helmholz.de...
-
Page 2: Table Of Contents
Content Safety instructions ....................3 Introduction ......................3 Function of the PN/EtherCAT Coupler ..............4 Connection ......................4 Power supply ..........................4 Network ............................4 Download and install the GSDML and ESI file ............5 Install GSDML file in TIA Portal ...................... 5 Install ESI file in TwinCAT V2/V3 .................... -
Page 3: Safety Instructions
2 Introduction This document explains the initial commissioning of the PN/EtherCAT Coupler. The latest version of the documentation can be found at www.helmholz.de or scan the QR code directly. Quickstart Guide PN/EtherCAT Coupler | Version 1 | 02.08.2023... -
Page 4: Function Of The Pn/Ethercat Coupler
3 Function of the PN/EtherCAT Coupler With the PN/EtherCAT Coupler a simple and easy connection of a PROFINET machine to an EtherCAT machine is possible. The PN/EtherCAT Coupler allows the data transfer between a PROFINET controller and an EtherCAT master. Output data received on one side of the network is made available to the PLC as input data on the other side of the network. -
Page 5: Download And Install The Gsdml And Esi File
5 Download and install the GSDML and ESI file Please go to the product page of the PN/EtherCAT Coupler at www.helmholz.de and then to the download area or follow the link provided in the QR code. There you can download the current version of the GSDML and ESI file of the PN/EtherCAT Coupler in zipped form. -
Page 6: Install Esi File In Twincat V2/V3
TwinCAT V3: C:\TwinCAT\3.1\Config\Io\EtherCAT TwinCAT must be restarted so that the PN/EtherCAT Coupler is available afterwards. It can then be selected in the dialog "Insert EtherCAT device" under "Helmholz GmbH & Co. KG / EtherCAT Coupler". 5.3 Install ESI file in CODESYS To install the ESI file of the PN/EtherCAT coupler open the "Device Repository"... - Page 7 Quickstart Guide PN/EtherCAT Coupler | Version 1 | 02.08.2023...
-
Page 8: Data Exchange Methodology
6 Data exchange methodology The data exchange between the two network sides is carried out by the PN/EtherCAT Coupler as fast as possible. This means that as soon as new, valid output data has been received from the controller on one network side, it is transmitted as input data to the controller on the other network side at the next possible time. -
Page 9: Byte Order (Endianness)
6.2 Byte order (endianness) Since the byte order is different for the two bus systems PROFINET and EtherCAT - PROFINET uses "Big Endian" and EtherCAT "Little Endian" - the values are automatically converted in the PN/EtherCAT coupler. The conversion is automatically performed by the coupler for all data types that comprise 2, 4 or 8 bytes. For BYTE, SINT and USINT modules, however, the sequence of the data remains unchanged. -
Page 10: Configuration Of The Profinet Side
7 Configuration of the PROFINET side The data exchange between the PROFINET and the EtherCAT side of the PN/EtherCAT coupler is defined via the Simatic Engineering Tool - here using the example of "TIA Portal". The I/O data for exchange can be created in the slots of the PROFINET configuration. -
Page 11: Assign A Name To The Pn/Ethercat Coupler
PLC. If the configuration is correct, the PROFINET "BF" LED should be off. The Helmholz IPSet tool, which can be downloaded free of charge from the Helmholz website, can also be used to set the PROFINET device name. Please follow the link in the QR code on the right. -
Page 12: Configuration Of Ethercat Side
8 Configuration of EtherCAT side The configuration of the EtherCAT side of the PN/EtherCAT coupler is explained below using CODESYS V3.5 as an example. The configuration should be similar with other tools. 8.1 Add PN/EtherCAT Coupler to project Precondition for a configuration is that there is already an EtherCAT master in the project. To add the PN/EtherCAT coupler in the device list with right click on the desired EtherCAT master and select the entry "Add device"... -
Page 13: Module Configuration
8.2 Module configuration After creating the coupler, the modules can now be added according to the PROFINET configuration. To add modules right click on the coupler in the device list and select the entry "Append device" in the menu to add a module behind already existing modules. Alternatively in the device list with right click on an already existing module and select in the menu the entry "Insert device"... -
Page 14: The Pn/Ethercat Coupler Website
9 The PN/EtherCAT Coupler website As soon as the PN/EtherCAT coupler has been configured by the PROFINET PLC, the web interface of the device is accessible via the IP address configured in PROFINET. The web interface can only be accessed via the PROFINET side. -
Page 15: Firmware-Update
For a firmware update, please download the latest firmware from the following link: https://www.helmholz.de/goto/700-161-3EC02 The firmware file can be recognized by the file extension "HUF" (Helmholz Update File) and is encrypted to protect it from changes. Quickstart Guide PN/EtherCAT Coupler | Version 1 | 02.08.2023... -
Page 16: Status-Byte
10 Status-Byte To be able to consider the state of the PN/EtherCAT coupler in the respective PLC, the coupler contains a status byte in the cyclic input data both on the PROFINET and on the EtherCAT side. The status byte provides information about the validity of the exchanged I/O data, the status of the respective other network side and the status of the power supply at PS 1 and PS 2. -
Page 17: Status-Byte On Ethercat Side
10.2 Status-Byte on EtherCAT side In CODESYS you can find the status byte with the contained bits by double-clicking the coupler in the device list and then switching to the "EtherCAT I/O image" view. Structure of the status byte: Name Exchanged I/O data valid PROFINET I/O connection (AR) established PROFINET &... -
Page 18: Diagnostic Led Information
11 Diagnostic LED information X1 PROFINET (left side) X2 EtherCAT (right side) SF-LED (red) ER-LED (red) System Fault LED for signaling system faults Error LED for signaling various error states (see chap. 11.3 for details) (see chap. 11.4 for details) BF-LED (red) RN-LED (greed) Bus fault LED for signaling connection errors... -
Page 19: Led Diagnostics For Profinet Interface
11.1 LED diagnostics for PROFINET interface The LED states listed assume that the coupler is in the ready-to-run state, i.e. the central green RUN LED is lit. SF-LED BF-LED MT-LED links Status of the PROFINET interface (red) (red) (yellow) Error-free operating state with valid data exchange between the PROFINET and the EtherCAT control. -
Page 20: Led Diagnostics For Ethercat Interface
11.2 LED diagnostics for EtherCAT interface The LED states listed assume that the coupler is in the ready-to-run state, i.e. the central green RUN LED is lit. LED (color) State Function ER-LED (rot) No error condition Flashing Request of the controller to the coupler to change to a higher EtherCAT state was rejected (e.g. -
Page 21: Technical Data
12 Technical data Order no. 700-161-3EC02 Article name PN/EtherCAT Coupler Scope of delivery PN/EtherCAT Coupler with power supply connector Dimensions (D x W x H) 32,5 x 58,5 x 76 mm Weight approx. 135 g PROFINET interface (X1) Number Connection 2x RJ45, integrated switch Protocol PROFINET IO Device as defined in IEC 61158-6-10... - Page 22 We can send you the corresponding license conditions, including a copy of the complete license text together with the product. They are also provided in our download area of the respective products under www.helmholz.de. We also offer to send you or any third party the complete corresponding source text of the respective open source software for an at-cost fee of 10.00 Euro as a DVD upon request.
