7. Supported ModbusTCP function codes 8. Configuration in the TIA portal 9. Parameters of the PN/ModbusTCP Coupler 10. Assign a PROFINET device name to the PN/ModbusTCP Coupler 11. Web interface of the PN/ModbusTCP Coupler 12. MQTT Publisher 13. Firmware update & reset to factory settings 14.
Operate the device only in flawless condition. The permissible operating conditions and performance limits (technical data) must be adhered to. Retrofits, changes, or modifications to the device are strictly forbidden. Quick Start Guide PN/ModbusTCP Coupler...
2. Introduction This document explains the initial commissioning of the PN/ModbusTCP Coupler. SCAN You can find the most current version of the documentation under www.helmholz. QR CODE PN/ModbusTCP Coupler de or scan the QR code directly. documentation TO GET MANUAL 3.
ModbusTCP network. Install the file in the engineering tool so that the PN/ModbusTCP Coupler is available The PN/ModbusTCP Coupler must be supplied with 24 V DC at the wide range input for configuration. 18 ... 30 V via the provided connector. The power supply is designed redundantly. At least a supply path PS 1 or PS 2 must be connected.
6. Concept of data exchange The PN/ModbusTCP Coupler is a ModbusTCP server. It receives data via ModbusTCP, which is then transmitted to the IO image of the PROFINET PLC (inputs in the PLC) and makes data available as transmission data, which it receives from the PROFINET PLC (outputs in the PLC).
7. Supported ModbusTCP function codes The PN/ModbusTCP Coupler supports the following function codes: Data size Data range Function Function code Function code decimal Input bits Read discrete inputs 0x02 Read coils 0x01 Output bits or Bit access Write single coil...
8. Configuration in the TIA portal The PN/ModbusTCP Coupler can be found in the hardware catalog under “Other field devices / PROFINET IO / Gateway / Helmholz GmbH & Co. KG / Helmholz PN/Mod- busTCP Coupler”. The PN/ModbusTCP Coupler can be completely configured via the GSDML file in the PROFINET configurator.
9. Parameters of the PN/ModbusTCP Coupler The configuration of the PN/ModbusTCP Coupler can take place completely through the PROFINET hardware configurator. However, several parameters can also be optionally set via the website, e.g. the IP address of the ModbusTCP server, the DHCP host name.
When the configuration of the PN/ModbusTCP Coupler has been completed in the hardware configurator of the engineering tool, it can be loaded into the PLC. In order that the PN/ModbusTCP Coupler can be found by the PROFINET controller, the PROFINET device name must be assigned to the PN/ModbusTCP Coupler. To this purpose, use the function “Assign device name”, which you can access in the Online...
11. Web interface of the PN/ModbusTCP Coupler The web interface of the PN/ModbusTCP coupler provides an overview of the status and the configuration of the device, as well as the possibility for carrying out a firm- ware update. The ModbusTCP configuration can also be set in the web interface if this hasn’t been prescribed through the PROFINET configuration.
Page 13
The current value is displayed in brackets. The IP address and the DNS name of the ModbusTCP network interface are set on the “ModbusTCP server settings” website when these have not been fixed through the GSDML configuration. Quick Start Guide PN/ModbusTCP Coupler...
Address of the MQTT broker Broker TCP port: MQTT port at the MQTT broker Keep alive (seconds): MQTT connection monitoring in the event of inactivity Note: The MQTT Publisher of the PN/ModbusTCP Coupler currently does not provide encoding! Quick Start Guide PN/ModbusTCP Coupler...
Page 15
The following MQTT topics can also be read on both network interfaces: ClientID/Modules List: Contains the list of all topics made available by the PN/ModbusTCP Coupler via the addressed interface. ClientID/Status Register: Contains the value of both status bytes, see chapter 11.1.
“HUF” (Helmholz Update File). The firmware is transferred to the PN/ModbusTCP Coupler and burned with the “Submit” button. The PN/ModbusTCP Coupler then performs a restart and the new firmware is active. Please download the current firmware under www.helmholz.de or scan the QR code.
(static or acquired via DHCP) Byte 2: Number of active connections 11.2 Control bits The PN/ModbusTCP Coupler can be controlled via the following control bits in the PROFINET output image: Byte 1 “Control bits” Bit 7 Bit 6 Bit 5...
PS2 Power supply present RUN (green) Firmware or device defective. Please contact Support The device is ready to operate RJ45 LEDs X1 P1/P2 and X2 P1/P2 Green (Link) Connected Orange (Act) Data transfer at the port running Quick Start Guide PN/ModbusTCP Coupler...
16. Technical data Order no. 700-159-3MB01 Article designation PN/ModbusTCP Coupler Scope of delivery PN/ModbusTCP Coupler incl. Quick Start Guide PROFINET interface - Number 1 with 2 ports - Protocol PROFINET IO as defined in IEC 61158-6-10 - Transmission rate 100 Mbps full duplex - I/O image size max.
Page 20
Our customers are at the center of everything we do. We welcome all ideas and suggestions. Helmholz GmbH & Co. KG | Hannberger Weg 2 | 91091 Großenseebach | Germany | Phone +49 9135 7380-0 | Fax +49 9135 7380-110 | info@helmholz.de | www.helmholz.com...
