Helmholz 700-158-3PN02 Quick Start Manual

Pn/pn coupler
Hide thumbs
Table of Contents

Advertisement

Quick Links

Quickstart Guide
PN/PN Coupler
Order number: 700-158-3PN02
For firmware V2.0 and above
Helmholz GmbH & Co. KG | Hannberger Weg 2 | 91091 Großenseebach | Germany
Phone +49 9135 7380-0 | Fax +49 9135 7380-110 | info@helmholz.de | www.helmholz.de
Version
7
en
12.10.2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 700-158-3PN02 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Helmholz 700-158-3PN02

Summary of Contents for Helmholz 700-158-3PN02

  • Page 1 Quickstart Guide Version PN/PN Coupler Order number: 700-158-3PN02 For firmware V2.0 and above Helmholz GmbH & Co. KG | Hannberger Weg 2 | 91091 Großenseebach | Germany 12.10.2021 Phone +49 9135 7380-0 | Fax +49 9135 7380-110 | info@helmholz.de | www.helmholz.de...

  • Page 2: Table Of Contents

    Content Safety instructions ....................3 Introduction ......................3 Function of the PN/PN Coupler ................4 Connection ......................4 Power supply ..........................4 Network ............................5 Install GSDML file ....................5 Configuration in TIA Portal ................... 6 IO Configuration .......................... 7 Parameterization of the PN/PN coupler ..................

  • Page 3: Safety Instructions

    This document explains the initial commissioning of the PN/PN Coupler. The latest version of the document and a detailed manual can be found at www.helmholz.de or scan the QR code directly. Quickstart Guide PN/PN Coupler V2 | Version 7 | 12.10.2021...

  • Page 4: Function Of The Pn/Pn Coupler

    3 Function of the PN/PN Coupler With the PN/PN Coupler, a simple and uncomplicated connection of two separate PROFINET networks is possible. The PN/PN Coupler enables data transmission between two PROFINET controllers. A PROFINET IO device is on both PROFINET network sides. Received input data on one of the network sides is made available as output data to the other network side.

  • Page 5: Network

    5 Install GSDML file Please download the GSDML file ("GSDML-V2.35-Helmholz-PN-PN-coupler-____.xml") at www.helmholz.de or scan the QR code. Install the GSDML file in the "Tools" / "Manage device description file (GSD)" menu in the TIA Portal. The PN/PN Coupler can be found in the hardware catalog at "Other field devices / PROFINET IO / Gateway / Helmholz GmbH &...

  • Page 6: Configuration In Tia Portal

    6 Configuration in TIA Portal Select either “PN/PN Coupler V2 X1” for the left network side or “PN/PN Coupler V2 X2” for the right network side from the device list. Provide the PN/PN Coupler with a PROFINET name under “General” and check the Ethernet address for the device.

  • Page 7: Io Configuration

    6.1 IO Configuration Now insert the desired IO modules into the plug points. IO modules for 1, 2, 4, 8, 16, 32, 64, and 128 bytes are available for input and output. Combined IN/OUT modules are also available. The sequence and the sizes of the modules must always be selected consistently with the modules on the opposite PROFINET side.

  • Page 8: Parameterization Of The Pn/Pn Coupler

    6.2 Parameterization of the PN/PN coupler The parameters of the PN/PN Coupler can be set in “Properties/Module parameters”. Data validity display DIA: The validity of the data is displayed in the bit with the lowest value (Bit 0) of the first input byte of the corresponding PROFINET side: 0 = data could not be transmitted.

  • Page 9: Assign A Name To The Pn/Pn Coupler

    If the PN/PN coupler has received the correct PROFINET name, it is recognized and configured by the PLC. If the configuration is correct, the PROFINET "BF" LED should be off. To set the PROFINET name, the Helmholz IPSet Tool can also be used, which can be downloaded free of charge from the Helmholz website.

  • Page 10: Web Interface Of The Pn/Pn Coupler

    7 Web interface of the PN/PN Coupler As soon as the PN/PN Coupler has been configured by the PROFINET PLC, the web interface of the device is accessible if it is activated in the PROFINET configuration. If the web page of the device is not available, please check the "Web page" parameter in the PROFINET configuration.
  • Page 11 For firmware update please download the current firmware under the following link or scan the QR code: http://www.helmholz.de/goto/700-158-3PN02#tab-software The firmware file can be recognized by the file extension "HUF" (Helmholz Update File) and is encrypted to protect it from modification. Quickstart Guide PN/PN Coupler V2 | Version 7 | 12.10.2021...

  • Page 12: Technical Data

    8 Technical data Order no. 700-158-3PN02 Article designation PN/PN Coupler (V2) PROFINET interfaces (X1 & X2) Connection 2x RJ45, integrated switch Protocol PROFINET IO Device as defined in IEC 61158-6-10 Transmission rate 100 Mbit/s full duplex I/O image size Up to 1024 Byte of input and output data...

  • Page 13: Led Status Information

    We can send you the corresponding license conditions, including a copy of the complete license text together with the product. They are also provided in our download area of the respective products under www.helmholz.de. We also offer to send you or any third party the complete corresponding source text of the respective open source software for an at-cost fee of 10.00 Euro as a DVD upon request.
