Helmholz 700-158-3DP01 Quick Start Manual

Dp/pn coupler
Hide thumbs
Table of Contents

Advertisement

Quick Links

Quick Start Guide DP/PN Coupler
Version
1
en
as of FW 1.00
www.helmholz.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 700-158-3DP01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Helmholz 700-158-3DP01

Summary of Contents for Helmholz 700-158-3DP01

  • Page 1 Quick Start Guide DP/PN Coupler Version as of FW 1.00 www.helmholz.de...

  • Page 2: Table Of Contents

    Contents 1. Introduction 2. Function of the DP/PN Coupler 3. Connection 4. Install GSD/GSDML ile 5. Set PROFIBUS address 6. Coniguration of the PROFIBUS side 7. Coniguration of the PROFINET side 8. Assign a PROFINET device name to the DP/PN Coupler 9.

  • Page 3: Introduction

    Note: Please observe the safety instructions for the product, which can be found in the manual. You can ind the manual on the accompanying CD or it can be downloaded from the website www.helmholz.de in the download area. 2. Function of the DP/PN Coupler With the DP/PN Coupler, a simple and uncomplicated connection of PROFIBUS to PROFINET networks is possible.

  • Page 4: Connection

    3. Connection The RJ45 “X1 P1” and “X1 P2” socket is for the connection of the PROFINET network. The sub-D socket is for the connection of the PROFIBUS network. The DP/PN Coupler must be supplied with 24 V DC at the wide range input 18 ...

  • Page 5: Install Gsd/Gsdml Ile

    4. Install GSD/GSDML ile The GSD and GSDML iles can be found on the accompanying CD or in the down- load area of the DP/PN Coupler at www.helmholz.de. For the PROFIBUS side, the GSD ile (“HELM0FEB.gsd”), for the PROFINET side, the GSDML ile (“GSDML-V2.33-Helmholz-DP-PN-coupler-______.xml”) is required.

  • Page 6: Coniguration Of The Profibus Side

    The DP/PN Coupler can be found in the hardware catalog under “Other ield devices -> PROFIBUS-DP -> Gateway -> Helmholz -> DP/PN Coupler”. Connect the PROFIBUS network of the PROFIBUS CPU with the DP/PN Coupler.

  • Page 7: Coniguration Of The Profinet Side

    7. Coniguration of the PROFINET side The DP/PN Coupler can be found in the hardware catalog under “Other ield devices -> PROFINET IO -> Gateway -> Helmholz GmbH & Co. KG -> Helmholz DP/PN Coupler”. Provide the DP/PN Coupler with a PROFINET name under “General”. Connect the PROFINET network of the PROFINET CPU with the DP/PN Coupler.

  • Page 8: Assign A Profinet Device Name To The Dp/Pn Coupler

    8. Assign a PROFINET device name to the DP/PN Coupler When the coniguration of the DP/PN Coupler has been completed in the hardware conigurator of the engineering tool, it can be loaded into the PLC. In order that the DP/PN Coupler can be found by the PROFINET controller, the PROFINET device name must be assigned to the DP/PN Coupler.

  • Page 9: Web Interface Of The Dp/Pn Coupler

    9. Web interface of the DP/PN Coupler The web interface of the DP/PN coupler provides an overview of the status and the Note: Calling the web page can inluence the transmission performance of the DP/ coniguration of the device, as well as the possibility to perform a irmware update. PN-Coupler.

  • Page 10: Led Status Information

    10. LED status information PB (PROFIBUS) PN (PROFINET) SF (red) Coniguration correct Coniguration correct There is no coniguration, the PROFINET coniguration does not There is no coniguration, the PROFIBUS coniguration does not agree with agree with the PROFIBUS coniguration, or a diagnosis exists. the PROFINET coniguration, or a diagnosis exists.

  • Page 11: Technical Data

    11. Technical data Order no. 700-158-3DP01 PROFINET interface PROFINET IO as deined in IEC 61158-6-10 - Protocol - Transmission rate 100 Mbps full duplex - Number of conigurable slots 2x RJ45, integrated switch - Connection Media Redundancy Protocol (MRP), automatic addressing, topology detection (LLDP, DCP), diagnosis alarm...
  • Page 12 Our products contain open source software, among others. This software is subject to the respectively relevant license conditions. We can send you the corresponding license condi- tions, including a copy of the complete license text together with the product. They are also provided in our download area of the respective products under www.helmholz.de. We also offer to send you or any third party the complete corresponding source text of the respective open source software for an at-cost fee of 10.00 Euro as a DVD upon request.
